Parts for 300XS (3.2L DFI) 2-Stroke DFI Mercury Optimax Outboard Motor Gear Housing Driveshaft, Torque Master 2, S/N-1E053149 & Up

Revise Search: Outboard > 2-Stroke DFI Mercury Optimax Outboard > 300XS (3.2L DFI) > 1E052058 & Up - USA > Gear Housing Driveshaft, Torque Master 2, S/N-1E053149 & Up

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gear Housing Driveshaft, Torque Master 2, S/N-1E053149 & Up

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0077244	SEAL KIT-G/H (1 required per assembly)
		26-8M0077244 - Gear Housing Seal Kit [ More info ] $96.99 Available to Order: Shipping delay up to 10 days.
#-	817275A08	REPAIR KIT-W/P (1 required per assembly) — Replaces: 8M0077246
		817275A08 - Water Pump Repair Kit [ More info ] $117.99 $113.49 In Stock
		18-3406 - Water Pump Kit 817275A08 [ More info ] $103.26 3 In Stock.
#-	8M0075782	GC TM2 1.75 SILVR (1 required per assembly)
		16008M0075782 - Gearcase TM2 1.75 SILVR [ More info ] Unavailable
		1600-8M0228610 - 1600-8M0228610 - GC TM2 1.75 SILVR [ More info ] Unavailable Replaced by -8M0236245
		1600-8M0236245 - GC TM2 1.75 SILVR [ More info ] Unavailable
#1	8M0075791	GEAR HOUSING ASSEMBLY BASIC (1 required per assembly)
		16008M0075791 - Gear Housing -Basic [ More info ] Unavailable
#2	8M0010459	FILLER BLOCK (1 required per assembly)
		8M0010459 - Filler Block [ More info ] $23.09 Available to Order: Shipping delay up to 10 days.
#3	43044	PIN DOWEL - WITHOUT HOLE (.375 X .625) (2 required per assembly)
		17-43044 - Pin -Dowel-solid [ More info ] $2.49 1 In Stock.
#4	826134Q	ANODE (2 required per assembly)
		97-826134Q - Anode, Aluminum, Outboard Side Pocket, Priced Individually [ More info ] $16.49 10 In Stock.
		18-6068 - Anode, Zinc, 826134 [ More info ] $14.31 6 In Stock.
		97-826134T - Anode - Outboard Side Pocket - Priced Individually [ More info ] $18.19 5 In Stock.
#5	4000333	SCREW (M6 X 40) (1 required per assembly)
		10-40003 33 - Screw - Priced Individually [ More info ] $4.09 10+ In Stock.
#6	401386	NUT (M6) STAINLESS STEEL (1 required per assembly)
		11-40138 6 - Nut - Priced Individually [ More info ] $5.09 9 In Stock.
#7	79953A04	PLUG ASSEMBLY (.375-16 X .250) Vent (1 required per assembly)
		10-79953A04 - Drain Screw Kit [ More info ] $6.79 Available to Order: Shipping delay up to 10 days.
		10-02699 - Drain Plug [ More info ] $3.59 $2.75 10+ In Stock.
#8	8M0204693	SEAL @6 (1 required per assembly) — Replaces: 830749
		26-8M0204693 - Drain Screw Washer, Priced Individually [ More info ] $5.19 10+ In Stock.
		10-10100-1 - Drain Screw Washer 830749 [ More info ] $3.79 $2.91 7 In Stock.
#9	76214T5	ANODE KIT Mercury (1 required per assembly)
		97-76214T 5 - Anode Kit, Aluminum, Priced Individually [ More info ] Unavailable
		18-6244 - Anode, Magnesium, Plate Only - No Fin, 76214 [ More info ] $25.59 $24.49 6 In Stock.
		18-6016A - Anode, Aluminum, Plate Only - No Fin [ More info ] $29.75 In Stock
		18-6016 - Anodic Plate, Zinc, Plate Only - No Fin 76214 [ More info ] $26.41 3 In Stock.
		97-8M0059339 - Anode, Aluminum, BULK-10PC 76214A 6 QS [ More info ] $194.99 $192.22 Available to Order: Shipping delay up to 10 days.
