Parts for 115 DFI (3 Cyl.) (1.5L) 2-Stroke DFI Mercury Optimax Outboard Motor Gear Housing Driveshaft - 2.33:1 Gear Ratio
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 9011J37 | GC 90 DFI LG Long (1 required per assembly) |
  |
|
1667-9011J37 - Gear Housing Assembly [ More info ]
|
  |
|
90-205-B20T - SE205 Lower Unit Mercury 3 and 4 Cylinder, 2.33 to 1, Big Foot, 30-50HP, 4 Stroke, 20 Inch [ More info ]
|
  |
|
90-205-B20D - SE205 Lower Unit Mercury 3 and 4 Cylinder, 2.33 to 1, 2 Stroke, DFI, 20 Inch [ More info ]
|
| #- | 9011J39 | GC 90 DFI XL X-Long (1 required per assembly) |
  |
|
1667-9011J39 - Gear Housing Assembly [ More info ] Unavailable |
  |
|
90-205-B25D - SE205 Lower Unit Mercury 3 and 4 Cylinder, 2.33 to 1, DFI, 25 Inch [ More info ]
|
| #- | 43035A4 | SEAL KIT (1 required per assembly) |
  |
|
26-43035A 4 - Seal Kit [ More info ]
|
  |
|
26-00075 - Seal Kit, 26-43035A4 [ More info ]
|
| #- | 8M0113799 | REPAIR KIT-W/P (1 required per assembly) — Replaces: 43024A7 |
  |
|
46-8M0113799 - Water Pump Repair Kit [ More info ]
|
  |
|
46-47806 - Water Pump Repair Kit [ More info ]
|
| #- | 8M0100526 | REPAIR KIT - IMP (1 required per assembly) — Replaces: 43026Q06 |
  |
|
47-8M0100526 - Impeller Repair Kit [ More info ]
|
  |
|
18-3265 - Water Pump Kit 47-43026Q06 [ More info ]
|
  |
|
18-3214 - Impeller Repair Kit, Without Housing [ More info ]
|
  |
|
47-8M0100527 - Repair Kit - Impeller [ More info ]
|
  |
|
46-01811 - Water Pump Kit without Housing 47-43026T11, Q06 [ More info ]
|
| #- | 803489T1 | REPAIR KIT-CLUTCH (1 required per assembly) |
  |
|
52-803489T 1 - Clutch Repair Kit [ More info ]
|
| #- | 803496T2 | BEARING/SEAL KIT WITHOUT FORWARD BEARING (1 required per assembly) |
  |
|
31-803496T 2 - Repair Kit [ More info ]
|
| #1 | 9011G59 | GEAR HOUSING ASSEMBLY BASIC (1 required per assembly) |
  |
|
1667-9011G59 - Gear Housing Assembly [ More info ]
|
| #2 | 8M0084244 | PIN DOWEL FRONT (1 required per assembly) — Replaces: 43043 |
  |
|
178M0084244 - Pin - Dowel [ More info ]
|
| #3 | 43046 | TUBE OILER (1 required per assembly) |
  |
|
43046 - Oiler Tube [ More info ]
|
| #4 | 79953Q04 | SCREW KIT DRAIN (3 required per assembly) |
  |
|
10-79953Q04 - Screw Kit - Priced Individually [ More info ]
|
  |
|
18-2244 - Plug Kit, 10-79953A2 [ More info ]
|
  |
|
10-79953K04 - Drain Screw - Priced Individually [ More info ]
|
| #5 | 8M0204693 | SEAL @6 (3 required per assembly) — Replaces: 830749 |
  |
|
26-8M0204693 - Drain Screw Washer, Priced Individually [ More info ]
|
  |
|
10-10100-1 - Drain Screw Washer 830749 [ More info ]
|
| #6 | 43044 | PIN DOWEL - WITHOUT HOLE (.375 X .625) REAR (1 required per assembly) |
  |
|
17-43044 - Pin -Dowel-solid [ More info ]
|
| #7 | 31640T07 | TRIM TAB (1 required per assembly) |
  |
31640T07 - Trim Tab [ More info ] Unavailable |
|
  |
|
8M0236553 - Trim Tab [ More info ]
|
| #8 | 825427 | SCREW (.437-14 X 1.250) STAINLESS STEEL (1 required per assembly) |
  |
|
10-825427 - Screw [ More info ]
|
| #9 | 451761 | WASHER (.453 X .812 X .105) BLACK OXIDE (1 required per assembly) |
  |
|
12-45176 1 - Washer [ More info ]
|
| #10 | 43040T1 | CARRIER ASSEMBLY (1 required per assembly) |
  |
|
43040T 1 - Carrier Assembly [ More info ]
|
| #11 | NSS | NOT SOLD SEPARATE NEEDLE BEARING (1 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #12 | 826134Q | ANODE (2 required per assembly) |
  |
|
97-826134Q - Anode, Aluminum, Outboard Side Pocket, Priced Individually [ More info ]
|
  |
|
18-6068 - Anode, Zinc, 826134 [ More info ]
|
  |
|
97-826134T - Anode - Outboard Side Pocket - Priced Individually [ More info ]
|
| #13 | 401386 | NUT (M6) STAINLESS STEEL (1 required per assembly) |
  |
|
11-40138 6 - Nut - Priced Individually [ More info ]
|
| #14 | 4000333 | SCREW (M6 X 40) (1 required per assembly) |
  |
|
10-40003 33 - Screw - Priced Individually [ More info ]
|
| #15 | NSS | NOT SOLD SEPARATE PINION GEAR - 12 TEETH Part of 43-882813A3 (1 required per assembly) |
| #16 | 35921 | NUT (.625-18) (1 required per assembly) |
  |
