Parts for 250XS (3.0L DFI) 2-Stroke DFI Mercury Optimax Outboard Motor Air Compressor Components

Revise Search: Outboard > 2-Stroke DFI Mercury Optimax Outboard > 250XS (3.0L DFI) > 1E053158 & Up - USA > Air Compressor Components

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Air Compressor Components

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	832804A03	O-RING KIT (1 required per assembly)
		25-832804A03 - O-ring Kit, Air Compressor [ More info ] $27.79 Available to Order: Shipping delay up to 10 days.
#1	8M0133589	COMPRESSOR KIT Black (1 required per assembly) — Replaces: 8M0060051
		8M0133589 - Compressor Kit [ More info ] $1,857.49 $1,806.57 Available to Order: Shipping delay up to 10 days.
#2	8M0060381	END CAP ASSEMBLY (1 required per assembly)
		11008M0060381 - End Cap Assembly [ More info ] $599.99 Available to Order: Shipping delay up to 10 days.
#3	8M0045380	SCREW (M8 X 50) (1 required per assembly)
		10-8M0045380 - Screw - Priced Individually [ More info ] $6.89 1 In Stock.
#4	67206001	O-RING (1 required per assembly)
		25-67206001 - O-Ring [ More info ] $4.69 Available to Order: Shipping delay up to 10 days.
#5	67206001	O-RING (1 required per assembly)
#6	85593920	SCREW @2 (4 required per assembly)
		10-855939 20 - Screw - Priced Individually [ More info ] $8.99 Available to Order: Shipping delay up to 10 days.
#7	833146T06	CONNECTING ROD ASSEMBLY (1 required per assembly)
		653-833146T06 - Connecting Rod Assembly [ More info ] $179.99 Available to Order: Shipping delay up to 10 days.
#8	NSS	NOT SOLD SEPARATE PISTON ASSEMBLY (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#9	8348101	RING LOCK (2 required per assembly)
		53-834810 1 - Lock Ring [ More info ] $2.49 Available to Order: Shipping delay up to 10 days.
#10	835088A10	REED PLATE ASSEMBLY (1 required per assembly)
		835088A10 - Reed Plate Assembly [ More info ] $348.49 Available to Order: Shipping delay up to 10 days.
#11	67207	O-RING (3.489 X .070) (2 required per assembly)
		25-67207 - O-ring, (3.489 X .070) [ More info ] $4.49 2 In Stock.
#12	832804	O-RING (2.739 X .070) (1 required per assembly)
		25-832804 - O-ring, (2.739 X .070) [ More info ] $5.09 Available to Order: Shipping delay up to 10 days.
#13	828225	SEAL (1 required per assembly)
		26-828225 - Seal [ More info ] $30.69 Available to Order: Shipping delay up to 10 days.
#14	8M0073890	HEAD KIT COMPRESSOR (1 required per assembly)
		8M0073890 - Compressor Head [ More info ] $173.49 Available to Order: Shipping delay up to 10 days.
#15	8307535	FITTING STRAIGHT (1 required per assembly)
		22-830753 5 - Fitting [ More info ] $22.49 Available to Order: Shipping delay up to 10 days.
#16	82127335	SCREW (M8 X 35 MM) (4 required per assembly)
		10-821273 35 - Screw [ More info ] $5.19 10+ In Stock.
#17	8M0037204	SCREW NYLON, PUSH-IN (.25-20 X .50) (1 required per assembly)
		10-8M0037204 - Screw - Priced Individually [ More info ] $5.69 Available to Order: Shipping delay up to 10 days.
#18	22875	CLIP (1 required per assembly)
		54-22875 - Clip - Priced Individually [ More info ] $3.99 1 In Stock.
#19	996642	FITTING ELBOW 90 DEGREE (.125-27 X .250) NYLON (1 required per assembly)
		22-99664 2 - Elbow [ More info ] $2.69 6 In Stock.
#20	428641	FITTING CHECK VALVE (2 required per assembly)
		21-42864 1 - Fitting [ More info ] $41.49 Available to Order: Shipping delay up to 10 days.
#21	856744	FITTING (1 required per assembly)
		22-856744 - Fitting [ More info ] $43.49 Available to Order: Shipping delay up to 10 days.
#22	16604	FITTING STRAIGHT (.125-27) (1 required per assembly)
		22-16604 - Fitting [ More info ] $11.49 1 In Stock.
#23	831985	O-RING (.468 X .078) (1 required per assembly)
		25-831985 - O-ring, (.468 X .078) [ More info ] $5.29 Available to Order: Shipping delay up to 10 days.
#24	13536A14	SENSOR ASSEMBLY TEMPERATURE (1 required per assembly)
		13536A14 - Temperature Sensor [ More info ] $64.25 1 In Stock.
#25	137151	RETAINER (1 required per assembly)
		13715 1 - Retainer [ More info ] $4.29 Available to Order: Shipping delay up to 10 days.
#26	81893414	SCREW (M8 X 14) (1 required per assembly)
		10-818934 14 - Screw [ More info ] $3.39 Available to Order: Shipping delay up to 10 days.
#27	390721	PLUG PIPE (.125-27) BRASS (1 required per assembly)
		22-39072 1 - Plug - Priced Individually [ More info ] $9.29 1 In Stock.
#28	85593920	SCREW @2 (6 required per assembly)
#29	8M0138680	PULLEY (1 required per assembly) — Replaces: 843224, 8M0051194
		8M0138680 - Pulley [ More info ] $336.99 Available to Order: Shipping delay up to 10 days.
#30	8M0045380	SCREW @5 (4 required per assembly)
#31	884594	WASHER (1 required per assembly)
		12-884594 - Washer [ More info ] $7.59 Available to Order: Shipping delay up to 10 days.
