Parts for Mercury 90 (Powerhead - Oil Injection) Pinion & Impeller Shaft (Threaded Drive)

Revise Search: Mercury Jet Drive & SportJet > 90 (Powerhead - Oil Injection) > 1994 0E066620 - 0E095087 - USA > Pinion & Impeller Shaft (Threaded Drive)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Pinion & Impeller Shaft (Threaded Drive)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	820240A2	COVER ASSY PINION SHAFT (Painted) (1 required per assembly) — Replaces: 820240A1
		820240A 2 - Cover, NLA [ More info ] Unavailable
#2	820295	SEAL COVER (2 required per assembly)
		26-820295 - Seal, NLA [ More info ] $27.76 $23.52 10+ In Stock.
#3	4010725	SCREW (4 required per assembly)
		10-40107 25 - Screw [ More info ] $5.79 Available to Order: Shipping delay up to 10 days.
#4	8203242	GASKET PINION SHAFT COVER (1 required per assembly)
		27-820324 2 - Gasket [ More info ] Unavailable
#5	820239A5	HOUSING KIT PINION SHAFT (Painted) (1 required per assembly) — Replaces: 820239A3
		1100-820239A 5 - Housing Kit,NLA [ More info ] Unavailable
#6	59628	BEARING BALL (1 required per assembly)
		30-59628 - Ball Bearing, NLA [ More info ] $62.50 $52.95 9 In Stock.
#7	8M0103473	BEARING ASSEMBLY TAPERED ROLLER (Cup And Cone) (1 required per assembly) — Replaces: 86748A1
		31-8M0103473 - Upper Drive Shaft Bearing BRVZZ [ More info ] $53.99 In Stock
#8	54030	O-RING (2.987 X .103) (1 required per assembly)
		25-54030 - O-ring, (2.987 X .103) [ More info ] $5.89 Available to Order: Shipping delay up to 10 days.
#9	820327020	SHIM YELLOW (.020) (AR required per assembly)
		15-820327020 - Shim -.020-Yellow, NLA [ More info ] $6.00 $5.08 10+ In Stock.
#9	820327010	SHIM BROWN (.010) (AR required per assembly)
		15-820327010 - Shim -.010-Brown, NLA [ More info ] $7.02 10+ In Stock.
#9	820327007	SHIM FROST (.0075) (AR required per assembly)
		15-820327007 - Shim -.0075-Frost, NLA [ More info ] $7.19 10+ In Stock.
#9	820327005	SHIM BLUE (.005) (AR required per assembly)
		15-820327005 - Shim -.005-Blue, NLA [ More info ] $7.25 $6.14 10+ In Stock.
#9	820327004	SHIM BEIGE (.004) (AR required per assembly)
		15-820327004 - Shim -.004-Beige, NLA [ More info ] $6.67 $5.65 10+ In Stock.
#9	820327002	SHIM RED (.002) (AR required per assembly)
		15-820327002 - Shim -.002-RED, NLA [ More info ] $7.19 10+ In Stock.
#10	820246	SHAFT PINION (1 required per assembly)
		45-820246 - Pinion Shaft, NLA [ More info ] $155.54 $131.75 3 In Stock.
#11	820248	GEAR PINION (1 required per assembly)
		43-820248 - Gear-Pinion, NLA [ More info ] $120.72 10+ In Stock.
#12	820335	WASHER (1 required per assembly)
		12-820335 - Washer, NLA [ More info ] Unavailable
#13	818591	NUT (1 required per assembly)
		11-818591 - Nut (M14) [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#14	820241A3	COVER ASSEMBLY IMPELLER SHAFT (Painted) (1 required per assembly) — Replaces: 820241A2
		820241A 3 - Cover Assembly [ More info ] $75.46 1 In Stock.
#15	8M0103473	BEARING ASSEMBLY TAPERED ROLLER (Cup And Cone) (1 required per assembly) — Replaces: 86748A1
#16	62700	O-RING (3.237 X .103) (1 required per assembly)
		25-62700 - O-Ring [ More info ] $3.99 1 In Stock.
		18-0860-9 - O-Ring 25-62700 2-Pack [ More info ] $7.29 Available to Order: Shipping delay up to 10 days.
#17	820321020	SHIM YELLOW (.020) (AR required per assembly)
		15-820321020 - Shim -.020-Yellow, NLA [ More info ] $6.00 $5.08 10+ In Stock.
#17	820321010	SHIM BROWN (.010) (AR required per assembly)
		15-820321010 - Shim -.010-Brown, NLA [ More info ] $7.02 10+ In Stock.
#17	820321007	SHIM FROST (.0075) (AR required per assembly)
		15-820321007 - Shim -.0075-Frost, NLA [ More info ] $10.31 $8.73 10+ In Stock.
#17	820321005	SHIM BLUE (.005) (AR required per assembly)
		15-820321005 - Shim -.005-Blue, NLA [ More info ] $7.61 $6.45 10+ In Stock.
#17	820321004	SHIM BEIGE (.004) (AR required per assembly)
		15-820321004 - Shim -.004-Beige, NLA [ More info ] $6.00 $5.08 10+ In Stock.
#17	820321002	SHIM RED (.002) (AR required per assembly)
		15-820321002 - Shim -.002-RED, NLA [ More info ] $6.00 $5.08 10+ In Stock.
#18	4010725	SCREW (4 required per assembly)
#19	818591	NUT (1 required per assembly)
#20	820335	WASHER (1 required per assembly)
#21	820249T	GEAR-IMPELLER IMPELLER SHAFT (1 required per assembly) — Replaces: 820249
		43-820249T - Impeller Gear, NLA [ More info ] $90.55 2 In Stock.
#22	820247T	SHAFT-IMPELLER IMPELLER (THREADED) (1 required per assembly) — Replaces: 820247
		44-820247T - Impeller Shaft, NLA [ More info ] Unavailable
#--	820611A1	SEAL/GASKET SET DRIVE HOUSING (1 required per assembly)
		26-820611A 1 - Seal/Gasket Kit [ More info ] Unavailable
#--	820238A14	HOUSING KIT-COMP DRIVE (Complete) (Painted) (No Impeller) (1 required per assembly) — Replaces: 820238A4, 820238A5
		1500-820238A14 - Housing Kit-COMP,NLA [ More info ] Unavailable