#9	76214Q5	ANODE KIT Quicksilver (1 required per assembly)
		97-76214Q 5 - Anode, Outboard & MCM Aluminum - Priced Individually [ More info ] Unavailable
#10	8M0204686	SCREW (1 required per assembly) — Replaces: 806327
		10-8M0204686 - Trim Tab Anode Screw, Outboard [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#11	8M0047129	COVER ASSEMBLY (1 required per assembly)
		8M0047129 - Cover Assembly [ More info ] $34.99 Available to Order: Shipping delay up to 10 days.
#12	881866	FITTING (1 required per assembly)
		22-881866 - Fitting [ More info ] $7.59 Available to Order: Shipping delay up to 10 days.
#13	896522	O-RING (799 X .103) (1 required per assembly)
		25-896522 - O-ring, (799 X .103) [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#14	8M0204708	SEAL (1 required per assembly) — Replaces: 8164641
		26-8M0204708 - Shift Shaft Oil Seal-O/B [ More info ] $16.99 Available to Order: Shipping delay up to 10 days.
		26-8M0246145 - SHIFT SHAFT OIL SEAL O/B [ More info ] $16.99 10 In Stock.
#15	8M0046563	RETAINING RING (1 required per assembly)
		53-8M0046563 - Retainer Ring [ More info ] $4.29 Available to Order: Shipping delay up to 10 days.
#16	8M0204741	SCREW @4 (4 required per assembly) — Replaces: 40011128, 8M4503518
		108M0204741 - SCREW Note: Priced Individually [ More info ] $4.59 Available to Order: Shipping delay up to 10 days.
#17	77674	WASHER (1 required per assembly)
		12-77674 - Washer, Rubber [ More info ] $1.80 4 In Stock.
		18-2316-9 - Washer, 12-77674, 5PK [ More info ] $4.69 $4.68 Available to Order: Shipping delay up to 10 days.
#18	880729	GASKET (1 required per assembly)
		27-880729 - Gasket [ More info ] $4.49 Available to Order: Shipping delay up to 10 days.
#19	824145	SHIFT SHAFT (1 required per assembly)
		824145 - Shift Shaft - Lower [ More info ] $92.93 1 In Stock.
#20	NSS	NOT SOLD SEPARATE PINION GEAR Part of 43-892595A04 (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#21	35921	NUT (.625-18) (1 required per assembly)
		11-35921 - Nut, (.625-18) [ More info ] $7.99 10+ In Stock.
		18-3719 - Nut, 11-35921, 314730 [ More info ] $5.19 1 In Stock.
		18-2359 - Nut Kit [ More info ] $5.19 $3.51 Available to Order: Shipping delay up to 10 days.
#22	92721	WASHER (1 required per assembly)
		12-92721 - Washer, Pinion Gear [ More info ] $1.50 $0.85 10+ In Stock.
#23	42647A1	BEARING ASSEMBLY ROLLER (1 required per assembly)
		31-42647A 1 - Roller Bearing - Drive Shaft [ More info ] $65.99 Available to Order: Shipping delay up to 10 days.
		18-1117 - Bearing, 387817, 31-42647A1 [ More info ] $56.09 1 In Stock.
		31-02762 - Bearing, 31-42647A1, 387817 [ More info ] $47.99 $42.20 Available to Order: Shipping delay up to 10 days.
#24	895079T	DRIVESHAFT LONG (1 required per assembly)
		45-895079T - Drive Shaft [ More info ] $503.49 1 In Stock.
#25	8M0204723	KEY @2 ALSO A COMPONENT OF WATER PUMP HOUSING (1 required per assembly) — Replaces: 8M0032833
		288M0204723 - KEY Note: Priced Individually [ More info ] $4.39 2 In Stock.
#26	8M0063267	SHIM SET (1 required per assembly) — Replaces: 8M0053110
		15-8M0063267 - Shim Set [ More info ] $28.41 10+ In Stock.
#27	8M0063268	SHIM SET (AR required per assembly)
		15-8M0063268 - Shim Set [ More info ] $31.57 4 In Stock.
