Parts for 225 (DFI) 2-Stroke DFI Mercury Optimax Outboard Motor Cylinder Block & End Cap
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 854198R99 | PH 200 DFI -RM (200) (1 required per assembly) — Replaces: 854198A99 |
  |
|
854198R99 - Powerhead 200 Dfi -rm [ More info ] Unavailable |
| #- | 854199A99 | PH 200/225 DFI (225) (1 required per assembly) |
  |
|
854199A99 - Powerhead 200/225 Dfi [ More info ] Unavailable |
| #- | 8M0133170 | GASKET SET (1 required per assembly) — Replaces: 832934A98 |
  |
|
278M0133170 - Gasket Set [ More info ]
|
| #1 | 9811A44 | CYLINDER BLOCK (225) (1 required per assembly) |
  |
|
885-9811A44 - Cylinder Block [ More info ]
|
| #1 | 9811A43 | CYLINDER BLOCK (200) (1 required per assembly) |
  |
|
885-9811A43 - Cylinder Block, NLA [ More info ]
|
| #2 | 903509 | STUD (M10 X 1.5 X 64) (4 required per assembly) |
  |
|
16-90350 9 - Stud [ More info ]
|
| #3 | 8154431 | STUD (M10 X 1.5 X 155) (6 required per assembly) |
  |
|
16-815443 1 - Stud [ More info ]
|
| #4 | 328022 | PLUG PIPE (.125-27) BRASS (1 required per assembly) |
  |
|
22-32802 2 - Brass Pipe Plug, Priced Individually [ More info ]
|
  |
|
18-4263 - Pipe Plug, 1/8-27 NPT, Brass [ More info ]
|
| #5 | 8M0204679 | PLUG-PIPE (1 required per assembly) — Replaces: 428611 |
  |
|
22-8M0204679 - Exhaust Manifold Pipe Plug [ More info ]
|
| #6 | 8248577 | DEFLECTOR (6 required per assembly) — Replaces: 8248572, 8248574 |
  |
|
824857 7 - Water Deflector [ More info ]
|
| #7 | 878105 | CHECK VALVE (1 required per assembly) — Replaces: 432781, 432783 |
  |
21-878105 - Check Valve [ More info ] Unavailable |
|
  |
|
21-878105 1 - Check Valve [ More info ]
|
| #8 | 8M0108355 | HOSE (57 INCHES BULK) (6 IN.) (1 required per assembly) — Replaces: 830756109, 8M0047428 |
  |
|
32-8M0108355 - Hose, 57 Inch [ More info ]
|
| #9 | 822769 | CONNECTOR (1 required per assembly) |
  |
|
22-822769 - Connector [ More info ]
|
| #10 | NSS | NOT SOLD SEPARATE PLUG (1 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #11 | 8M0036405 | PIN (3 required per assembly) — Replaces: 67296 |
  |
|
17-8M0036405 - Pin - Center Main [ More info ]
|
| #12 | 43044 | PIN DOWEL - WITHOUT HOLE (.375 X .625) (1 required per assembly) |
  |
|
17-43044 - Pin -Dowel-solid [ More info ]
|
| #13 | 426585 | CHECK VALVE (2 required per assembly) |
  |
|
21-42658 5 - Check Valve [ More info ]
|
| #14 | 856842 | ELBOW (1 required per assembly) |
  |
|
22-856842 - Elbow [ More info ]
|
| #15 | 850309001 | PLUG STOP (6 required per assembly) — Replaces: 850309 |
  |
|
19-850309001 - Plug - Stop [ More info ]
|
| #16 | 81893435 | SCREW (M8 X 35) (12 required per assembly) |
  |
|
10-818934 35 - Screw [ More info ]
|
  |
|
108M0103814 - Screw (M8 x 35 MM) [ More info ]
|
| #17 | 8159234 | CHECK VALVE (2 required per assembly) |
  |
|
21-815923 4 - Check Valve [ More info ]
