Parts for 150, XR-6 / Magnum III 2-Stroke Carbureted Mercury Outboard Motor Gear Housing (Propshaft) - Counter Rotation

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > 150, XR-6 / Magnum III > 0D082000 - 0G303045 - USA > Gear Housing (Propshaft) - Counter Rotation

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gear Housing (Propshaft) - Counter Rotation

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	815791A92	GASKET SET THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT (1 required per assembly)
		27-815791A92 - Engine Gasket Set [ More info ] $207.49 1 In Stock.
		27-27673 - Gasket Set [ More info ] $164.99 $126.17 1 In Stock.
#-	89238A2	SEAL KIT THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT (1 required per assembly)
		26-89238A 2 - Seal Kit [ More info ] $97.49 In Stock
		18-2655 - Seal Kit, 26-89238A2 [ More info ] $75.40 10+ In Stock.
		26-00288-1 - Lower Gearcase Seal Kit Mercury Mariner V6 [ More info ] $74.99 $57.34 1 In Stock.
#1	9148T47	GEAR HSG-BASIC-BL (BASIC) (GRAY) (1 required per assembly) — Replaces: 9148A47, 9148A48, 9148T48
		1647-9148T47 - Gear Housing - Basic, Black [ More info ] $1,782.99 Available to Order: Shipping delay up to 10 days.
		1647-9148T49 - Gear Housing - Basic, NLA [ More info ] $600.00 $508.20 2 In Stock.
#47	789562	CAM-SHIFT (1 required per assembly) — Replaces: 78956
		78956 2 - Shift Cam [ More info ] $11.49 3 In Stock.
#48	89594A1	CAM/FOLLOWER KIT (1 required per assembly)
		89594A 1 - Cam/Follower Kit [ More info ] $234.99 Available to Order: Shipping delay up to 10 days.
#49	79911A1	ROD KIT-CLUTCH (1 required per assembly) — Replaces: 799111
		79911A 1 - Clutch Rod Kit [ More info ] $186.49 Available to Order: Shipping delay up to 10 days.
#50	79910	SPRING (2 required per assembly)
		24-79910 - Spring, Compression [ More info ] $8.19 2 In Stock.
#51	78910	WASHER (AR required per assembly)
		12-78910 - Washer, Compression Spring [ More info ] $1.99 10+ In Stock.
#52	8M0084245	PIN - LOCATOR (1 required per assembly) — Replaces: 78906
		178M0084245 - Locator Pin [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#53	14469T	CUP-BEARING (1 required per assembly) — Replaces: 14469
		14469T - Bearing Cup [ More info ] $510.53 Available to Order: Shipping delay up to 10 days.
#54	88957T	BEARING-BALL (1 required per assembly) — Replaces: 88957A1, 88957
		30-88957T - Ball Bearing [ More info ] $64.49 Available to Order: Shipping delay up to 10 days.
#55	N.S.S.	NOT SOLD SEPARATE REVERSE GEAR (PART OF 43-18572A1 OR 43-18475A1) (1 required per assembly)
		N.S.S. - Not Sold Separate [ More info ] Unavailable
#56	15844	BEARING ASSEMBLY ROLLER (1 required per assembly)
		31-15844 - Roller Bearing [ More info ] $21.29 $11.22 10+ In Stock.
#57	78909	PIN-DETENT (2 required per assembly)
		17-78909 - Pin, Detent [ More info ] $19.19 $18.40 3 In Stock.
#58	8M0100493	CLUTCH KIT (1 required per assembly) — Replaces: 823174, 823174T
		52-8M0100493 - Clutch Kit [ More info ] $116.49 Available to Order: Shipping delay up to 10 days.
#59	8M0084243	PIN - CROSS (1 required per assembly) — Replaces: 78905
		178M0084243 - Pin - CROSS [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#60	78962	SPRING (2 required per assembly)
		24-78962 - Spring, Retaining - Cross Pin [ More info ] $11.49 6 In Stock.
#61	18572T1	GEAR SET (135/150) (1 required per assembly) — Replaces: 18572A1
		43-18572T 1 - Gear Set [ More info ] Unavailable
#61	18475T1	GEAR SET (175/200) (1 required per assembly) — Replaces: 18475A1
		43-18475T 1 - Gear Set [ More info ] $657.56 2 In Stock.
