Parts for V-135 2-Stroke Carbureted Mercury Outboard Motor Reed Block & Cylinder Head

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > V-135 > 0A904646 - 0C100860 - USA > Reed Block & Cylinder Head

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Reed Block & Cylinder Head

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	90484A88	GASKET SET ( required per assembly)
		27-90484A88 - Gasket Set [ More info ] Unavailable
#1	96423T	CYLINDER HEAD (2 PIECE DESIGN) (2 required per assembly) — Replaces: 96423
		96423T - Cylinder Head [ More info ] $357.75 Available to Order: Shipping delay up to 10 days.
#2	96278	GASKET CYLINDER COVER - (2 PIECE DESIGN) (2 required per assembly)
		27-96278 - Cylinder Cover Gasket [ More info ] $6.79 Available to Order: Shipping delay up to 10 days.
		18-2808-9 - Gasket 27-96278 2-Pack [ More info ] $28.04 Available to Order: Shipping delay up to 10 days.
#3	96283	COVER CYLINDER - (2 PIECE DESIGN) (2 required per assembly) — Replaces: 96283T
		96283 - Cover, NLA [ More info ] Unavailable
#4	74824	SCREW (.312-18 X 1.250) CYLINDER COVER - (2 PIECE DESIGN) (40 required per assembly)
		10-74824 - Screw - Priced Individually [ More info ] $1.80 3 In Stock.
#5	184196	CYLINDER HEAD (1 PIECE DESIGN) (2 required per assembly) — Replaces: 184191, 184192
		18419 6 - Cylinder Head [ More info ] Unavailable
		18419 7 - Cylinder Head [ More info ] Unavailable
		18419F 1 - Cylinder Head [ More info ] $239.00 $202.43 3 In Stock.
#6	96281T01	GASKET CYLINDER HEAD (2 required per assembly) — Replaces: 96542, 965421
		27-96281T01 - Head Gasket [ More info ] $69.49 Available to Order: Shipping delay up to 10 days.
		18-3863 - Head Gasket 27-96542-1 [ More info ] $48.49 2 In Stock.
#7	98534	SCREW (.375-16 X 2.30) CYLINDER HEAD (24 required per assembly)
		10-98534 - Screw [ More info ] Unavailable
#8	25909	WASHER (.406 X .812 X .065) CYLINDER HEAD SCREW (24 required per assembly)
		12-25909 - Washer (.406 X .812 X .065) [ More info ] $1.90 Available to Order: Shipping delay up to 10 days.
#9	8M0204714	GASKET @4 (2 required per assembly) — Replaces: 62386, 62386001
		27-8M0204714 - Thermostat Gasket, Priced Individually [ More info ] $2.89 10+ In Stock.
#10	90390A1	COVER KIT THERMOSTAT (2 required per assembly)
		90390A 1 - Thermostat Cover Kit [ More info ] $52.48 3 In Stock.
#11	815549	SCREW (.312-18 X 2.00) THERMOSTAT COVER (NOT USED W/REF. #5) (2 required per assembly) — Replaces: 77065
		10-815549 - Screw [ More info ] $5.39 $4.32 3 In Stock.
#11	35386	SCREW (.312-18 X 1.00) THERMOSTAT COVER (QTY OF 4 W/REF.#5) (2 required per assembly)
		10-35386 - Screw - Priced Individually [ More info ] $1.10 7 In Stock.
#12	687271	FITTING (.250-18) 90 DEGREE - BRASS ELBOW - WATER HOSES (1 required per assembly) — Replaces: 68727
		22-68727 1 - Fitting [ More info ] $32.68 1 In Stock.
#13	77653101	HOSE (48.00 INCHES BULK) WATER DISTRIBUTION (2 required per assembly) — Replaces: 7765377, 7765378
		32-77653101 - Hose -48 Inch [ More info ] $61.99 Available to Order: Shipping delay up to 10 days.
#14	68728	FITTING THE THERMOSTAT COVER TO WATER HOSES (1 required per assembly)
		22-68728 - Fitting [ More info ] Unavailable
#15	816311	TIE STRAP (8.00 INCHES) WATER HOSES (4 required per assembly) — Replaces: 73498, 90077
		54-816311 - TIE STRAP Note: Priced Individually [ More info ] Unavailable
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 10+ In Stock.
#16	97465	SENDER TEMPERATURE (STARBOARD) (1 required per assembly)