#28	8M0146553	BEARING ASSEMBLY CUP/CONE (1 required per assembly) — Replaces: 48939A2
		318M0146553 - Bearing ASSY [ More info ] $27.23 1 In Stock.
#29	NSS	NOT SOLD SEPARATE CUP (1 required per assembly)
#30	8M0146566	BEARING ASSEMBLY CUP/CONE (1 required per assembly) — Replaces: 36387A1
		318M0146566 - Upper Driveshaft Bearing [ More info ] $74.99 $74.83 Available to Order: Shipping delay up to 10 days.
		31-02194 - Bearing Kit 31-36387A 1 [ More info ] $52.49 $41.29 In Stock
#31	NSS	NOT SOLD SEPARATE CUP (1 required per assembly)
#32	8245191	RETAINER (1 required per assembly)
		824519 1 - Retainer [ More info ] $6.99 1 In Stock.
		18-2346 - Retainer, 824519 1 [ More info ] $5.25 Available to Order: Shipping delay up to 10 days.
#33	817275A09	HOUSING WATER PUMP-COMPLETE (1 required per assembly)
		817275A09 - Water Pump Repair Kit [ More info ] $129.99 $124.49 In Stock
#34	861415A1	SEAL KIT (1 required per assembly)
		26-861415A 1 - Seal Kit -mcm [ More info ] $15.39 Available to Order: Shipping delay up to 10 days.
#35	8M0204741	SCREW @4 (4 required per assembly) — Replaces: 40011128, 8M4503518
#36	43026T2	IMPELLER (1 required per assembly)
		47-43026T 2 - Water Pump Impeller [ More info ] $36.49 6 In Stock.
		18-3056 - Impeller 47-43026-2 [ More info ] $26.99 $26.12 10+ In Stock.
		47-43026Q02 - Water Pump Impeller [ More info ] $36.49 Available to Order: Shipping delay up to 10 days.
#37	8M0204709	FACEPLATE-W/P (1 required per assembly) — Replaces: 8172761
		8M0204709 - Water Pump Faceplate, Outboard [ More info ] $14.59 Available to Order: Shipping delay up to 10 days.
#38	880719	RING RETAINING (1 required per assembly)
		53-880719 - Ring - Retaining [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
#39	8M0007131	CARRIER ASSEMBLY OIL SEAL (1 required per assembly)
		8M0007131 - Carrier Assembly Oil Seal [ More info ] $55.55 2 In Stock.
#40	8M0142854	O RING (2.175 X .103) (1 required per assembly) — Replaces: 896523
		25-8M0142854 - O-Ring [ More info ] $1.10 5 In Stock.
#41	NSS	NOT SOLD SEPARATE OIL SEAL (1 required per assembly)
#42	NSS	NOT SOLD SEPARATE OIL SEAL (1 required per assembly)
#43	8172771	GASKET (1 required per assembly)
		27-817277 1 - Gasket -Sold each [ More info ] $5.69 9 In Stock.
		18-2566-9 - Gasket 27-817277 2-Pack [ More info ] $8.67 10+ In Stock.
#44	8M0142616	GASKET FACE PLATE TO GEARCASE (1 required per assembly) — Replaces: 8M0050720, 8M0112903
		27-8M0142616 - Gasket LOWER [ More info ] $9.59 Available to Order: Shipping delay up to 10 days.
#45	832942A1	COUPLING ASSEMBLY (1 required per assembly)
		832942A 1 - Coupling Kit [ More info ] $28.49 Available to Order: Shipping delay up to 10 days.
#46	8M0204654	O RING @10 (1 required per assembly) — Replaces: 35027
		25-8M0204654 - O RING @10 [ More info ] Unavailable
#47	8M0204645	O RING (1 required per assembly) — Replaces: 21836
		25-8M0204645 - O RING [ More info ] $2.39 5 In Stock.
#48	43585	COUPLING (1 required per assembly)
		43585 - Shift Shaft Coupling [ More info ] $31.89 Available to Order: Shipping delay up to 10 days.
		18-1730 - Coupling, 43585 [ More info ] $32.89 $30.50 2 In Stock.
		93-02639 - Shift Coupling 43585 [ More info ] $24.99 $19.11 Available to Order: Shipping delay up to 10 days.
