Parts for 200XS DFI (2.5L) 2-Stroke DFI Mercury Optimax Outboard Motor Driveshaft Housing
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 881805A01 | GASKET SET (1 required per assembly) |
  |
|
27-881805A01 - Engine Gasket Set [ More info ]
|
| #1 | 8343T10 | D SHAFT HSG-BLACK (LONG) (1 required per assembly) |
  |
|
1590-8343T10 - Drive Shaft Housing - Black [ More info ]
|
| #2 | 59579 | STUD (LONG) (2 required per assembly) |
  |
|
|
| #3 | 849330 | BOOT-IDLE EXHAUST (LONG) (1 required per assembly) |
  |
|
849330 - Boot - Idle Exhaust [ More info ]
|
| #4 | 898831 | SCREW (LONG) (2 required per assembly) — Replaces: 63474 |
  |
|
10-898831 - Screw [ More info ]
|
| #5 | 816054T1 | MOUNT @2 (LONG) (2 required per assembly) |
  |
|
816054T 1 - Mount - Priced Individually [ More info ] Unavailable |
| #6 | 816056 | WASHER (LONG) (4 required per assembly) |
  |
|
12-816056 - Washer [ More info ]
|
| #7 | 898832 | NUT @5 (LONG) (2 required per assembly) — Replaces: 82670817 |
  |
|
11-898832 - Nut, (.500-20) [ More info ]
|
| #8 | 88238A10 | CABLE ASSY (LONG) (1 required per assembly) |
  |
|
88238A10 - Cable Assembly [ More info ]
|
| #9 | 8M0036782 | CLAMP (LONG) (2 required per assembly) — Replaces: 67076 |
  |
|
54-8M0036782 - Clamp [ More info ]
|
| #10 | 66727 | SCREW @5 (LONG) (4 required per assembly) |
  |
|
10-66727 - Screw - Priced Individually [ More info ]
|
| #11 | 8M4500752 | COVER (LONG) (2 required per assembly) — Replaces: 67077T, 8M0001130 |
  |
|
100-8M4500752 - Cover [ More info ]
|
| #12 | 88417 | SCREW @5 (LONG) (4 required per assembly) |
  |
|
10-88417 - Screw - Priced Individually [ More info ]
|
| #13 | 35521 | NUT @5 (LONG) (4 required per assembly) |
  |
|
11-35521 - Nut - Priced Individually [ More info ]
|
| #14 | 88238A10 | CABLE ASSY (LONG) (1 required per assembly) |
| #15 | 41508 | SCREW (LONG) (1 required per assembly) |
  |
|
10-41508 - Screw [ More info ]
|
| #16 | 822838 | WASHER (LONG) (10 required per assembly) |
  |
|
12-822838 - Washer, (.401 X .745 X .097) [ More info ]
|
| #17 | 46335 | NUT (LONG) (10 required per assembly) |
  |
|
11-46335 - Nut (.375-24) [ More info ]
|
| #18 | 64649 | PLUG @2 (LONG) (1 required per assembly) |
  |
|
19-64649 - Plug - Priced Individually [ More info ]
|
| #19 | 18276T | EXHAUST TUBE (LONG) (1 required per assembly) — Replaces: 18276 |
  |
|
18276T - Exhaust Tube [ More info ]
|
| #20 | 66350001 | SEAL (LOWER) (LONG) [0T997974] & Up (1 required per assembly) — Replaces: 66350 |
  |
|
66350001 - Lower Seal [ More info ]
|
| #21 | 8M0039076 | SEAL (UPPER) (LONG) (1 required per assembly) — Replaces: 177261 |
  |
|
8M0039076 - Seal [ More info ]
|
| #22 | 818900T24 | D SHAFT HSG-BLACK (SHORT) (1 required per assembly) |
  |
|
1581-818900T24 - Drive Shaft Housing - Black [ More info ] Unavailable |
| #23 | 59579 | STUD (.437-14/.437-20 X 2.812) (SHORT) (2 required per assembly) |
| #24 | 818908 | STUD (.500-13/.500-20 X 4.120) (SHORT) (2 required per assembly) |
  |
|
16-818908 - Stud [ More info ]
|
| #25 | 816056 | WASHER (SHORT) (2 required per assembly) |
| #26 | 898832 | NUT (.500-20) (SHORT) (2 required per assembly) — Replaces: 82670817 |
| #27 | 8189091 | PLATE EXHAUST BLOCKOFF (SHORT) (1 required per assembly) |
  |
|
818909 1 - Plate [ More info ]
|
| #28 | 39349 | SCREW (.312-18 X .750) STAINLESS STEEL (SHORT) (1 required per assembly) |
  |
|
10-39349 - Screw - Priced Individually [ More info ]
|
| #29 | 847539 | WASHER (SHORT) (1 required per assembly) |
  |
|
12-847539 - Washer [ More info ]
|
| #30 | 822838 | WASHER (SHORT) (10 required per assembly) |
| #31 | 8M0204726 | NUT-BRASS @3 (HEIGHT = .281)(SHORT) (2 required per assembly) — Replaces: 826709113, 8M0042636 |
  |
|
118M0204726 - NUT-BRASS Note: Priced Individually [ More info ]
|
| #31 | 82671013 | NUT @5 (HEIGHT = .468)(SHORT) (8 required per assembly) |
  |
|
11-826710 13 - Nut, (.375-24) Stainless Steel [ More info ]
|
  |
|
18-3720-9 - Lock Nut, 11-34932, 5PK [ More info ]
|
| #32 | 991734 | GASKET (LONG) (1 required per assembly) |
  |
|
27-99173 4 - Gasket [ More info ]
|
| #33 | 822836 | WASHER (3 required per assembly) |
  |
|
12-822836 - Washer, (.445 X .805 X .108) [ More info ] Unavailable |
| #34 | 859116 | NUT @5 (3 required per assembly) |
  |
|
11-859116 - Nut, (.437-20), Sold Individually [ More info ]
|
