Parts for 115 DFI (3 Cyl.) (1.5L) 2-Stroke DFI Mercury Optimax Outboard Motor Air Compressor
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 8M0050654 | COMPRESSOR-1.5L (1 required per assembly) — Replaces: 854333T11, 8M0048123 |
  |
|
8M0050654 - COMPRESSOR-1.5L [ More info ]
|
| #2 | 8M0086896 | END CAP ASSY (1 required per assembly) — Replaces: 853874A02, 8M0048560 |
  |
8M0086896 - End Cap Assembly [ More info ] Unavailable |
|
  |
|
8M0114192 - End Cap Assembly [ More info ]
|
| #3 | 86391 | O-RING (1 required per assembly) |
  |
|
25-86391 - O-ring,Transfer Port Cover [ More info ]
|
| #4 | 853658T02 | CONNECTING ROD ASSEMBLY (1 required per assembly) |
  |
|
657-853658T02 - Connecting Rod [ More info ]
|
| #5 | NSS | NOT SOLD SEPARATE PISTON ASSEMBLY-WITH RINGS (1 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #6 | 854638 | LOCK RING (2 required per assembly) |
  |
|
53-854638 - Lock Ring - Priced Individually [ More info ]
|
| #7 | 853584A10 | REED PLATE ASSEMBLY (1 required per assembly) |
  |
|
853584A10 - Reed Plate Assembly [ More info ]
|
| #8 | 854442 | GASKET (1 required per assembly) |
  |
|
27-854442 - Gasket [ More info ]
|
| #9 | 854443 | GASKET (1 required per assembly) |
  |
|
27-854443 - Gasket [ More info ]
|
| #10 | 854334T02 | HEAD COMPRESSOR (1 required per assembly) |
  |
|
854334T02 - Compressor Head [ More info ]
|
| #11 | 38565 | FITTING (.375-18) (1 required per assembly) |
  |
|
22-38565 - Fitting [ More info ]
|
| #12 | 82446035 | SCREW (M8 X 35 MM) (4 required per assembly) |
  |
|
10-824460 35 - Screw [ More info ]
|
| #13 | 996642 | FITTING ELBOW 90 DEGREE (.125-27 X .250) NYLON (2 required per assembly) |
  |
|
22-99664 2 - Elbow [ More info ]
|
| #14 | 856744 | FITTING (1 required per assembly) |
  |
|
22-856744 - Fitting [ More info ]
|
| #15 | 831985 | O-RING (.468 X .078) (1 required per assembly) |
  |
|
25-831985 - O-ring, (.468 X .078) [ More info ]
|
| #16 | 8M0148668 | SENSOR ASSEMBLY (1 required per assembly) — Replaces: 885342002 |
  |
|
8M0148668 - Temperature Sensor [ More info ]
|
| #17 | 896699 | O-RING (1.78 MM X .08 MM) (1 required per assembly) |
  |
|
25-896699 - O-ring, (1.78 Mm X .08 Mm) [ More info ]
|
| #18 | 888421 | CHECK VALVE (3 required per assembly) |
  |
|
21-888421 - Check Valve [ More info ]
|
| #19 | 8215832 | PIN SPECIAL (1.5 INCHES) (1 required per assembly) |
  |
|
821583 2 - Pin (Special) [ More info ]
|
| #20 | 15133 | FITTING (1 required per assembly) |
  |
|
22-15133 - Fitting [ More info ]
|
| #21 | 69355 | TIE STRAP (5.50 INCHES) (5 required per assembly) |
  |
|
69355 - Tie Strap - Priced Individually [ More info ]
|
  |
|
8M0214940 - TIE STRAP [ More info ]
|
| #22 | 88306955 | HOSE (.125 X 25.00 INCHES) (1 required per assembly) |
  |
|
32-883069 55 - Oil Line [ More info ]
|
| #23 | 889851 | CONNECTOR (1 required per assembly) |
  |
|
21-889851 - Check Valve [ More info ]
|
| #24 | 82130025 | SCREW (M6 X 25) (1 required per assembly) |
  |
|
10-821300 25 - Screw [ More info ]
|
| #25 | 853944T03 | PULLEY (1 required per assembly) |
  |
|
853944T03 - Pulley [ More info ]
|
| #26 | 85593912 | SCREW (M6 X 12) (6 required per assembly) |
  |
|
10-855939 12 - Screw [ More info ]
|
| #27 | 8M0047394 | TENSIONER ARM (1 required per assembly) — Replaces: 854799001 |
  |
|
8M0047394 - Tensioner Arm [ More info ]
|
| #28 | 8547971 | PULLEY (1 required per assembly) |
  |
|
854797 1 - Pulley [ More info ] Unavailable |
| #29 | 4010825 | SCREW (M10 X 25) HEX FLANGE - STAINLESS STEEL (1 required per assembly) |
  |
|
10-40108 25 - Screw [ More info ]
|
| #30 | 8570111 | BEARING FLANGED (2 required per assembly) |
  |
|
30-857011 1 - Bearing - Priced Individually [ More info ]
|
| #31 | 856549001 | BUSHING (2 required per assembly) |
  |
|
23-856549001 - Bushing - Priced Individually [ More info ]
|
| #32 | 88104441 | TUBING (18.00 INCHES BULK) CUT TO 8 INCHES (2 required per assembly) |
  |
|
32-881044 41 - Hose - 18 Inch [ More info ]
|
| #33 | 8547953 | SPRING (1 required per assembly) |
  |
|
24-854795 3 - Spring [ More info ]
|
| #34 | 4000382 | SCREW (M10 X 60) (1 required per assembly) |
  |
|
10-40003 82 - Screw [ More info ]
|
| #35 | 88104441 | TUBING (18.00 INCHES BULK) CUT TO 13 INCHES (1 required per assembly) |
| #36 | 816311T | TIE STRAP @100 (4 required per assembly) |
  |
|
54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ]
|
| #37 | 82446090 | SCREW (3 required per assembly) |
  |
|
10-824460 90 - Screw [ More info ]
|
