Parts for V-150 Magnum 2-Stroke Carbureted Mercury Outboard Motor Transom Bracket (S/N me-5503247 / Ma-5600162 - 6616990)
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 79879A1 | REPAIR KIT-TRIM (1 required per assembly) |
  |
|
79879A 1 - Trim Repair Kit [ More info ]
|
| #1 | 7476T1 | TRANSOM BRACKET (BLACK)(PORT ) (1 required per assembly) |
  |
|
1494-7476T 1 - Transom Bracket,NLA [ More info ] Unavailable |
| #1 | 7476T6 | TRANSOM BRACKET (GRAY)(PORT ) (1 required per assembly) |
  |
|
1494-7476T 6 - TRANSOM BRA,NLA [ More info ] Unavailable |
| #2 | 7478T1 | TRANSOM BRACKET (BLACK)(STARBOARD ) (1 required per assembly) |
  |
|
1495-7478T 1 - Transom Bracket,NLA [ More info ] Unavailable |
| #2 | 7478T6 | TRANSOM BRACKET (GRAY)(STARBOARD ) (1 required per assembly) |
  |
|
1495-7478T 6 - TRANSOM BRA,NLA [ More info ] Unavailable |
| #3 | 677552 | SCREW (2 required per assembly) |
  |
|
10-67755 2 - Screw [ More info ]
|
| #4 | 8M0149747 | SCREW (2 required per assembly) — Replaces: 677551 |
  |
|
108M0149747 - SCREW [ More info ]
|
| #5 | 8M0204648 | WASHER @5 (4 required per assembly) — Replaces: 28421 |
  |
|
12-8M0204648 - ENGINE MOUNTING WASHER Note: Must be ordered in multiples of 5 O/B [ More info ]
|
| #6 | 35000 | NUT @2 (4 required per assembly) |
  |
|
11-35000 - Nut,(1/2-20 ) [ More info ]
|
| #7 | 87180 | SCREW (1 required per assembly) |
  |
|
10-87180 - Screw [ More info ]
|
| #8 | 82671317 | NUT @5 (1 required per assembly) — Replaces: 20220 |
  |
|
11-826713 17 - Nut, (.500-20) [ More info ]
|
| #9 | 826125A1 | TILT TUBE KIT (1 required per assembly) — Replaces: 99170A1, 99170A2 |
  |
|
826125A 1 - Tilt Tube Kit [ More info ]
|
| #10 | 88750 | WASHER-WAVE @2 (2 required per assembly) |
  |
|
13-88750 - Wave Washer - Priced Individually [ More info ]
|
| #11 | 858869 | NUT @5 (1 required per assembly) — Replaces: 56041, 30499 |
  |
|
11-858869 - Nut, (.875-14) [ More info ]
|
| #11 | 34862 | NUT (1"-14-BLACK) (1 required per assembly) — Replaces: 90068T, 90068F2 |
  |
|
11-34862 - Nut (1.0-14) [ More info ]
|
  |
|
11-859133 - Nut, NLA [ More info ] Unavailable |
| #11 | 859133 | ORD 11-826713 27 (1"-14-GRAY) (1 required per assembly) — Replaces: 90068T6, 90068F3 |
| #12 | 45711 | O RING @5 (1 required per assembly) |
  |
|
25-45711 - Valve Cover O-Ring, Priced Individually [ More info ]
|
| #13 | 85026T | PLATE (2 required per assembly) — Replaces: 85026 |
  |
|
|
| #14 | 28636 | SCREW @5 (4 required per assembly) |
  |
|
10-28636 - Screw - Priced Individually [ More info ]
|
| #15 | 8M0204649 | WASHER @10 (1 required per assembly) — Replaces: 29245 |
  |
|
12-8M0204649 - WASHER Note: Priced Individually [ More info ]
|
| #16 | 85035T | SPACER (1 required per assembly) |
  |
85035T - Spacer - Black [ More info ] Unavailable |
