Parts for V-150 2-Stroke Carbureted Mercury Outboard Motor Carburetor (Wmh-30 / 31 / 32 / 33 / 34)

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > V-150 > 0D082000 - 0G303045 - USA > Carburetor (Wmh-30 / 31 / 32 / 33 / 34)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Carburetor (Wmh-30 / 31 / 32 / 33 / 34)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8107492	GASKET KIT-CARB (1 required per assembly)
		810749 2 - Carburetor Gasket Kit [ More info ] $16.29 6 In Stock.
		18-7213 - Carburetor Kit, 810749-2 [ More info ] $11.46 10+ In Stock.
		1300-36007 - Mercury Mariner V6 Carburetor Kit [ More info ] $10.49 $8.91 1 In Stock.
#-	8116912	REPAIR KIT-CARB (1 required per assembly)
		1395-811691 2 - Carburetor Repair Kit [ More info ] $141.99 Available to Order: Shipping delay up to 10 days.
		18-7355 - Carburetor Kit, 1395-8116912 [ More info ] $109.59 $99.99 10+ In Stock.
#-	815791A92	GASKET SET (1 required per assembly)
		27-815791A92 - Engine Gasket Set [ More info ] $212.47 1 In Stock.
		27-27673 - Gasket Set [ More info ] $164.99 $126.17 1 In Stock.
#1	818650A28	CARBURETOR 135 - WMH-30 (1 required per assembly)
		3311-818650A28 - Carburetor [ More info ] Unavailable
#1	818650A29	CARBURETOR 135 - WMH-30 (1 required per assembly)
		3311-818650A29 - Carburetor, NLA [ More info ] Unavailable
#1	818650A55	CARBURETOR BOTTOM (30A) 135 - WMH-30 (1 required per assembly)
		3311-818650A55 - Carburetor Kit,NLA [ More info ] Unavailable
#1	818650A31	CARBURETOR 150 - WMH-31 (1 required per assembly)
		3311-818650A31 - Carburetor, NLA [ More info ] Unavailable
#1	818650A32	CARBURETOR 150 - WMH-31 (1 required per assembly)
		3311-818650A32 - Carburetor [ More info ] Unavailable
#1	818650A56	CARBURETOR BOTTOM (31A) 150 - WMH-31 (1 required per assembly)
		3311-818650A56 - Carburetor [ More info ] Unavailable
#1	818650A34	CARBURETOR TRACKER/XR6/MAGNUM III-WMH-32 (1 required per assembly)
		3311-818650A34 - Carburetor, NLA [ More info ] $90.00 $76.23 3 In Stock.
#1	818650A35	CARBURETOR TRACKER/XR6/MAGNUM III-WMH-32 (1 required per assembly)
		3311-818650A35 - Carburetor, NLA [ More info ] $90.00 $76.23 6 In Stock.
#1	818650A57	CARBURETOR BOTTOM (32A) TRACKER/XR6/MAGNUM III-WMH-32 (1 required per assembly)
		3311-818650A57 - Carburetor Kit,NLA [ More info ] Unavailable
#1	818650A37	CARBURETOR 175 - WMH-33 (1 required per assembly)
		3311-818650A37 - Carburetor [ More info ] Unavailable
#1	818650A38	CARBURETOR 175 - WMH-33 (1 required per assembly)
		3311-818650A38 - Carburetor [ More info ] Unavailable
#1	818650A58	CARBURETOR BOTTOM (33A) 175 - WMH-33 (1 required per assembly)
		3311-818650A58 - Carburetor Kit,NLA [ More info ] Unavailable
#1	818650A52	CARBURETOR 200 - WMH-34 (1 required per assembly)
		3311-818650A52 - Carburetor [ More info ] Unavailable
#1	818650A53	CARBURETOR 200 - WMH-34 (1 required per assembly)
		3311-818650A53 - Carburetor [ More info ] Unavailable
#1	818650A59	CARBURETOR BOTTOM (34A) 200 - WMH-34 (1 required per assembly)
		3311-818650A59 - Carburetor Kit,NLA [ More info ] Unavailable
#2	810779	CAP (6 required per assembly)
		810779 - Limiter Cap [ More info ] Unavailable
#3	NSS	NOT SOLD SEPARATE IDLE MIXTURE SCREW/SPRING (6 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#5	677511	GASKET (3 required per assembly)
		27-67751 1 - Gasket - Priced Individually [ More info ] $1.99 4 In Stock.
#6	815633060	JET (.060) (.056 - 135) (6 required per assembly)
		815633060 - Jet -.060, NLA [ More info ] $5.99 $5.07 4 In Stock.
#6	7570	JET .040 (XR6/MAGNUM III) (6 required per assembly)
		1399-7570 - Jet -.040 [ More info ] $17.23 10+ In Stock.
#6	815633050	JET (.050) (150/175/200) (6 required per assembly)
		815633050 - Jet -.050 [ More info ] $7.00 10 In Stock.