|
| #18 | 82446180 | SCREW (M10 X 80) (8 required per assembly) |
  |
|
10-824461 80 - Screw [ More info ]
|
| #19 | 8348083 | STRAINER (1 required per assembly) |
  |
|
35-834808 3 - Strainer [ More info ]
|
| #20 | 8348083 | STRAINER [0G911719] & Below (1 required per assembly) |
| #21 | 8M0180565 | PLUG [0G911720] & Up (1 required per assembly) — Replaces: 32803 |
  |
|
228M0180565 - PLUG [ More info ]
|
| #22 | 8215832 | PIN SPECIAL (1.5 INCHES) (1 required per assembly) — Replaces: 821583 |
  |
|
821583 2 - Pin (Special) [ More info ]
|
| #23 | 892024122 | TUBING (240.00 INCHES BULK) (22-1/2 IN.) (1 required per assembly) — Replaces: 99130122 |
  |
|
32-892024122 - Tubing - 20 Feet [ More info ]
|
| #24 | 892024122 | TUBING (240.00 INCHES BULK) (3-3/4 IN.) (1 required per assembly) — Replaces: 99130122 |
| #25 | NSS | NOT SOLD SEPARATE PLUG-SERIAL NUMBER (1 required per assembly) |
| #26 | 816311T | TIE STRAP @100 (4 required per assembly) — Replaces: 816311 |
  |
|
54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ]
|
| #27 | 858714 | HOSE TO FUEL PUMP (1 required per assembly) |
  |
|
32-858714 - Hose [ More info ] Unavailable |
| #28 | 816311T | TIE STRAP @100 (2 required per assembly) — Replaces: 816311 |
| #29 | 856774 | WASHER @5 (10 required per assembly) |
  |
12-856774 - Washer, (.406 X .750 X .105) Stainless Steel [ More info ] Unavailable |
|
  |
|
128M0214963 - WASHER Note: Priced Individually [ More info ]
|
| #30 | 4013610 | NUT @3 (10 required per assembly) — Replaces: 400266 |
  |
|
11-40136 10 - Nut, (M10) Stainless Steel [ More info ]
|
| #31 | 8212251 | BRACKET (1 required per assembly) |
  |
|
821225 1 - Bracket [ More info ] Unavailable |
| #32 | 82130016 | SCREW @5 (2 required per assembly) |
  |
|
10-821300 16 - Screw - Priced Individually [ More info ]
|
| #33 | 822486 | BRACKET (1 required per assembly) |
  |
|
822486 - Guide Bracket [ More info ] Unavailable |
| #34 | 8285581 | ENCODER (1 required per assembly) |
  |
|
828558 1 - Encoder [ More info ]
|
| #35 | 82104510 | SCREW (1 required per assembly) |
  |
|
10-821045 10 - Screw [ More info ]
|
| #36 | 9787A4 | END CAP ASSY (1 required per assembly) |
  |
|
1171-9787A 4 - End Cap Assembly [ More info ]
|
| #37 | 62700 | O-RING (3.237 X .103) (1 required per assembly) |
  |
|
25-62700 - O-Ring [ More info ]
|
  |
|
18-0860-9 - O-Ring 25-62700 2-Pack [ More info ]
|
| #38 | 8308981 | SEAL (2 required per assembly) — Replaces: 830898 |
  |
|
26-830898 1 - Seal [ More info ]
|
| #39 | 82130020 | SCREW @5 (4 required per assembly) |
  |
|
10-821300 20 - Screw - Priced Individually [ More info ]
|
| #40 | 855671A2 | PLATE-ALTERNATOR (1 required per assembly) |
  |
|
855671A 2 - PLATE-ALTERNATOR,NLA [ More info ] Unavailable |
| #41 | 855729 | MOUNT (3 required per assembly) |
  |
|
23-855729 - Mount [ More info ]
|
