Parts for V-200 2-Stroke Carbureted Mercury Outboard Motor Choke Plate & Throttle Levers (Design II)
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 89221A88 | GASKET SET [Merc-6203991/Mariner-6201970] & Up (1 required per assembly) |
  |
|
27-89221A88 - Gasket Set [ More info ] Unavailable |
  |
|
18-4319 - Gasket, 27-11338A88 [ More info ]
|
| #- | 89221A80 | GASKET SET [Merc-6073192/Mariner-6055033] THRU [Merc-6203990/Mariner-6201969] (1 required per assembly) |
  |
|
27-89221A80 - Gasket Set [ More info ]
|
| #1 | 67245T | BRACKET COWL MOUNTIN - UPPER (1 required per assembly) |
  |
|
67245T - Bracket, NLA [ More info ]
|
| #2 | 67272 | GROMMET (2 required per assembly) |
  |
|
25-67272 - Grommet, NLA [ More info ] Unavailable |
| #3 | 90435 | MOUNT (2 required per assembly) |
  |
|
90435 - Rubber Mount [ More info ]
|
| #4 | 21249 | WASHER @5 (4 required per assembly) |
  |
|
12-21249 - Washer - Priced Individually [ More info ]
|
| #5 | 8267089 | NUT @5 (4 required per assembly) — Replaces: 20361 |
  |
|
11-826708 9 - Nut - Priced Individually [ More info ]
|
  |
|
18-3722-9 - Lock Nut, 121731, 11-35888, Pack of 5 [ More info ]
|
| #6 | 93772A2 | MODULE ASSY (1 required per assembly) |
  |
|
93772A 2 - Module Assembly [ More info ] Unavailable |
| #7 | 892211 | GASKET (3 required per assembly) |
  |
|
27-89221 1 - Gasket [ More info ]
|
| #8 | 88509 | PLATE (1 required per assembly) |
  |
|
88509 - Plate, NLA [ More info ] Unavailable |
| #9 | 43440T | INLET (2 required per assembly) |
  |
|
43440T - Inlet, NLA [ More info ]
|
| #10 | 48408 | SCREW @5 (12 required per assembly) |
  |
|
10-48408 - Screw - Priced Individually [ More info ]
|
| #11 | 877361 | GASKET (1 required per assembly) |
  |
|
27-87736 1 - Gasket [ More info ]
|
| #12 | 93518A1 | COVER ASSY (1 required per assembly) |
  |
|
93518A 1 - Cover Assembly [ More info ] Unavailable |
| #13 | 48408 | SCREW @5 (9 required per assembly) |
| #14 | 88488 | SCREW (3-1/4") (4 required per assembly) |
  |
|
10-88488 - Screw, NLA [ More info ] Unavailable |
| #15 | 884891 | SCREW (2 required per assembly) — Replaces: 88489 |
  |
|
10-88489 1 - Screw [ More info ]
|
| #16 | 35459 | WASHER (6 required per assembly) |
  |
|
12-35459 - Washer (.265 X .620 X .06) [ More info ]
|
| #17 | 67760 | LINK [Merc-6073191/Mariner-6055032] & Below (1 required per assembly) |
  |
|
67760 - Link, NLA [ More info ] Unavailable |
| #17 | 87604 | THROTTLE LINK [Merc-6073192/Mariner-6055033] & Up (1 required per assembly) |
  |
|
87604 - Throttle Link, NLA [ More info ] Unavailable |
| #18 | 67759 | LEVER (Upper/Center) [Merc-6073191/Mariner-6055032] & Below (2 required per assembly) |
  |
|
67759 - Throttle Lever [ More info ]
|
| #18 | 67749 | THROTTLE LEVER (Lower) [Merc-6073191/Mariner-6055032] & Below (1 required per assembly) |
  |
|
67749 - Throttle Lever [ More info ] Unavailable |
| #18 | 828277A1 | LINKAGE KIT (OIL INJECTION) (1 required per assembly) — Replaces: 93332A1, 41048 |
  |
|
828277A 1 - Linkage Kit [ More info ] Unavailable |
| #19 | 15124 | SCREW (#10-32 X .750) (3/4") (3 required per assembly) — Replaces: 92501 |
  |
|
10-15124 - Screw [ More info ]
|
| #20 | 26996 | LOCKWASHER @15 (3 required per assembly) |
  |
|
13-26996 - LockWasher - Priced Individually [ More info ]
|
| #21 | 24676 | WASHER (3 required per assembly) |
  |
|
12-24676 - Washer, (.200 X .440 X .032) [ More info ]
|
| #22 | 67297 | PIN-CLEVIS (3 required per assembly) |
  |
|
17-67297 - Clevis Pin [ More info ]
|
| #23 | 89302 | WASHER @5 (3 required per assembly) — Replaces: 27736 |
  |
|
12-89302 - Washer (.203 X .406 X .040) [ More info ]
|
| #24 | 26953 | PIN-COTTER @5 (3 required per assembly) |
  |
|
18-26953 - Cotter Pin - Priced Individually [ More info ]
|
| #25 | 67748 | ROLLER (1 required per assembly) |
  |
|
|
