Parts for 200 (DFI) 2-Stroke DFI Mercury Optimax Outboard Motor Fuel Rails

Revise Search: Outboard > 2-Stroke DFI Mercury Optimax Outboard > 200 (DFI) > 0G590000 - 0G760299 - USA > Fuel Rails

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Fuel Rails

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	854198R99	PH 200 DFI -RM (200) (1 required per assembly) — Replaces: 854198A98, 854198A99
		854198R99 - Powerhead 200 Dfi -rm [ More info ] Unavailable
#-	854199A99	PH 200/225 DFI (225) (1 required per assembly) — Replaces: 854199A98
		854199A99 - Powerhead 200/225 Dfi [ More info ] Unavailable
#1	828123A23	COMPRESSOR KIT (SEE BREAKDOWN ON AIR COMPRESSOR COMPONENTS) (1 required per assembly) — Replaces: 828123A9, 828123A14
		828123A23 - 8M0063279 [ More info ] Unavailable
		8M0063279 - Compressor Assembly [ More info ] Unavailable
		8M0133589 - Compressor Kit [ More info ] $1,857.49 $1,806.57 Available to Order: Shipping delay up to 10 days.
#2	85593912	SCREW @5 (5 required per assembly)
		10-855939 12 - Screw [ More info ] $3.59 6 In Stock.
#3	8M0175171	PULLEY (1 required per assembly) — Replaces: 8328231, 8328233
		8M0175171 - PULLEY [ More info ] $75.49 Available to Order: Shipping delay up to 10 days.
#4	81893450	SCREW (4 required per assembly)
		10-818934 50 - Screw [ More info ] $5.29 Available to Order: Shipping delay up to 10 days.
#5	852394T5	FUEL RAIL (PORT) (1 required per assembly) — Replaces: 852394A4
		852394T 5 - FUEL RAIL-PORT,NLA [ More info ] Unavailable
#6	850065T4	AIR INJECTOR (6 required per assembly) — Replaces: 8500653, 850065T3
		850065T 4 - Air Injector [ More info ] Unavailable
		850065A 4 - Air Injector Kit [ More info ] Unavailable
		850065A 5 - Air Injector Kit [ More info ] $159.99 1 In Stock.
		850065A10 - Air Injector Kit [ More info ] Unavailable
		850065A11 - Air Injector Kit [ More info ] Unavailable
		850065A12 - Air Injector Kit [ More info ] Unavailable
		883078A 4 - Air Injector Kit [ More info ] Unavailable
		883078A05 - 8M0065916 [ More info ] Unavailable
		8M0065916 - 8M6001743 [ More info ] Unavailable
		8M6001743 - Air Injector Kit [ More info ] $999.99 Available to Order: Shipping delay up to 10 days.
#7	828694A1	WASHER ASSY (6 required per assembly)
		12-828694A 1 - Washer,Cupped [ More info ] $16.69 10+ In Stock.
#8	816311T	TIE STRAP @100 (1 required per assembly) — Replaces: 816311
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 10+ In Stock.
#9	8M0064785	HOSE FUEL/AIR BALANCE (2 required per assembly) — Replaces: 8525122
		328M0064785 - Hose [ More info ] $64.99 Available to Order: Shipping delay up to 10 days.
#10	85686953	SLEEVE-27 INCH (1 required per assembly)
		23-856869 53 - Sleeve-27 INCH [ More info ] Unavailable
#11	852395T5	FUEL RAIL (STARBOARD) (1 required per assembly) — Replaces: 852395A4
		852395T 5 - Fuel Rail- Stbd [ More info ] Unavailable
#12	85682931	TUBING (13.00 INCHES) (2-1/2 IN.) (1 required per assembly) — Replaces: 85682923
		32-856829 31 - Tubing - 13 Inch [ More info ] $17.39 Available to Order: Shipping delay up to 10 days.
#13	826810	VALVE-CHECK (1 required per assembly)
		21-826810 - Check Valve [ More info ] $94.99 $80.45 10+ In Stock.
#14	85682931	TUBING (13.00 INCHES) (9 IN.) (1 required per assembly) — Replaces: 85682923
#15	816311T	TIE STRAP @100 (4 required per assembly) — Replaces: 816311
#16	856839	HOSE (1 required per assembly)
		32-856839 - Tubing - To Telltale [ More info ] $60.99 Available to Order: Shipping delay up to 10 days.
#17	82104510	SCREW (4 required per assembly)
		10-821045 10 - Screw [ More info ] $1.10 2 In Stock.
#18	46997	CLIP (4 required per assembly)
		54-46997 - Clip [ More info ] $1.88 $1.59 10 In Stock.
#19	8M0034470	STUD (M10 X 92) (M10 X 91) (4 required per assembly) — Replaces: 852961, 858778
		16-8M0034470 - Stud [ More info ] Unavailable
		168M0063255 - Stud [ More info ] $28.29 Available to Order: Shipping delay up to 10 days.
#20	826292	NUT (4 required per assembly)
		11-826292 - Nut (M10) [ More info ] $4.19 $3.36 10+ In Stock.
#21	8M0064781	HOSE FUEL SUPPLY (1 required per assembly) — Replaces: 8568302
		32-8M0064781 - Hose [ More info ] $36.49 Available to Order: Shipping delay up to 10 days.
#22	85686953	SLEEVE-27 INCH (1 required per assembly)
#23	85466755	HOSE (2 IN.) - FUEL RETURN (1 required per assembly)
		32-854667 55 - Hose -28 Inch - NLA [ More info ] $83.84 10+ In Stock.
#24	8568201	HOSE (1 required per assembly)
		32-856820 1 - Hose, NLA [ More info ] $37.50 $31.77 4 In Stock.
#25	856952	TUBING AIR DUMP (1 required per assembly)
		32-856952 - Hose [ More info ] Unavailable
#26	850241	CLAMP (14.0) (2 required per assembly)
		54-850241 - Clamp [ More info ] $3.29 Available to Order: Shipping delay up to 10 days.
#27	8M0204696	CLAMP @5 (4 required per assembly) — Replaces: 855697
		54-8M0204696 - CLAMP Note: Priced Individually [ More info ] $2.59 Available to Order: Shipping delay up to 10 days.
#28	856880	CLAMP @5 (9 required per assembly)
		54-856880 - Clamp [ More info ] $4.10 10+ In Stock.
		54-8M0214964 - CLAMP @5 [ More info ] Unavailable
#29	8567631	HOSE (1 required per assembly)
		32-856763 1 - Hose [ More info ] $93.99 Available to Order: Shipping delay up to 10 days.
#30	85687631	SLEEVE-16 INCH (1 required per assembly)
		23-856876 31 - Sleeve -16 Inch [ More info ] $39.99 Available to Order: Shipping delay up to 10 days.
#31	8567411	FITTING (1 required per assembly)
		22-856741 1 - Fitting, NLA [ More info ] $41.25 $34.94 10+ In Stock.
