Parts for 300XS (3.2L DFI) 2-Stroke DFI Mercury Optimax Outboard Motor Gear Housing Propeller Shaft-Counter-Sportmaster

Revise Search: Outboard > 2-Stroke DFI Mercury Optimax Outboard > 300XS (3.2L DFI) > 1E052058 & Up - USA > Gear Housing Propeller Shaft-Counter-Sportmaster

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gear Housing Propeller Shaft-Counter-Sportmaster

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	840307T22	G CASE 1.62 CL (1 required per assembly)
		1688-840307T22 - Gear Housing Assembly [ More info ] Unavailable
		1600-8M0236257 - GC SM CL 1.62 [ More info ] Unavailable
#-	840307T26	G CASE 1.75 CL (1 required per assembly)
		1688-840307T26 - Gear Housing Assembly [ More info ] Unavailable
#-	840307T24	G CASE 1.62 CXL (1 required per assembly)
		1688-840307T24 - Gear Housing Assembly [ More info ] Unavailable
#-	840307T30	G CASE CXXL 1.62 (1 required per assembly)
		1688-840307T30 - Gear Housing Assembly [ More info ] Unavailable
#-	840307T28	G CASE 1.75 CXL (1 required per assembly)
		1688-840307T28 - Gear Housing Assembly [ More info ] Unavailable
		1600-8M0236312 - GC SM CXL 1.75 [ More info ] Unavailable
#-	840307T32	G CASE CXXL 1.75 (1 required per assembly)
		1688-840307T32 - Gearcase Cxxl 1.75 [ More info ] Unavailable
#-	816575A6	SEAL KIT-G/H (1 required per assembly)
		26-816575A 6 - Gear Housing Seal Kit [ More info ] $104.49 Available to Order: Shipping delay up to 10 days.
#-	840389K06	HUB KIT-HD PROP (1 required per assembly)
		840389K06 - Hub Kit -hd Prop [ More info ] Unavailable
		8M0183487 - HUB KIT-HD PROP [ More info ] $205.54 Available to Order: Shipping delay up to 10 days.
#-	840382A02	SNUBBER STRIP KIT (1 required per assembly)
		840382A02 - Snubber Strip Kit [ More info ] $28.67 1 In Stock.
#1	840307T3	GEAR HOUSING ASSEMBLY BASIC (1 required per assembly)
		1688-840307T 3 - Gear Housing Assembly [ More info ] Unavailable
#2	823903	SHIFT CRANK (1 required per assembly)
		823903 - Crank [ More info ] Unavailable
		8M0226861 - CRANK-SHIFTER [ More info ] Unavailable
#3	19755T7	SPOOL ASSEMBLY (1 required per assembly)
		19755T 7 - Spool Assembly [ More info ] Unavailable
#4	NSS	NOT SOLD SEPARATE SPOOL (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#5	NSS	NOT SOLD SEPARATE SLEEVE (1 required per assembly)
#6	NSS	NOT SOLD SEPARATE COTTER PIN (1 required per assembly)
#7	47397A1	SHIM SET (AR required per assembly)
		15-47397A 1 - Shim Set [ More info ] $16.79 $11.26 10+ In Stock.
		18-2285 - Shim 15-47397A1 [ More info ] $30.99 $27.04 In Stock
#8	848876A1	ADAPTER ASSEMBLY BEARING (1 required per assembly)
		848876A 1 - Adaptor [ More info ] $371.32 Available to Order: Shipping delay up to 10 days.
#9	15843T	BEARING NEEDLE (1 required per assembly)
		31-15843T - Needle Bearing [ More info ] $56.85 8 In Stock.
#10	815480	BEARING THRUST (1 required per assembly)
		31-815480 - Thrust Bearing [ More info ] $32.49 $7.81 10+ In Stock.
#11	828290A5	GEAR ASSEMBLY REVERSE (1.62:1) (1 required per assembly)
		43-828290A 5 - Reverse Gear [ More info ] $792.74 1 In Stock.
#11	828696T4	GEAR REVERSE (1.75:1) (1 required per assembly)
		43-828696T 4 - Reverse Gear [ More info ] $816.68 Available to Order: Shipping delay up to 10 days.
#12	15844	BEARING ASSEMBLY ROLLER (1 required per assembly)
		31-15844 - Roller Bearing [ More info ] $21.29 $11.22 10+ In Stock.
#13	848878T	CLUTCH (1 required per assembly)
		52-848878T - Clutch [ More info ] $341.99 Available to Order: Shipping delay up to 10 days.