|
  |
|
8M0237541 - SPACER [ More info ] Unavailable |
| #17 | 70732 | SCREW @5 (4 required per assembly) |
  |
|
10-70732 - Screw - Priced Individually [ More info ]
|
| #18 | 8M0204649 | WASHER @10 (4 required per assembly) — Replaces: 29245 |
| #19 | 89949A1 | PLATE ASSY (1 required per assembly) |
  |
|
89949A 1 - Anode Plate, Aluminum [ More info ]
|
| #20 | 90192 | SCREW (.250-20 X .750) STAINLESS STEEL (4 required per assembly) — Replaces: 89996 |
  |
|
10-90192 - Screw [ More info ]
|
| #21 | 88512 | CLAMP (4 required per assembly) |
  |
|
54-88512 - Clamp [ More info ]
|
| #22 | 88829 | SCREW (4 required per assembly) |
  |
|
10-88829 - Screw [ More info ]
|
| #23 | 26996 | LOCKWASHER @15 (4 required per assembly) |
  |
|
13-26996 - LockWasher - Priced Individually [ More info ]
|
| #24 | 79610A6 | CYLINDER ASSY (1 required per assembly) |
  |
|
79610A 6 - Cylinder Assembly, NLA [ More info ]
|
| #25 | 86489 | BUSHING (2 required per assembly) |
  |
|
23-86489 - Bushing - Trim Cylinder [ More info ]
|
| #26 | 85022 | WASHER (2 required per assembly) |
  |
|
12-85022 - Washer, Transom Bracket Bass [ More info ]
|
| #27 | 30316 | SPRING (2 required per assembly) |
  |
|
24-30316 - Spring [ More info ]
|
| #28 | 85020T | PIN-PIVOT (2 required per assembly) — Replaces: 85020 |
  |
|
17-85020T - Pivot Pin [ More info ]
|
| #29 | 85024 | SHAFT (1 required per assembly) |
  |
|
85024 - SHAFT,NLA [ More info ] Unavailable |
| #30 | 86637 | BEARING (2 required per assembly) |
  |
|
23-86637 - Bearing - Trim Shaft [ More info ]
|
| #31 | 91862 | PIN (1 required per assembly) |
  |
|
17-91862 - Pin, Trim Cylinder, NLA [ More info ]
|
| #32 | 89024A1 | HOSE (PORT) (1 required per assembly) |
  |
|
32-89024A 1 - Hose - Hydraulic [ More info ]
|
| #32 | 89023A2 | HOSE (STARBOARD) (1 required per assembly) |
  |
|
32-89023A 2 - Hose - Hydraulic [ More info ]
|
| #33 | 12602002 | GROMMET (2 required per assembly) — Replaces: 12602, 126021 |
  |
|
25-12602002 - Grommet (.44 I.d.) [ More info ]
|
| #34 | 87207 | CONNECTOR (1 required per assembly) |
  |
|
22-87207 - Connector [ More info ]
|
| #35 | 87871T | COVER (1 required per assembly) — Replaces: 87871 |
  |
|
|
| #36 | 87775 | GASKET (1 required per assembly) |
  |
|
27-87775 - Inlet Cover Gasket [ More info ]
|
| #37 | 45507 | GROMMET @2 (1 required per assembly) |
  |
|
25-45507 - Grommet, Rubber [ More info ]
|
| #38 | 36070 | SCREW @5 (4 required per assembly) |
  |
|
10-36070 - Screw - Priced Individually [ More info ]
|
| #38 | 32866 | SCREW @5 (4 required per assembly) |
  |
|
10-32866 - Screw - Priced Individually [ More info ]
|
| #39 | 26996 | LOCKWASHER @15 (4 required per assembly) |
| #40 | 68219 | NUT @5 (4 required per assembly) |
  |
|
11-68219 - Nut (#10-32) [ More info ]
|