| #42 | 82130145 | SCREW (3 required per assembly) |
  |
|
10-821301 45 - Screw [ More info ]
|
| #43 | 82130175 | SCREW (M10 X 75) (2 required per assembly) |
  |
|
10-821301 75 - SCREW,NLA [ More info ] Unavailable |
| #44 | 855725 | WASHER (4 required per assembly) |
  |
|
12-855725 - Washer [ More info ]
|
| #45 | 855726 | SPACER (2 required per assembly) |
  |
|
23-855726 - Spacer, NLA [ More info ]
|
| #46 | 855727 | SPACER (1 required per assembly) |
  |
|
23-855727 - Spacer, NLA [ More info ] Unavailable |
| #47 | 856816 | BRACKET (1 required per assembly) |
  |
|
856816 - Bracket, NLA [ More info ]
|
| #48 | 8568781 | CLAMP (2 required per assembly) |
  |
|
54-856878 1 - Clamp, NLA [ More info ]
|
| #49 | 4010610 | SCREW (2 required per assembly) |
  |
|
10-40106 10 - Screw [ More info ]
|
| #50 | 69056 | WASHER (2 required per assembly) |
  |
|
12-69056 - Washer, (.255 X .620 X .030) Stainless Steel [ More info ]
|
| #51 | 818574 | SEAL (2 required per assembly) |
  |
|
818574 - Cylinder Head Seal [ More info ]
|
| #52 | 818573 | O RING (6 required per assembly) |
  |
|
25-818573 - O-Ring [ More info ]
|
  |
|
18-7400-9 - O-Ring (PK5) 908194 [ More info ]
|
| #53 | 850275A1 | HEAD-CYL-STBD (STARBOARD)(225) (1 required per assembly) |
  |
|
903-850275A 1 - Cylinder Head Starboard, NLA [ More info ] Unavailable |
| #53 | 850276A1 | HEAD-CYL-PORT (PORT)(225) (1 required per assembly) |
  |
|
903-850276A 1 - Cylinder Head Port, NLA [ More info ]
|
| #53 | 850275A2 | HEAD-CYL-STBD (STARBOARD)(200) (1 required per assembly) |
  |
|
903-850275A 2 - Cylinder Head Starboard, NLA [ More info ] Unavailable |
| #53 | 850276A4 | HEAD-CYL-PORT (PORT)(200) (1 required per assembly) |
  |
|
903-850276A 4 - Cylinder Head Port, NLA [ More info ]
|
| #54 | 854639001 | SEAL @2 (2 required per assembly) — Replaces: 854639 |
  |
|
26-854639001 - Seal - Priced Individually [ More info ]
|
| #55 | NLA | NO LONGER AVAILABLE THERMOSTAT (Refer to Service Bullein 2002-08) (2 required per assembly) |
  |
|
NLA - No Longer Availab [ More info ] Unavailable |
| #56 | 8503181 | GASKET @6 (2 required per assembly) |
  |
|
27-850318 1 - Gasket [ More info ]
|
| #57 | 8503173 | COVER-THERMOSTAT (2 required per assembly) — Replaces: 8503171 |
  |
|
850317 3 - Thermostat Cover [ More info ]
|
| #58 | 8533393 | FITTING [0G911719] & Below (1 required per assembly) |
  |
|
22-853339 3 - Fitting, NLA [ More info ] Unavailable |
| #59 | 8533394 | FITTING [0G911720] & Up (1 required per assembly) |
  |
|
22-853339 4 - Fitting [ More info ]
|
| #60 | 82130025 | SCREW @5 (4 required per assembly) |
  |
|
10-821300 25 - Screw [ More info ]
|
| #61 | 891570050 | SCREW @5 (40 required per assembly) — Replaces: 82446050, 859096 |
  |
10-891570050 - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-8M0045380 - Screw - Priced Individually [ More info ]
|
