Parts for 40, W40 (w / Marathon) 2-Stroke Carbureted Mercury Outboard Motor Intake Manifold
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 11764M | GASKET SET (1 required per assembly) |
  |
|
27-11764M - Gasket Set [ More info ] Unavailable |
| #1 | 11773M | REED VALVE ASSY (2 required per assembly) |
  |
|
11773M - REED Valve,NLA [ More info ] Unavailable |
| #2 | 92676M | REED SET (1 required per assembly) |
  |
|
34-92676M - Reed Kit, NLA [ More info ]
|
| #3 | 11775M | INTAKE MANIFOLD (1 required per assembly) |
  |
|
11775M - Intake Manifold [ More info ] Unavailable |
| #4 | 80727M | CHECK VALVE (1 required per assembly) |
  |
|
21-80727M - Check Valve, NLA [ More info ]
|
| #5 | 811045M | HOSE (1 required per assembly) — Replaces: 99990M |
  |
|
32-811045M - Hose, NLA [ More info ] Unavailable |
| #6 | 82046M | CLIP @5 (10 required per assembly) |
  |
|
54-82046M - Clip, NLA [ More info ]
|
| #7 | 11776 | GASKET (1 required per assembly) — Replaces: 11776M |
  |
|
27-11776 - Gasket [ More info ] Unavailable |
| #8 | 83356M | SCREW @2 (4 required per assembly) |
  |
|
10-83356M - Screw, NLA [ More info ]
|
| #9 | 11778M | GASKET (2 required per assembly) |
  |
|
27-11778M - Cover Gasket [ More info ] Unavailable |
| #10 | 11779M | STUD (4 required per assembly) |
  |
|
16-11779M - Stud, NLA [ More info ]
|
| #11 | 84658M | SCREW (2 required per assembly) |
  |
|
10-84658M - Screw, NLA [ More info ]
|
| #12 | 82405M | SCREW @2 (7 required per assembly) |
  |
|
10-82405M - Screw, NLA [ More info ]
|
| #13 | 82214M | WASHER @5 (13 required per assembly) |
  |
|
12-82214M - Washer - Priced Individually [ More info ]
|
| #14 | 811013M | COVER [M-029924/ML-365385] & Below (1 required per assembly) — Replaces: 11780M |
  |
|
811013M - Cover [ More info ] Unavailable |
| #15 | 811045M | HOSE (1 required per assembly) — Replaces: 84731M |
| #16 | 11791M | CHECK VALVE (1 required per assembly) |
  |
|
21-11791M - Check Valve, NLA [ More info ]
|
| #17 | 11781 | GASKET (1 required per assembly) — Replaces: 11781M |
  |
|
27-11781 - Gasket [ More info ] Unavailable |
| #18 | 80122M | FITTING @2 (4 required per assembly) |
  |
|
22-80122M - Fitting - Priced Individually, NLA [ More info ]
|
| #19 | 11782M | GASKET (1 required per assembly) |
  |
|
27-11782M - Cover Gasket [ More info ]
|
| #20 | 82389M | NUT @2 (4 required per assembly) — Replaces: 82380M |
  |
|
11-82389M - Nut, NLA [ More info ] Unavailable |
| #21 | 11787M | LEVER (1 required per assembly) |
  |
|
|
| #22 | 11790M | PIN (1 required per assembly) |
  |
|
17-11790M - Pin, NLA [ More info ] Unavailable |
| #23 | 11783M | COVER (1 required per assembly) |
  |
|
11783M - Cover [ More info ] Unavailable |
| #24 | 95558M | O-RING (1 required per assembly) |
  |
|
25-95558M - O-Ring, NLA [ More info ]
|
| #25 | 11784M | COVER (1 required per assembly) |
  |
|
|
| #26 | 11785M | SCREW (3 required per assembly) |
  |
|
10-11785M - Screw, NLA [ More info ] Unavailable |
| #27 | 95526M | SCREW (4 required per assembly) |
  |
|
10-95526M - SCREW,NLA [ More info ] Unavailable |
| #28 | 11786M | GASKET (1 required per assembly) |
  |
|
27-11786M - Cover Gasket [ More info ] Unavailable |
| #29 | 811045M | HOSE (3 required per assembly) — Replaces: 81995M |
| #30 | 11788M | ROD (1 required per assembly) |
  |
|
|
| #31 | 16333 | ROD SNAP (1 required per assembly) — Replaces: 81191M |
  |
|
16333 - Rod Snap [ More info ] Unavailable |
| #32 | 83960M | CHOKE KNOB (1 required per assembly) |
  |
|
83960M - Choke Knob, NLA [ More info ] Unavailable |
| #33 | 84760M | GROMMET (1 required per assembly) |
  |
|
25-84760M - Grommet, Choke Knob,NLA [ More info ] Unavailable |
