Parts for V-200 (2.5L) 1991 Only 2-Stroke Carbureted Mercury Outboard Motor Carburetor
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 815791A92 | GASKET SET (200) (1 required per assembly) — Replaces: 815791A90, 815809A90, 815810A90 |
  |
|
27-815791A92 - Engine Gasket Set [ More info ]
|
  |
|
27-27673 - Gasket Set [ More info ]
|
| #- | 8116912 | REPAIR KIT-CARB (1 required per assembly) — Replaces: 810750, 8107501 |
  |
|
1395-811691 2 - Carburetor Repair Kit [ More info ]
|
  |
|
18-7355 - Carburetor Kit, 1395-8116912 [ More info ]
|
| #- | 8107492 | GASKET KIT-CARB (1 required per assembly) — Replaces: 810749, 8107491 |
  |
|
810749 2 - Carburetor Gasket Kit [ More info ]
|
  |
|
18-7213 - Carburetor Kit, 810749-2 [ More info ]
|
  |
|
1300-36007 - Mercury Mariner V6 Carburetor Kit [ More info ]
|
| #1 | 818650A28 | CARBURETOR (135 - WMH-8A-Top) (1 required per assembly) — Replaces: 813682A4, 813682A7 |
  |
|
3311-818650A28 - Carburetor [ More info ] Unavailable |
| #1 | 818650A29 | CARBURETOR 135 - WMH-8A-Center) (1 required per assembly) — Replaces: 813682A5, 813682A8 |
  |
|
3311-818650A29 - Carburetor, NLA [ More info ] Unavailable |
| #1 | 818650A55 | CARB KIT (135 - WMH-8A-Bottom) (1 required per assembly) — Replaces: 813682A6, 813682A9 |
  |
|
3311-818650A55 - Carburetor Kit,NLA [ More info ] Unavailable |
| #1 | 818650A10 | CARB (150 - WMH-1-Top) (1 required per assembly) — Replaces: 9672A1, 9672A19 |
  |
3311-818650A10 - Carburetor [ More info ] Unavailable |
|
  |
|
3311-818650A31 - Carburetor, NLA [ More info ] Unavailable |
| #1 | 818650A11 | CARB. (150 - WMH-1-Center) (1 required per assembly) — Replaces: 9672A2, 9672A20 |
  |
3311-818650A11 - Carburetor [ More info ] Unavailable |
|
  |
|
3311-818650A32 - Carburetor [ More info ] Unavailable |
| #1 | 818650A12 | CARB. (150 - WMH-1-Bottom) (1 required per assembly) — Replaces: 9672A3, 9672A21 |
  |
3311-818650A12 - Carburetor [ More info ] Unavailable |
|
  |
3311-818650A33 - Carburetor [ More info ] Unavailable |
|
  |
|
3311-818650A56 - Carburetor [ More info ] Unavailable |
| #1 | 818650A31 | CARBURETOR (150 - WMH-7-Top) (1 required per assembly) — Replaces: 9672A19, 818650A10 |
| #1 | 818650A32 | CARBURETOR (150 - WMH-7-Center) (1 required per assembly) — Replaces: 9672A20, 818650A11 |
| #1 | 818650A33 | CARBURETOR (150 - WMH-7-Bottom) (1 required per assembly) — Replaces: 9672A21, 818650A12 |
| #1 | 9672A61 | CARB (XR4/MAGNUM II-Top) (1 required per assembly) — Replaces: 9672A13, 9672A28 |
  |
|
3308-9672A61 - Carburetor,NLA [ More info ] Unavailable |
| #1 | 9672A62 | CARB (XR4/MAGNUM II-Center) (1 required per assembly) — Replaces: 9672A14, 9672A29 |
  |
|
3308-9672A62 - Carburetor,NLA [ More info ] Unavailable |
| #1 | 9672A63 | CARB (XR4/MAGNUM II-Bottom) (1 required per assembly) — Replaces: 9672A15, 9672A30 |
  |
|
3308-9672A63 - Carburetor,NLA [ More info ] Unavailable |
| #1 | 818650A7 | CARB. (175 - WMH-2-Top) (1 required per assembly) — Replaces: 9672A4, 9672A31 |
  |
3311-818650A 7 - Carburetor [ More info ] Unavailable |
|
  |
|
3311-818650A37 - Carburetor [ More info ] Unavailable |
| #1 | 818650A8 | CARB. (175 - WMH-2-Center) (1 required per assembly) — Replaces: 9672A5, 9672A32 |