#62	176151	SPACER-SHIM (AR required per assembly)
		0176151 - L/P 25.95 [ More info ] Unavailable
#62	176152	SPACER-SHIM (AR required per assembly)
		0176152 - CR GA AY, TRIM-S/D (176152) [ More info ] Unavailable
#62	176153	SPACER-SHIM (AR required per assembly)
		0176153 [ More info ] Unavailable Replaced by 0176154
		0176154 - Ze Trim Gauge Assembly-s/D (176154) [ More info ] Unavailable
#62	176154	SPACER-SHIM (AR required per assembly)
#62	176155	SPACER-SHIM (AR required per assembly)
		0176155 - L/P 27.25 [ More info ] Unavailable
#62	176156	SPACER-SHIM (AR required per assembly)
		0176156 - Ze Trim Gauge Assembly-s/D (176156) [ More info ] Unavailable
#62	176157	SPACER-SHIM (AR required per assembly)
		23-17615 7 - Spacer - Shim [ More info ] $17.32 1 In Stock.
#62	176158	SPACER-SHIM (AR required per assembly)
		0176158 - KIT,TRIM, (176158) [ More info ] Unavailable
#62	176159	SPACER-SHIM (AR required per assembly)
		23-17615 9 - Spacer - Shim [ More info ] $18.39 Available to Order: Shipping delay up to 10 days.
#62	1761510	SPACER-SHIM (AR required per assembly)
		23-17615 10 - Spacer Shim - .143 Inch [ More info ] $18.59 Available to Order: Shipping delay up to 10 days.
#62	1761511	SPACER-SHIM (AR required per assembly)
		23-17615 11 - Spacer Shim - .145 Inch [ More info ] $17.99 Available to Order: Shipping delay up to 10 days.
#62	1761512	SPACER-SHIM (AR required per assembly)
		23-17615 12 - Spacer - Shim - .147 [ More info ] $18.59 Available to Order: Shipping delay up to 10 days.
#62	1761513	SPACER-SHIM (AR required per assembly)
		23-17615 13 - Spacer - Shim - .149 [ More info ] $18.59 1 In Stock.
#63	15841	BEARING (1 required per assembly)
		31-15841 - Roller Bearing [ More info ] $63.49 $42.45 10+ In Stock.
#64	17616	WASHER-THRUST (1 required per assembly)
		12-17616 - Thrust Washer [ More info ] $224.49 $53.78 10+ In Stock.
#65	31534	O RING @4 (1 required per assembly)
		25-31534 - O-Ring, Bearing Carrier [ More info ] Unavailable
		25-8M0214920 - Bell Housing O-Ring Note: Priced Individually [ More info ] $6.29 6 In Stock.
#66	18447T2	ADAPTOR ASSEMBLY (1 required per assembly) — Replaces: 18447A2
		18447T 2 - Adaptor Assembly [ More info ] Unavailable
#67	15843T	BEARING NEEDLE (1 required per assembly) — Replaces: 15843
		31-15843T - Needle Bearing [ More info ] $56.85 8 In Stock.
#68	18448	WASHER-THRUST (2 required per assembly)
		12-18448 - Thrust Washer [ More info ] $10.19 $2.05 7 In Stock.
#69	15842	BEARING (2 required per assembly)
		31-15842 - Thrust Bearing [ More info ] $42.07 10+ In Stock.
#70	18446	PROPSHAFT (1 required per assembly)
		44-18446 - Prop Shaft [ More info ] $512.05 4 In Stock.
#71	818896T2	BEARING CARRIER (1 required per assembly) — Replaces: 818896A2
		818896T 2 - Bearing Carrier [ More info ] Unavailable
#72	30956T	BEARING NEEDLE (1 required per assembly) — Replaces: 30956
		31-30956T - Roller Bearing [ More info ] $19.49 In Stock
#73	8M0204670	SEAL @5 (1 required per assembly) — Replaces: 76868
		26-8M0204670 - Gearcase Seal, Priced Individually [ More info ] $19.19 5 In Stock.
#74	183231	WASHER-KEYED (1 required per assembly)
		14-18323 1 - Washer -keyed [ More info ] $37.89 4 In Stock.
#75	8M2000347	RETAINER (1 required per assembly) — Replaces: 79448, 8M2011027
		8M2000347 - Retainer [ More info ] Unavailable
		8M0168577 - Bearing Carrier Retaining Nut [ More info ] $43.49 In Stock
#76	30281	KEY @5 (1 required per assembly)
		28-30281 - Key - Priced Individually [ More info ] $2.99 9 In Stock.
