Parts for V-150 Magnum 2-Stroke Carbureted Mercury Outboard Motor Choke Plate & Throttle Levers

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > V-150 Magnum > 5600162 - 0A904645 > Choke Plate & Throttle Levers

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Choke Plate & Throttle Levers

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	90484A88	GASKET SET [ME-6042946/MA-6038681] & Up (1 required per assembly)
		27-90484A88 - Gasket Set [ More info ] Unavailable
#-	79583A81	GASKET SET [5866777] THRU [6042945] (1 required per assembly)
		27-79583A81 - Engine Gasket Set [ More info ] Unavailable
#-	NLA	NO LONGER AVAILABLE GASKET SET (Service Bulletin 81-8) [ME-5866776/MA-6038680] & Below (1 required per assembly)
		NLA - No Longer Availab [ More info ] Unavailable
#1	67245T	BRACKET COWL MOUNTING - UPPER (1 required per assembly)
		67245T - Bracket, NLA [ More info ] $9.70 3 In Stock.
#2	67272	GROMMET (2 required per assembly)
		25-67272 - Grommet, NLA [ More info ] Unavailable
#3	90435	MOUNT (2 required per assembly)
		90435 - Rubber Mount [ More info ] $61.44 1 In Stock.
#4	21249	WASHER @5 (4 required per assembly)
		12-21249 - Washer - Priced Individually [ More info ] $8.49 $1.70 10+ In Stock.
#5	8267089	NUT @5 (4 required per assembly) — Replaces: 20361
		11-826708 9 - Nut - Priced Individually [ More info ] $1.50 10 In Stock.
		18-3722-9 - Lock Nut, 121731, 11-35888, Pack of 5 [ More info ] $11.99 $8.16 Available to Order: Shipping delay up to 10 days.
#6	87076A4	STABILIZER ASSY (1 required per assembly)
		87076A 4 - Stabilizer Assembly [ More info ] Unavailable
#7	799831	CHOKE PLATE [6616991] & Up (1 required per assembly)
		79983 1 - Choke Plate, NLA [ More info ] Unavailable
#7	99390A4	CHOKE PLATE ASSY [6616990] & Below (1 required per assembly)
		99390A 4 - CHOKE PLATE,NLA [ More info ] Unavailable
#8	672741	GASKET (1 required per assembly)
		27-67274 1 - Gasket [ More info ] Unavailable
#9	68000	SCREW @2 (6 required per assembly)
		10-68000 - Screw, NLA [ More info ] $2.14 10+ In Stock.
#10	20583	WASHER @5 (6 required per assembly)
		12-20583 - Washer - Priced Individually [ More info ] $1.50 10+ In Stock.
#11	672751	GASKET (1 required per assembly)
		27-67275 1 - Gasket [ More info ] $15.69 1 In Stock.
#12	67246T	COVER (1 required per assembly)
		67246T - Induction Silencer Cover [ More info ] Unavailable
#13	98255	SCREW [ME-6443213/MA-6443818] & Up (2 required per assembly)
		10-98255 - Screw, NLA [ More info ] $1.50 $1.28 1 In Stock.
#14	69056	WASHER (2 required per assembly) — Replaces: 21631
		12-69056 - Washer, (.255 X .620 X .030) Stainless Steel [ More info ] $1.80 2 In Stock.
#15	26992	LOCKWASHER @5 (2 required per assembly)
		13-26992 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#16	90585	PLUG (1 required per assembly)
		19-90585 - Plug [ More info ] $20.04 10+ In Stock.
#17	67760	LINK (1 required per assembly)
		67760 - Link, NLA [ More info ] Unavailable
#18	67759	LEVER (UPPER)(OIL INJECTION) (1 required per assembly)
		67759 - Throttle Lever [ More info ] $26.93 10+ In Stock.
#19	41049	LEVER (CENTER)(OIL INJECTION) (1 required per assembly)
		41049 - Throttle Lever [ More info ] $47.42 10+ In Stock.
#20	67749	LEVER THROTTLE LOWER (1 required per assembly)
		67749 - Throttle Lever [ More info ] Unavailable
#21	15124	SCREW (#10-32 X .750) (3/4&QUOT;) (3 required per assembly) — Replaces: 92501
		10-15124 - Screw [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
#22	26996	LOCKWASHER @15 (3 required per assembly)
		13-26996 - LockWasher - Priced Individually [ More info ] $1.20 Available to Order: Shipping delay up to 10 days.
#23	24676	WASHER (3 required per assembly)