#14	78909	PIN DETENT (2 required per assembly)
		17-78909 - Pin, Detent [ More info ] $19.19 $18.40 9 In Stock.
#15	848838	PIN CROSS (1 required per assembly)
		17-848838 - Pin, Cross [ More info ] $45.49 Available to Order: Shipping delay up to 10 days.
#16	78962	SPRING (2 required per assembly)
		24-78962 - Spring, Retaining - Cross Pin [ More info ] $11.49 6 In Stock.
#17	8M0051204	PROPSHAFT (1 required per assembly) — Replaces: 841979
		44-8M0051204 - Prop Shaft [ More info ] $346.35 Available to Order: Shipping delay up to 10 days.
#18	828289A4	GEAR ASSEMBLY FORWARD (1.62:1) (1 required per assembly)
		43-828289A 4 - Forward Gear Assembly [ More info ] $811.44 1 In Stock.
#18	828695A3	GEAR ASSEMBLY FORWARD (1.75:1) (1 required per assembly)
		43-828695A 3 - Forward Gear Assembly [ More info ] $864.66 Available to Order: Shipping delay up to 10 days.
#19	1761540	SPACER SHIM (.178) (AR required per assembly)
		23-17615 40 - Spacer - Shim [ More info ] $132.96 Available to Order: Shipping delay up to 10 days.
#19	1761541	SPACER SHIM (.180) (AR required per assembly)
		23-17615 41 - Spacer Shim [ More info ] $23.20 Available to Order: Shipping delay up to 10 days.
#19	1761542	SPACER SHIM (.182) (AR required per assembly)
		23-17615 42 - Spacer Shim [ More info ] $23.20 Available to Order: Shipping delay up to 10 days.
#19	1761543	SPACER SHIM (.184) (AR required per assembly)
		23-17615 43 - SPACER Shim [ More info ] $23.20 Available to Order: Shipping delay up to 10 days.
#19	1761544	SPACER SHIM (.186) (AR required per assembly)
		23-17615 44 - Spacer Shim [ More info ] $24.04 Available to Order: Shipping delay up to 10 days.
#19	1761545	SPACER SHIM (.188) (AR required per assembly)
		23-17615 45 - Spacer Shim [ More info ] $31.80 Available to Order: Shipping delay up to 10 days.
#19	1761546	SPACER SHIM (.190) (AR required per assembly)
		23-17615 46 - Spacer Shim [ More info ] $24.37 Available to Order: Shipping delay up to 10 days.
#19	1761547	SPACER SHIM (.192) (AR required per assembly)
		23-17615 47 - Spacer Shim [ More info ] $23.20 Available to Order: Shipping delay up to 10 days.
#19	1761548	SPACER SHIM (.194) (AR required per assembly)
		23-17615 48 - Spacer Shim [ More info ] $23.20 Available to Order: Shipping delay up to 10 days.
#19	1761549	SPACER SHIM (.196) (AR required per assembly)
		23-17615 49 - Spacer Shim [ More info ] $23.20 Available to Order: Shipping delay up to 10 days.
#19	1761550	SPACER SHIM (.198) (AR required per assembly)
		23-17615 50 - Spacer Shim [ More info ] $23.20 Available to Order: Shipping delay up to 10 days.
#19	1761551	SPACER SHIM (.200) (AR required per assembly)
		23-17615 51 - Spacer Shim [ More info ] $32.18 Available to Order: Shipping delay up to 10 days.
#20	815480	BEARING THRUST (1 required per assembly)
#21	848875A1	ADAPTER ASSEMBLY BEARING (1 required per assembly)
		848875A 1 - Adaptor [ More info ] $528.78 Available to Order: Shipping delay up to 10 days.
#22	15843T	BEARING NEEDLE (1 required per assembly)
#23	18448	THRUST WASHER (1 required per assembly)
		12-18448 - Thrust Washer [ More info ] $10.19 $2.05 7 In Stock.
#24	15842	BEARING THRUST (2 required per assembly)
		31-15842 - Thrust Bearing [ More info ] $42.07 10+ In Stock.
#25	8182912	THRUST RACE (2 required per assembly)
		818291 2 - Spacer [ More info ] Unavailable
		818291 1 - Race - Thrust [ More info ] $115.62 10+ In Stock.
#26	814605	KEEPER (2 required per assembly)
		814605 - Keeper - Priced Individually [ More info ] $12.49 $2.50 10+ In Stock.