#77	31640Q4	TRIM TAB (USE WITH GEAR HOUSING W/O ANODES) (1 required per assembly) — Replaces: 316404
		97-31640Q4 - Anode/Trim Tab [ More info ] $18.69 8 In Stock.
		18-6241 - Trim Tab Anode, Magnesium, 31640 [ More info ] $24.39 $24.18 In Stock
		18-6011A - Trim Tab Anode, Aluminum [ More info ] $16.90 1 In Stock.
		18-6011 - Trim Tab, Zinc, 31640A1 [ More info ] $21.77 9 In Stock.
		97-31640T 4 - Trim Tab Anode [ More info ] $20.49 8 In Stock.
#77	31640T07	TRIM TAB (USE WITH GEAR HOUSING W/ANODES) (1 required per assembly) — Replaces: 316405, 31640T5
		31640T07 - Trim Tab [ More info ] Unavailable
		8M0236553 - Trim Tab [ More info ] $27.56 6 In Stock.
#78	8M0204686	SCREW (1 required per assembly) — Replaces: 806327
		10-8M0204686 - Trim Tab Anode Screw, Outboard [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#79	8M0039169	FILLER BLOCK (1 required per assembly) — Replaces: 67891
		8M0039169 - Filler Block [ More info ] $31.99 Available to Order: Shipping delay up to 10 days.
#80	45176	WASHER @5 THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT (2 required per assembly)
		12-45176 - Washer, (.453 X .812 X .105) [ More info ] $1.50 6 In Stock.
#81	8M0204653	NUT @10 THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT (2 required per assembly) — Replaces: 34933
		11-8M0204653 - Prop Lock Nut 7/16-20 , Priced Individually [ More info ] $5.29 9 In Stock.
		11-00118 - Nut, Sold Individually [ More info ] $3.59 $2.95 7 In Stock.
#82	8354671	THRUST WASHER THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT (1 required per assembly) — Replaces: 13171, 835467
		12-835467 1 - Thrust Washer [ More info ] $19.99 10+ In Stock.
		12-835467Q01 - Thrust Washer - Priced Individually [ More info ] $41.60 10 In Stock.
		18-4220 - Washer, 12-835467 1 [ More info ] $39.19 4 In Stock.
		12-835467K01 - Thrust Washer - Priced Individually [ More info ] $41.60 Available to Order: Shipping delay up to 10 days.
#83	31211Q03	WASHER @2 THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT (1 required per assembly) — Replaces: 31211A2, 31211A3
		12-31211Q03 - Washer - Priced Individually [ More info ] $14.82 Available to Order: Shipping delay up to 10 days.
		18-3714 - Washer, 12-31211A2 [ More info ] $11.54 4 In Stock.
		12-31211K03 - Washer - Priced Individually [ More info ] $14.82 1 In Stock.
#84	816629Q	TAB WASHER @2 THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT (1 required per assembly) — Replaces: 816629
		14-816629Q - Tab Washer - Priced Individually [ More info ] $6.04 10 In Stock.
		18-3200-9 - Washer, 14-816629, 10PK [ More info ] $78.72 4 In Stock.
		14-816629K - Tab Washer - Priced Individually [ More info ] $6.08 10+ In Stock.
#85	52707Q1	PROP NUT KIT@2 THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT (1 required per assembly) — Replaces: 52707A1
		11-52707Q 1 - Prop Nut Kit - Priced Individually [ More info ] $16.81 3 In Stock.
		18-3701 - Nut Kit, 11-52707A1 [ More info ] $24.71 10+ In Stock.
		18-3700 - Prop Nut Only, 11-52707 [ More info ] $15.31 In Stock
		11-52707T 1 - Prop Nut Kit - Priced Individually [ More info ] $16.81 2 In Stock.
		11-00122 - Prop Nut Kit [ More info ] $13.99 $11.16 Available to Order: Shipping delay up to 10 days.
#86	423511	WASHER @2 THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT (1 required per assembly)
		13-42351 1 - Washer - Priced Individually [ More info ] $3.05 10+ In Stock.
#87	65210	SCREW @3 THESE REPLACEMENT PARTS ARE NOT INCLUDED WITH COMPLETE GEAR HOUSING REPLACEMENT (1 required per assembly)
		10-65210 - Screw - Priced Individually [ More info ] $2.89 3 In Stock.
#73A	8M0204670	SEAL @5 (1 required per assembly) — Replaces: 76868