		12-24676 - Washer, (.200 X .440 X .032) [ More info ] $1.50 10+ In Stock.
#24	67297	PIN-CLEVIS (3 required per assembly)
		17-67297 - Clevis Pin [ More info ] $12.19 Available to Order: Shipping delay up to 10 days.
#25	89302	WASHER @5 (3 required per assembly) — Replaces: 27736
		12-89302 - Washer (.203 X .406 X .040) [ More info ] $1.80 10+ In Stock.
#26	26953	PIN-COTTER @5 (3 required per assembly)
		18-26953 - Cotter Pin - Priced Individually [ More info ] $4.19 9 In Stock.
#27	67748	ROLLER (1 required per assembly)
		67748 - Roller [ More info ] $6.99 8 In Stock.
#28	26001	NUT [ME-6443212/MA-6443817] & Below (2 required per assembly)
		11-26001 - Nut, NLA Z [ More info ] $11.79 $9.44 6 In Stock.
#29	54293A10	SOLENOID ASSY [USA-5503246/AUS-8062734] & Below (1 required per assembly)
		54293A10 - Choke Solenoid, NLA [ More info ] Unavailable
		SW926 - Solenoid, 54293A13 [ More info ] $72.50 $71.61 In Stock
#30	39349	SCREW @5 [USA-5503246/AUS-8062734] & Below (2 required per assembly)
		10-39349 - Screw - Priced Individually [ More info ] $1.80 $1.44 10+ In Stock.
#31	8M0204647	LOCKWASHER @5 [USA-5503246/AUS-8062734] & Below (2 required per assembly) — Replaces: 26993
		138M0204647 - LOCKWASHER, Priced Individually [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#32	26996	LOCKWASHER @15 [USA-5503246/AUS-8062734] & Below (1 required per assembly)
#33	68219	NUT @5 [USA-5503246/AUS-8062734] & Below (1 required per assembly)
		11-68219 - Nut (#10-32) [ More info ] $2.99 10+ In Stock.
#34	56074A11	PLUNGER ASSY [USA-5503246/AUS-8062734] & Below (1 required per assembly)
		56074A11 - Plunger Assembly, NLA [ More info ] Unavailable
#35	89041	RETAINER [USA-5503246/AUS-8062734] & Below (3 required per assembly)
		89041 - Retainer, NLA [ More info ] Unavailable
#36	48408	SCREW @5 [USA-5503246/AUS-8062734] & Below (3 required per assembly)
		10-48408 - Screw - Priced Individually [ More info ] $2.29 Available to Order: Shipping delay up to 10 days.
#37	73861A1	SHAFT ASSY [USA-5503246/AUS-8062734] & Below (3 required per assembly)
		73861A 1 - Shaft Assembly, NLA [ More info ] $8.00 $6.78 7 In Stock.
#38	76040	CHOKE SHUTTER [USA-5503246/AUS-8062734] & Below (6 required per assembly)
		76040 - Choke Shutter [ More info ] $7.00 $5.93 10 In Stock.
#39	75898	SCREW [USA-5503246/AUS-8062734] & Below (12 required per assembly)
		10-75898 - SCREW,NLA [ More info ] Unavailable
#40	90401	LEVER [USA-5503246/AUS-8062734] & Below (3 required per assembly)
		90401 - Lever [ More info ] $2.50 $2.13 9 In Stock.
#41	88578	SPRING [USA-5503246/AUS-8062734] & Below (3 required per assembly)
		24-88578 - Spring, NLA [ More info ] $1.88 $1.59 10+ In Stock.
#42	73860	CHOKE ROD [USA-5503246/AUS-8062734] & Below (1 required per assembly)
		73860 - Choke Rod, NLA [ More info ] $4.83 $4.10 1 In Stock.
#43	67273	O RING @3 [USA-5503246/AUS-8062734] & Below (2 required per assembly)
		25-67273 - O-Ring - Priced Individually [ More info ] $2.09 $1.77 6 In Stock.
#44	67247	CHOKE KNOB [USA-5503246/AUS-8062734] & Below (1 required per assembly)
		67247 - Choke Knob, NLA [ More info ] $13.32 2 In Stock.
#45	67262	SCREW [USA-5503246/AUS-8062734] & Below (1 required per assembly)
		10-67262 - Screw, NLA [ More info ] $3.88 $3.28 3 In Stock.
#46	67249	CHOKE ROD [USA-5503246/AUS-8062734] & Below (1 required per assembly)
		67249 - CHOKE ROD,NLA [ More info ] Unavailable
#47	88522	SPRING [USA-5503246/AUS-8062734] & Below (1 required per assembly)
		24-88522 - Spring, NLA [ More info ] $5.39 1 In Stock.
#13A	33071	STUD [ME-6443212/MA-6443817] & Below (2 required per assembly)
		16-33071 - Stud, NLA [ More info ] Unavailable