#27	31534	O-RING (1 required per assembly)
		25-31534 - O-Ring, Bearing Carrier [ More info ] Unavailable
		25-8M0214920 - Bell Housing O-Ring Note: Priced Individually [ More info ] $6.29 6 In Stock.
#28	848841A1	CARRIER ASSY-BRG (1 required per assembly) — Replaces: 848841T1
		848841A 1 - Bearing Carrier Assembly [ More info ] $587.67 Available to Order: Shipping delay up to 10 days.
#29	817072	BEARING ROLLER (1 required per assembly)
		31-817072 - Roller Bearing [ More info ] $90.49 Available to Order: Shipping delay up to 10 days.
#30	815565	SEAL OIL (2 required per assembly)
		26-815565 - Seal [ More info ] $36.77 2 In Stock.
#31	817071	RING SNAP (1 required per assembly)
		53-817071 - Ring - Retaining [ More info ] $3.99 Available to Order: Shipping delay up to 10 days.
#32	8M0058389	SCREW KIT DRAIN (1 required per assembly) — Replaces: 67892A06
		22-8M0058389 - Screw Kit - Priced Individually [ More info ] $11.69 6 In Stock.
		18-23751-9 - Drain Screw , Package of 50 [ More info ] $346.09 In Stock
		18-2375 - Plug, 22-67892A1 [ More info ] $7.16 10+ In Stock.
		10-02683 - Drain Screw [ More info ] $6.39 $6.03 2 In Stock.
#33	191833	SEAL (1 required per assembly)
		12-19183 3 - Seal -Blue - Priced Individually [ More info ] Unavailable
		18-2945-9 - Gasket 12-19183 2-Pack [ More info ] $2.41 10+ In Stock.
		12-19183Q02 - Seals, Pack of 4 (yes this is actually a pack of 4) [ More info ] $6.69 5 In Stock.
		12-19183K02 - Seal, Pack of 4 [ More info ] $7.29 8 In Stock.
		12-8M0187157 - SEAL-BLUE, Sold Individually [ More info ] $1.49 10+ In Stock.
		12-02108-1 - Drain Gasket (1 piece) [ More info ] $1.20 $0.85 10+ In Stock.
#34	30281	KEY (1 required per assembly)
		28-30281 - Key - Priced Individually [ More info ] $2.99 9 In Stock.
#35	79447	TAB WASHER (1 required per assembly)
		14-79447 - Tab Washer - Priced Individually [ More info ] $13.69 10+ In Stock.
#36	8M2000347	RETAINER (1 required per assembly) — Replaces: 79448, 8M2011027
		8M2000347 - Retainer [ More info ] Unavailable
		8M0168577 - Bearing Carrier Retaining Nut [ More info ] $43.49 In Stock
#37	85344	WASHER (.750 INSIDE DIAMETER) (1 required per assembly)
		12-85344 - Washer, (.750 Inside Diameter) [ More info ] $2.79 Available to Order: Shipping delay up to 10 days.
#38	52707Q1	PROP NUT KIT (.750-16) (1 required per assembly)
		11-52707Q 1 - Prop Nut Kit - Priced Individually [ More info ] $16.81 3 In Stock.
		18-3701 - Nut Kit, 11-52707A1 [ More info ] $24.71 10+ In Stock.
		18-3700 - Prop Nut Only, 11-52707 [ More info ] $15.31 In Stock
		11-52707T 1 - Prop Nut Kit - Priced Individually [ More info ] $16.81 2 In Stock.
		11-00122 - Prop Nut Kit [ More info ] $13.99 $11.16 Available to Order: Shipping delay up to 10 days.
#39	76214Q5	ANODE(ALUM) @2 (1 required per assembly) — Replaces: 762145
		97-76214Q 5 - Anode, Outboard & MCM Aluminum - Priced Individually [ More info ] Unavailable
		18-6244 - Anode, Magnesium, Plate Only - No Fin, 76214 [ More info ] $25.59 $24.49 6 In Stock.
		18-6016A - Anode, Aluminum, Plate Only - No Fin [ More info ] $29.75 In Stock
		18-6016 - Anodic Plate, Zinc, Plate Only - No Fin 76214 [ More info ] $26.41 3 In Stock.
		97-8M0059339 - Anode, Aluminum, BULK-10PC 76214A 6 QS [ More info ] $194.99 $192.22 Available to Order: Shipping delay up to 10 days.
#40	66024	SCREW @2 (1 required per assembly)
		10-66024 - Screw - Priced Individually [ More info ] $9.69 6 In Stock.