#7	810721	LEVER THROTTLE (TOP/CENTER) (2 required per assembly)
		810721 - Throttle Lever [ More info ] Unavailable
#7	810722	LEVER THROTTLE (BOTTOM - WMH-SERIES) (1 required per assembly)
		810722 - LEVER-THROTTLE,NLA [ More info ] Unavailable
#7	8107221	LEVER THROTTLE (BOTTOM - WMH-A SERIES) (1 required per assembly)
		810722 1 - LEVER-THROTTLE,NLA [ More info ] Unavailable
#8	811284	SPACER (3 required per assembly)
		1395-811284 - Spacer, NLA [ More info ] $2.50 $2.13 10+ In Stock.
#9	810745	WASHER (3 required per assembly)
		12-810745 - WASHER,NLA [ More info ] Unavailable
#10	810744	NUT (3 required per assembly)
		11-810744 - NUT,NLA [ More info ] Unavailable
#11	NSS	NOT SOLD SEPARATE SPRING (3 required per assembly)
#12	5815	JET (.086) (150) (3 required per assembly)
		1395-5815 - Jet -.086 [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#12	6247	JET MAIN (.090) (XR6/MAGNUM III) (3 required per assembly)
		1395-6247 - Jet -.090 [ More info ] $15.49 4 In Stock.
#12	3517	JET (.084) (135/175/200) (3 required per assembly)
		1399-3517 - Jet -.084 [ More info ] $4.09 2 In Stock.
#13	5225	JET MAIN (.054) (135) (3 required per assembly)
		1399-5225 - Jet -.054 [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#13	6359	JET (.052) (150) (3 required per assembly)
		1395-6359 - Jet -.052 [ More info ] $4.09 5 In Stock.
#13	6246	JET (.048) (175) (3 required per assembly)
		1395-6246 - Jet -.048 [ More info ] $18.69 10+ In Stock.
#13	7831	JET MAIN FUEL (.058) (XR6/MAGNUM III) (3 required per assembly)
		1395-7831 - Jet -.058 [ More info ] $17.39 Available to Order: Shipping delay up to 10 days.
#13	5317	JET (.046) (200) (3 required per assembly)
		1399-5317 - Jet -.046 [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#14	NSS	NOT SOLD SEPARATE GASKET-FUEL BOWL (3 required per assembly)
#15	810738	FLOAT ASSEMBLY (3 required per assembly)
		810738 - Float Assembly [ More info ] $23.99 $22.96 10+ In Stock.
#16	F10064	SHAFT (3 required per assembly)
		F10064 - Float Support Shaft [ More info ] $4.59 10+ In Stock.
#17	NSS	NOT SOLD SEPARATE SCREW-FLOAT (3 required per assembly)
#18	8116901	VALVE SEAT KIT (3 required per assembly) — Replaces: 811690
		1395-811690 1 - Valve Seat Kit [ More info ] $32.89 5 In Stock.
#19	NSS	NOT SOLD SEPARATE GASKET-VALVE SEAT (3 required per assembly)
#20	823623	BOWL FUEL (TOP) (1 required per assembly)
		1395-823623 - Fuel Bowl, NLA [ More info ] Unavailable
#20	823624	BOWL FUEL (CENTER/BOTTOM) (2 required per assembly)
		1395-823624 - BOWL-FUEL,NLA [ More info ] Unavailable
#21	95961	PLUG BOWL DRAIN (15 required per assembly) — Replaces: 9596
		95961 - PLUG Bowl Drain NLA [ More info ] Unavailable
#22	NSS	NOT SOLD SEPARATE GASKET-POWER/PROGRESSION JET (AR required per assembly)
#23	4215	JET MAIN FUEL (.066) (200 - TOP) (2 required per assembly)
		1399-4215 - Jet -.066 [ More info ] $17.19 Available to Order: Shipping delay up to 10 days.
#23	4217	JET MAIN (.062) (150/XR6/MAGNUM III) (6 required per assembly)
		1399-4217 - Jet -.062 [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#23	4216	JET (.064) (200 - CENTER/BOTTOM) (4 required per assembly)
		1399-4216 - Jet -.064 [ More info ] $4.09 2 In Stock.
#24	808584	POWER JET (6 required per assembly)
		1395-808584 - Jet, NLA [ More info ] $11.99 $10.15 10+ In Stock.
#25	808612	SCREW AND WASHER (#8-32 X .750) (18 required per assembly)
		1395-808612 - Screw & Washer [ More info ] $2.69 10+ In Stock.
#26	7900	TEE FITTING (TOP/CENTER) (2 required per assembly)
		1395-7900 - Fitting -t [ More info ] $29.99 $25.39 1 In Stock.
#27	7901	ELBOW (BOTTOM) (1 required per assembly)
		1395-7901 - Elbow Fitting [ More info ] $43.49 Available to Order: Shipping delay up to 10 days.