|
11-35921 - Nut, (.625-18) [ More info ]
|
  |
|
18-3719 - Nut, 11-35921, 314730 [ More info ]
|
  |
|
18-2359 - Nut Kit [ More info ]
|
| #17 | 850307 | CAM SHIFT CONTROL (1 required per assembly) |
  |
|
850307 - Shift Control Cam [ More info ]
|
| #18 | 883047A1 | BEARING ASSEMBLY TAPERED ROLLER (1 required per assembly) |
  |
|
31-883047A 1 - Tapered Roller Bearing [ More info ]
|
| #19 | 8M0063265 | SHIM SET (AR required per assembly) — Replaces: 44492A1 |
  |
|
158M0063265 - Shim Set [ More info ]
|
| #20 | 888933A1 | DRIVESHAFT ASSEMBLY Long (1 required per assembly) |
  |
|
45-888933A 1 - Drive Shaft -lg [ More info ]
|
  |
|
92-205-04-20B - Drive Shaft replaces 45-888933A 1 [ More info ]
|
| #20 | 888934A1 | DRIVESHAFT ASSEMBLY X-Long (1 required per assembly) |
  |
|
45-888934A 1 - Drive Shaft -xl [ More info ]
|
  |
|
92-205-04-25B - Drive Shaft replaces 45-888934A 1 [ More info ]
|
| #21 | 42461A1 | SLEEVE/RING KIT (1 required per assembly) |
  |
|
42461A 1 - Sleeve/Ring Kit [ More info ]
|
| #22 | NSS | NOT SOLD SEPARATE SEAL RING (1 required per assembly) |
| #23 | 8M0113262 | COVER ASSEMBLY WATER PUMP (1 required per assembly) — Replaces: 43055A4 |
  |
|
46-8M0113262 - Water Pump Cover Assembly [ More info ]
|
| #24 | 430331 | GASKET (1 required per assembly) |
  |
|
27-43033 1 - Face Plate To Cover Gasket [ More info ]
|
| #25 | 430472 | GASKET (1 required per assembly) |
  |
27-43047 2 - Gasket [ More info ] Unavailable |
|
  |
|
27-8M0214931 - Gasket [ More info ]
|
| #26 | 43035 | SEAL OIL UPPER (1 required per assembly) |
  |
|
|
  |
|
18-0583 - Seal, 26-43035 [ More info ]
|
  |
|
26-8M0245495 - OIL SEAL [ More info ] Unavailable |
| #27 | 43036 | SEAL OIL LOWER (1 required per assembly) |
  |
|
|
  |
|
18-0522 - Seal, 26-43036 [ More info ]
|
| #28 | 8172771 | GASKET (1 required per assembly) |
  |
|
27-817277 1 - Gasket -Sold each [ More info ]
|
  |
|
18-2566-9 - Gasket 27-817277 2-Pack [ More info ]
|
| #29 | 817275A2 | HOUSING KIT UPPER WATER PUMP (1 required per assembly) |
  |
|
817275A 2 - Water Pump Housing Upper [ More info ]
|
  |
|
18-3572 - Water Pump Housing Kit 817275A2 [ More info ]
|
| #30 | 8M0204709 | FACEPLATE-W/P (1 required per assembly) — Replaces: 8172761 |
  |
|
8M0204709 - Water Pump Faceplate, Outboard [ More info ]
|
| #31 | 82684430 | SCREW (M6 X 30) (4 required per assembly) |
  |
|
10-826844 30 - Screw - Priced Individually [ More info ]
|
| #32 | 430232 | SEAL (1 required per assembly) |
  |
|
|
| #33 | 8M0204723 | KEY @2 (1 required per assembly) — Replaces: 8M0032833 |
  |
|
288M0204723 - KEY Note: Priced Individually [ More info ]
|
| #34 | 43026T2 | IMPELLER (1 required per assembly) |
  |
|
47-43026T 2 - Water Pump Impeller [ More info ]
|
  |
|
18-3056 - Impeller 47-43026-2 [ More info ]
|
  |
|
47-43026Q02 - Water Pump Impeller [ More info ]
|
| #35 | 82684425 | SCREW (M6 X 25) (6 required per assembly) |
  |
|
10-826844 25 - Screw [ More info ]
|
| #36 | 853906A1 | SHIFT SHAFT ASSEMBLY Long (1 required per assembly) |
  |
|
853906A 1 - Shaft Kit - Long [ More info ]
|
| #36 | 853908A1 | SHIFT SHAFT ASSEMBLY X-Long (1 required per assembly) |
  |
|
853908A 1 - Shaft Kit -xl [ More info ]
|
| #37 | 29641 | E RING (1 required per assembly) |
  |
|
53-29641 - E Ring - Priced Individually [ More info ]
|
| #38 | 43052A4 | BUSHING ASSEMBLY (1 required per assembly) |
  |
|
23-43052A 4 - Bushing Kit [ More info ]
|
| #39 | 8M0204681 | O RING @5 (1 required per assembly) — Replaces: 457101 |
  |
|
25-8M0204681 - O RING Note: Priced Individually [ More info ]
|
| #40 | 8M0204708 | SEAL (1 required per assembly) — Replaces: 8164641 |
  |
|
26-8M0204708 - Shift Shaft Oil Seal-O/B [ More info ]
|
  |
|
26-8M0246145 - SHIFT SHAFT OIL SEAL O/B [ More info ]
|
| #41 | 82684425 | SCREW (M6 X 25) (2 required per assembly) |
| #42 | 816575A2 | SEAL KIT (1 required per assembly) — Replaces: 861415 |
  |
|
26-816575A 2 - Seal Kit [ More info ]
|
  |
|
18-2599 - Seal, 26-816575A 2 [ More info ]
|
  |
|
26-02106 - Seal, 26-816575A2 [ More info ]
|
