Parts for 90 DFI (3 Cyl.) (1.5L) 2-Stroke DFI Mercury Optimax Outboard Motor Swivel Bracket & Steering Arm

Revise Search: Outboard > 2-Stroke DFI Mercury Optimax Outboard > 90 DFI (3 Cyl.) (1.5L) > 1B227000 - 1B417701 - USA > Swivel Bracket & Steering Arm

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Swivel Bracket & Steering Arm

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	8M0088881	SWIVEL BRACKET (1 required per assembly) — Replaces: 881919T01, 898032A03
		1400-8M0088881 - 1400-8M0088881 - SWIVEL BRACKET AS [ More info ] Unavailable Replaced by 1400-8M0107419
		14008M0107419 - Swivel Bracket [ More info ] Unavailable
		1400-8M0220957 - SWIVEL BRKT ASSY [ More info ] Unavailable
#2	87735	SEAL OIL (1 required per assembly)
		26-87735 - Seal [ More info ] $30.64 3 In Stock.
#3	818764	BUSHING (2 required per assembly)
		23-818764 - Bushing [ More info ] $31.92 3 In Stock.
#4	33504	O-RING (1 required per assembly)
		25-33504 - O-Ring - Priced Individually [ More info ] $1.20 10+ In Stock.
		258M0214926 - O RING Priced Individually [ More info ] $2.89 8 In Stock.
#5	816039	SPACER (1 required per assembly)
		23-816039 - Spacer - Swivel Bracket [ More info ] $13.89 1 In Stock.
#6	8M0169589	FITTING GREASE (2 required per assembly) — Replaces: 74036
		228M0169589 - Fitting Note: Priced Individually [ More info ] $4.79 Available to Order: Shipping delay up to 10 days.
#7	821207	BUSHING (2 required per assembly)
		23-821207 - Bushing [ More info ] $12.79 2 In Stock.
#8	64014	SCREW (.250-28 X .500) (2 required per assembly)
		10-64014 - Screw [ More info ] $1.82 Available to Order: Shipping delay up to 10 days.
#9	99661A35	SWIVEL PIN ASY-BK (1 required per assembly)
		99661A35 - Swivel Pin Assembly -bk [ More info ] $566.49 Available to Order: Shipping delay up to 10 days.
#10	92876A12	LINK ROD KIT (1 required per assembly) — Replaces: 92876A10
		92876A12 - Link Rod Assembly [ More info ] Unavailable
#11	849838	SCREW (1 required per assembly)
		10-849838 - Screw [ More info ] $22.61 6 In Stock.
#12	8M0204726	NUT-BRASS @3 (2 required per assembly) — Replaces: 826709113, 8M0042636
		118M0204726 - NUT-BRASS Note: Priced Individually [ More info ] $1.80 10 In Stock.
#13	37828	WASHER (2 required per assembly)
		12-37828 - Washer, (.390 X .625 X .062) Stainless Steel [ More info ] $0.80 2 In Stock.
#14	8M0000519	BUMPER @2 (2 required per assembly) — Replaces: 881974
		8M0000519 - Bumper - Priced Individually [ More info ] $11.79 1 In Stock.
#15	881914T01	BOTTOM YOKE (1 required per assembly)
		881914T01 - Bottom Yoke [ More info ] $270.49 Available to Order: Shipping delay up to 10 days.
#16	67684	RING-RETAIN @2 (1 required per assembly)
		53-67684 - Ring - Retaining [ More info ] $4.49 7 In Stock.
#17	816432	WASHER (1 required per assembly)
		12-816432 - Washer, Thrust [ More info ] $6.99 5 In Stock.
#18	NSS	NOT SOLD SEPARATE DECAL-SERIAL OVERLAMINATE (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#19	NSS	NOT SOLD SEPARATE DECAL-SERIAL NUMBER (1 required per assembly)
#20	8M0098264	TRIM SENDER-NATRL (1 required per assembly) — Replaces: 821400A2, 8M0074845
		8M0098264 - Trim Sender - Starboard Side [ More info ] $80.51 Available to Order: Shipping delay up to 10 days.
#21	11149A58	CABLE (1 required per assembly)
		84-11149A58 - Cable [ More info ] Unavailable
#22	852368	SCREW (2 required per assembly)
		10-852368 - Screw [ More info ] $1.70 Available to Order: Shipping delay up to 10 days.
#23	26996	LOCKWASHER @15 (2 required per assembly)
		13-26996 - LockWasher - Priced Individually [ More info ] $1.20 1 In Stock.
#24	89302	WASHER @5 (2 required per assembly)
		12-89302 - Washer (.203 X .406 X .040) [ More info ] $1.80 10+ In Stock.