  |
3311-818650A 8 - Carburetor [ More info ] Unavailable |
|
  |
|
3311-818650A38 - Carburetor [ More info ] Unavailable |
| #1 | 818650A9 | CARB. (175 - WMH-2-Bottom) (1 required per assembly) — Replaces: 9672A6, 9672A33 |
  |
3311-818650A 9 - Carburetor [ More info ] Unavailable |
|
  |
3311-818650A39 - Carburetor [ More info ] Unavailable |
|
  |
|
3311-818650A58 - Carburetor Kit,NLA [ More info ] Unavailable |
| #1 | 818650A37 | CARBURETOR (175 - WMH-11-Top) (1 required per assembly) — Replaces: 9672A31, 818650A7 |
| #1 | 818650A38 | CARBURETOR (175 - WMH-11-Center) (1 required per assembly) — Replaces: 9672A32, 818650A8 |
| #1 | 818650A39 | CARBURETOR (175 - WMH-11-Bottom) (1 required per assembly) — Replaces: 9672A33, 818650A9 |
| #1 | 818650A4 | CARB. (200-Top) (1 required per assembly) — Replaces: 9672A7, 9672A44 |
  |
3311-818650A 4 - Carburetor [ More info ] Unavailable |
|
  |
|
3311-818650A52 - Carburetor [ More info ] Unavailable |
| #1 | 818650A5 | CARB. (200-Center) (1 required per assembly) — Replaces: 9672A8, 9672A45 |
  |
3311-818650A 5 - Carburetor [ More info ] Unavailable |
|
  |
|
3311-818650A53 - Carburetor [ More info ] Unavailable |
| #1 | 818650A6 | CARB. (200-Bottom) (1 required per assembly) — Replaces: 9672A9, 9672A46 |
  |
3311-818650A 6 - Carburetor [ More info ] Unavailable |
|
  |
|
3311-818650A59 - Carburetor Kit,NLA [ More info ] Unavailable |
| #2 | 810779 | CAP (6 required per assembly) |
  |
|
810779 - Limiter Cap [ More info ] Unavailable |
| #3 | 677511 | GASKET MOUNTING FLANGE (3 required per assembly) |
  |
|
27-67751 1 - Gasket - Priced Individually [ More info ]
|
| #4 | 810743 | TUBE ASSEMBLY EMULSLON (135/150/XR4/Magnum II/175) (3 required per assembly) |
  |
|
810743 - TUBE ASSY,NLA [ More info ] Unavailable |
| #4 | 810764 | TUBE ASSEMBLY EMULSION (200) (3 required per assembly) |
  |
|
810764 - TUBE ASSY,NLA [ More info ] Unavailable |
| #5 | 810748 | LEVER ASSEMBLY ACCELERATOR (3 required per assembly) |
  |
|
810748 - ACCEL LEVER ASSY,NLA [ More info ] Unavailable |
| #6 | 810723 | LINK ACCELERATOR (3 required per assembly) |
  |
|
810723 - ACCELERATOR LINK,NLA [ More info ] Unavailable |
| #7 | NSS | NOT SOLD SEPARATE BUSHING, ACCELERATOR LINK (3 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #8 | NSS | NOT SOLD SEPARATE RING, ACCELERATOR LINK (6 required per assembly) |
| #9 | 810721 | LEVER THROTTLE (TOP/CENTER) (2 required per assembly) |
  |
|
810721 - Throttle Lever [ More info ] Unavailable |
| #9 | 810722 | LEVER THROTTLE (BOTTOM) (1 required per assembly) |
  |
|
810722 - LEVER-THROTTLE,NLA [ More info ] Unavailable |
| #10 | NSS | NOT SOLD SEPARATE SCREW, ACCELERATOR LEVER (3 required per assembly) |
| #11 | 811284 | SPACER (200) (3 required per assembly) — Replaces: 810746 |
  |
|
1395-811284 - Spacer, NLA [ More info ]
|
| #12 | 810745 | WASHER LEVER RETAINER NUT (3 required per assembly) |
  |
|
12-810745 - WASHER,NLA [ More info ] Unavailable |
| #13 | 810744 | NUT LEVER RETAINER (3 required per assembly) |
  |
|
11-810744 - NUT,NLA [ More info ] Unavailable |
| #14 | NSS | NOT SOLD SEPARATE SPRING, THROTTLE RETURN (3 required per assembly) |