| #62 | 8533394 | FITTING (STARBOARD) (1 required per assembly) |
| #63 | 81431247 | TUBING TO ADAPTOR PLATE (PORT 20-1/2 IN.) (1 required per assembly) |
  |
|
32-814312 47 - Hose -21 Inch [ More info ]
|
| #64 | 13536A12 | SENSOR-TEMP (PORT) (1 required per assembly) |
  |
|
13536A12 - Temperature Sensor [ More info ]
|
| #64 | 13536A14 | SENSOR-TEMP (STARBOARD) (1 required per assembly) |
  |
|
13536A14 - Temperature Sensor [ More info ]
|
| #65 | 81893412 | SCREW (2 required per assembly) |
  |
|
10-818934 12 - Screw [ More info ]
|
| #66 | 137151 | RETAINER (2 required per assembly) |
  |
|
13715 1 - Retainer [ More info ]
|
| #67 | 859092 | FITTING TO PRESSOR SENSOR (1 required per assembly) — Replaces: 623651 |
  |
|
22-859092 - Connector [ More info ]
|
| #68 | 56762 | TIE STRAP @5 (1 required per assembly) |
  |
|
56762 - Tie Strap - Priced Individually [ More info ]
|
| #69 | 8M0180565 | PLUG (1 required per assembly) — Replaces: 32803 |
| #70 | 8266241 | CLAMP (1 required per assembly) |
  |
|
826624 1 - Clamp [ More info ]
|
| #71 | 82130012 | SCREW @5 (2 required per assembly) |
  |
|
10-821300 12 - Screw - Priced Individually [ More info ]
|
| #72 | 8544862 | BRACKET (1 required per assembly) — Replaces: 8544861 |
  |
|
854486 2 - Bracket [ More info ]
|
| #73 | 850290 | LEVER-TPS (1 required per assembly) |
  |
|
850290 - Lever, NLA [ More info ]
|
| #74 | 82130025 | SCREW @5 (3 required per assembly) |
| #75 | 8318701 | BUSHING (6 required per assembly) |
  |
|
23-831870 1 - Bushing [ More info ]
|
| #76 | 834985 | GROMMET @5 (3 required per assembly) |
  |
|
25-834985 - Grommet [ More info ]
|
  |
|
25-8M0190980 - GROMMET Note: Must be ordered in multiples of 5 [ More info ]
|
| #77 | 83295221 | TPI (INSIDE) (1 required per assembly) — Replaces: 8329522, 83295220 |
  |
832952 21 - Throttle Position Indicator [ More info ] Unavailable |
|
  |
|
|
| #78 | 850882 | SPACER (1 required per assembly) |
  |
|
|
| #79 | 8M6005905 | TPI (OUTSIDE) (1 required per assembly) |
  |
|
|
| #80 | 40011117 | SCREW (3 required per assembly) |
  |
|
10-40011117 - Screw [ More info ] Unavailable |
| #81 | 1938540 | LINK (1 required per assembly) |
  |
|
19385 40 - Link, NLA [ More info ]
|
| #82 | 8568341 | CLAMP [0G911719] & Below (1 required per assembly) |
  |
|
54-856834 1 - CLAMP,NLA [ More info ] Unavailable |
| #82 | 859172 | CLAMP [0G911720] & Up (1 required per assembly) |
  |
|
54-859172 - Clamp [ More info ]
|
| #83 | 824921 | SPACER (1 required per assembly) |
  |
|
23-824921 - Spacer [ More info ]
|
| #84 | 81893420 | SCREW (1 required per assembly) |
  |
|
10-818934 20 - Screw [ More info ]
|
| #85 | 858951A01 | CLAMP KIT (1 required per assembly) — Replaces: 8568411 |
  |
|
54-858951A01 - Clamp Kit [ More info ]
|
| #86 | 8568311 | CLAMP (1 required per assembly) |
  |
|
54-856831 1 - CLAMP,NLA [ More info ] Unavailable |
