Parts for 250XS (3.0L DFI) 2-Stroke DFI Mercury Optimax Outboard Motor Water Hoses
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 841017A51 | POWERHEAD (1 required per assembly) — Replaces: 841017A04, 841017A50 |
  |
61-841017A51 - Powerhead [ More info ] Unavailable |
|
  |
|
61-841017A52 - Powerhead 250XS [ More info ] Unavailable |
| #1 | 8552141 | FITTING (4 required per assembly) |
  |
22-855214 1 - Fitting [ More info ] Unavailable |
|
  |
|
22-8M0214961 - FITTING [ More info ] Unavailable |
| #2 | 815504406 | CLAMP (4 required per assembly) |
  |
|
54-815504406 - Clamp [ More info ]
|
| #3 | 859090001 | HOSE STARBOARD DUMP STARBOARD (1 required per assembly) — Replaces: 859090 |
  |
|
32-859090001 - Hose - Dump [ More info ]
|
| #4 | 859089001 | HOSE PORT DUMP PORT (1 required per assembly) — Replaces: 859089 |
  |
|
32-859089001 - Hose - Dump [ More info ]
|
| #5 | 856839 | HOSE (1 required per assembly) |
  |
|
32-856839 - Tubing - To Telltale [ More info ]
|
| #6 | 815504104 | CLAMP (2 required per assembly) |
  |
|
54-815504104 - Clamp [ More info ]
|
| #7 | 858807 | HOSE (1 required per assembly) |
  |
|
32-858807 - Hose [ More info ]
|
| #8 | 815504104 | CLAMP (2 required per assembly) |
| #9 | 858865 | HOSE (1 required per assembly) |
  |
|
32-858865 - Hose [ More info ]
|
| #10 | 815504104 | CLAMP (2 required per assembly) |
| #11 | 291112 | FITTING (1 required per assembly) |
  |
|
0291112 - Exhaust Gasket (291112) [ More info ] Unavailable |
| #12 | 996642 | ELBOW (1 required per assembly) |
  |
|
22-99664 2 - Elbow [ More info ]
|