| #15 | 3517 | JET (.084) BOWL VENT (150) (3 required per assembly) |
  |
|
1399-3517 - Jet -.084 [ More info ]
|
| #15 | 6030 | JET (.070) BOWL VENT (135)(WMH-5) (3 required per assembly) |
  |
|
1395-6030 - Jet -.070 [ More info ]
|
| #15 | 6246 | JET (.048) BOWL VENT (135)(WMH-8) (3 required per assembly) |
  |
|
1395-6246 - Jet -.048 [ More info ]
|
| #15 | 19266040 | JET BOWL VENT (XRR/Magnum II) (3 required per assembly) |
  |
|
19266040 - Jet, NLA [ More info ]
|
| #15 | 6201 | JET (.080) BOWL VENT (175) (3 required per assembly) |
  |
|
1395-6201 - Jet -.080 - Priced Individually [ More info ]
|
| #15 | 3796 | JET (.076) BOWL VENT (200) (3 required per assembly) |
  |
|
1399-3796 - Jet -.076 [ More info ] Unavailable |
| #16 | 5315 | JET MAIN FUEL (.042) IDLE AIR BLEED (150) (3 required per assembly) |
  |
|
1399-5315 - Jet -.042 - See Note On Detail Page [ More info ] Unavailable |
| #16 | 7394 | JET (.044) IDLE AIR BLEED (135-WMH-5)(175) (3 required per assembly) |
  |
|
1395-7394 - Jet -.044 [ More info ]
|
| #16 | 6246 | JET (.048) IDLE AIR BLEED (135-WMH-8)(175) (3 required per assembly) |
| #16 | 19266036 | JET IDLE AIR BLEED (XR4/Magnum II-WMH-4) (3 required per assembly) |
  |
|
19266036 - Idle Air Bleed Jet, NLA [ More info ]
|
| #16 | 6359 | JET (.052) IDLE AIR BLEED (175) (3 required per assembly) |
  |
|
1395-6359 - Jet -.052 [ More info ]
|
| #16 | 19266040 | JET IDLE AIR BLEED (200) (3 required per assembly) |
| #16 | 5317 | JET (.046) IDLE AIR BLEED (200) (3 required per assembly) |
  |
|
1399-5317 - Jet -.046 [ More info ]
|
| #17 | 810742 | JET (.044) PROGRESSION AIR (150)(175-WMH-2) (3 required per assembly) |
  |
|
810742 - Jet -.044 [ More info ]
|
| #17 | 3026 | JET (.036) PROGRESSION AIR (135-WMH-5) (3 required per assembly) |
  |
|
1399-3026 - Jet -.036 [ More info ]
|
| #17 | 7570 | JET .040 PROGRESSION AIR (135WMH-8)(WMH-8) (3 required per assembly) |
  |
|
1399-7570 - Jet -.040 [ More info ]
|
| #17 | 810741 | JET (.030) PROGRESSION AIR (XR4/Magnum II) (6 required per assembly) |
  |
|
810741 - Jet .030, NLA [ More info ] Unavailable |
| #17 | 815633070 | JET PROGRESSION AIR (175-WMH-11) (6 required per assembly) |
  |
|
815633070 - Jet -.070, NLA [ More info ]
|
| #17 | 3251 | JET (.034) PROGRESSION AIR (200) (6 required per assembly) |
  |
|
1399-3251 - Jet .034, NLA [ More info ]
|
| #18 | 810747 | STEM ACCELERATOR PUMP (3 required per assembly) |
  |
|
17-810747 - ACCEL PUMP STEM,NLA [ More info ] Unavailable |
| #19 | 810737 | COVER ASSEMBLY ACCELERATOR (3 required per assembly) |
  |
|
810737 - ACCEL Cover, NLA [ More info ] Unavailable |
| #20 | NSS | NOT SOLD SEPARATE SCREW, ACCELERATOR (6 required per assembly) |
| #21 | NSS | NOT SOLD SEPARATE GASKET, FUEL BOWL (3 required per assembly) |
| #22 | NSS | NOT SOLD SEPARATE SPRING, ACCELERATOR PUMP (3 required per assembly) |
| #23 | 810762 | CUP ASSEMBLY (3 required per assembly) |
  |
|
810762 - Pump Cup Assembly, NLA [ More info ] Unavailable |
| #24 | NSS | NOT SOLD SEPARATE CUP (3 required per assembly) |
| #25 | NSS | NOT SOLD SEPARATE SPRING, ACCELERATOR PUMP (3 required per assembly) |
| #26 | 810738 | FLOAT ASSEMBLY (3 required per assembly) |
  |
|
810738 - Float Assembly [ More info ]
|
| #27 | NSS | NOT SOLD SEPARATE FLOAT SHAFT (3 required per assembly) |
| #28 | NSS | NOT SOLD SEPARATE SCREW, FLOAT SHAFT (3 required per assembly) |
| #29 | 8116901 | VALVE SEAT KIT (3 required per assembly) — Replaces: 810739, 8107391 |
  |
|
1395-811690 1 - Valve Seat Kit [ More info ]
|
| #30 | NSS | NOT SOLD SEPARATE GASKET, VALVE SEAT (3 required per assembly) |
| #31 | 810729 | BOWL FUEL (W/FITTLNG-TOP) (135/150/175/XR4/Magnum II/175-WHM-2/200) (1 required per assembly) |
  |
|
810729 - FUEL BOWL,NLA [ More info ] Unavailable |
| #31 | 810734 | BOWL FUEL (CENTER/BOTTOM) (135/150/175/XR4/Magnum II/175-WHM-2/200) (2 required per assembly) |
  |
|
810734 - FUEL BOWL,NLA [ More info ] Unavailable |
| #31 | 811932 | BOWL FUEL (TOP) (175-WMH-11) (1 required per assembly) |
  |
|
1395-811932 - Fuel Bowl, NLA [ More info ]
|
| #31 | 811931 | BOWL FUEL (CENTER/BOTTOM) (175-WMH-11) (2 required per assembly) |
  |
|
1395-811931 - Fuel Bowl, NLA [ More info ]
|
| #32 | 95961 | PLUG BOWL DRAIN POWER JET (12 required per assembly) — Replaces: 9596 |
  |
|
95961 - PLUG Bowl Drain NLA [ More info ] Unavailable |
| #33 | NSS | NOT SOLD SEPARATE GASKET, POWER/PROGRESSION JET (12 required per assembly) |
| #34 | 4217 | JET MAIN (.062) (150)(XR4/Magnum II) (6 required per assembly) |
  |
|
1399-4217 - Jet -.062 [ More info ]
|
| #34 | 6028 | JET (.050) (135) (6 required per assembly) |
  |
|
1395-6028 - Jet -.050 [ More info ]
|
| #34 | 4216 | JET (.064) (175/200) (6 required per assembly) |
  |
|
1399-4216 - Jet -.064 [ More info ]
|
| #35 | 810740 | JET POWER (150-WMH-1/XR4/Magnum II/175-WMH-2) (6 required per assembly) |
  |
|
810740 - PROG JET,NLA [ More info ] Unavailable |
| #35 | 811283 | JET POWER (150-WMH-7) (6 required per assembly) |
  |
|
1395-811283 - Progression Jet, NLA [ More info ]
|
| #35 | 816151 | JET POWER (135-WMH-5) (6 required per assembly) |
  |
|
816151 - PROG JET,NLA [ More info ] Unavailable |
| #35 | 811293 | JET POWER (135-WMH-8) (6 required per assembly) |
  |
|
1395-811293 - PROG JET,NLA [ More info ] Unavailable |
| #35 | 811685 | JET POWER (135-WMH-8A) (6 required per assembly) |
  |
|
1395-811685 - Power Jet, NLA [ More info ]
|
| #35 | 811285 | POWER JET POWER (XR4/Magnum II-WMH-6) (6 required per assembly) |
  |
|
1395-811285 - JET,NLA [ More info ] Unavailable |
| #35 | 811925 | POWER JET POWER (175-WMH-11) (6 required per assembly) |
  |
|
1395-811925 - PROG JET,NLA [ More info ] Unavailable |
| #35 | 810763 | POWER JET POWER (200) (6 required per assembly) |
  |
|
810763 - PROG JET,NLA [ More info ] Unavailable |
| #36 | NSS | NOT SOLD SEPARATE SCREW, FUEL BOWL (15 required per assembly) |
| #37 | NSS | NOT SOLD SEPARATE METERING BALL (3 required per assembly) |
| #38 | NSS | NOT SOLD SEPARATE METERING SPRING (3 required per assembly) |
| #39 | NSS | NOT SOLD SEPARATE RETAINER, METERING SPRING (3 required per assembly) |
| #40 | 7900 | TEE FITTING (TOP/CENTER) (2 required per assembly) |
  |
|
1395-7900 - Fitting -t [ More info ]
|
| #41 | 7901 | ELBOW (BOTTOM) (1 required per assembly) |
  |
|
1395-7901 - Elbow Fitting [ More info ]
|