		97465 - Temperature Sender [ More info ] $117.49 Available to Order: Shipping delay up to 10 days.
#17	96282	COVER TEMPERATURE SENDER (NOT USED W/REF. #5) (1 required per assembly)
		96282 - Cover, NLA [ More info ] Unavailable
#20	99747A2	HOUSING REED BLOCK (USE W/OLD DESIGN FUEL PUMP) (1 required per assembly)
		99747A 2 - Housing, NLA [ More info ] Unavailable
#20	99747A9	HOUSING REED BLOCK (USE W/SQUARE FUEL PUMP) (1 required per assembly)
		99747A 9 - REED BLOCK HSG,NLA [ More info ] Unavailable
#21	24878	SCREW (.250-20 X 1.25) REED BLOCK HOUSING (1 required per assembly)
		10-24878 - Screw, NLA [ More info ] $1.80 10+ In Stock.
#21	69093	SCREW (.250-20 X 1.50) REED BLOCK HOUSING (8 required per assembly)
		10-69093 - Screw, NLA [ More info ] $1.91 10+ In Stock.
#21	69067	SCREW (.250-20 X 1.375) REED BLOCK HOUSING (1 required per assembly)
		10-69067 - Screw - Priced Individually [ More info ] $3.19 10+ In Stock.
#22	935361	GASKET REED BLOCK HOUSING (1 required per assembly) — Replaces: 93536
		27-93536 1 - Gasket - Priced Individually [ More info ] $12.39 $9.92 7 In Stock.
#23	657442	GASKET REED BLOCK (6 required per assembly) — Replaces: 65744, 657441
		27-65744 2 - Gasket Note: Priced Individually [ More info ] Unavailable
		27-65744 3 - Gasket [ More info ] $7.09 Available to Order: Shipping delay up to 10 days.
#24	75953	REED BLOCK (6 required per assembly)
		75953 - Reed Block [ More info ] $130.64 1 In Stock.
#25	75362A1	REED KIT (6 required per assembly)
		34-75362A 1 - Reed Kit [ More info ] Unavailable
#26	961832	CLAMP-REED (12 required per assembly) — Replaces: 96183
		96183 2 - Clamp - Reed [ More info ] $9.69 $7.76 10+ In Stock.
#27	57583T	SCREW #8-32X3/8 REEDS TO REED BLOCK (60 required per assembly) — Replaces: 57583
		10-57583T - Screw - Priced Individually [ More info ] $1.40 Available to Order: Shipping delay up to 10 days.
#28	65746	SCREW (.250-20 X .750) REED BLOCK ATTACHING (12 required per assembly)
		10-65746 - Screw w/ Lw - Priced Individually [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
#29	270372	STUD (.250-28 X 1.125) CARBURETOR MOUNTING (12 required per assembly) — Replaces: 27037
		16-27037 2 - Stud [ More info ] $4.29 Available to Order: Shipping delay up to 10 days.
#30	426585	CHECK VALVE BLEED HOSE TO REED BLOCK HOUSING (5 required per assembly) — Replaces: 42658, 426582
		21-42658 5 - Check Valve [ More info ] $25.59 Available to Order: Shipping delay up to 10 days.
#31	15133	FITTING BLEED HOSE TO CYLINDER BLOCK (90 DEGREES) (5 required per assembly)
		22-15133 - Fitting [ More info ] $21.19 Available to Order: Shipping delay up to 10 days.
#32	892024122	TUBING (240.00 INCHES BULK) BLEED LINE (1 required per assembly) — Replaces: 99130122
		32-892024122 - Tubing - 20 Feet [ More info ] $48.49 In Stock
#33	42657A3	VALVE ASSY-CHECK (1 required per assembly) — Replaces: 42657A1
		21-42657A 3 - Check Valve Assembly [ More info ] $7.29 Available to Order: Shipping delay up to 10 days.
#34	56759	FITTING BARBED BLEED HOSE (PRESS-IN) (1 required per assembly) — Replaces: 65857
		22-56759 - Fitting [ More info ] $11.59 Available to Order: Shipping delay up to 10 days.
#35	64871A2	VALVE ASSY-CHECK (1 required per assembly)
		21-64871A 2 - Check Valve Assembly, NLA [ More info ] $21.47 10+ In Stock.
#36	13536A7	SENSOR ASSY-TEMP (PORT) (BLACK/GRAY) USED WITH REF. #5 REF. #36 IS USED WITH ENGINE TEMP. GUAGE (PORT) SENDERS MOUNTED ON STBD. ARE WORKING FOR WARNING HORNS: PORT MOUNTED ARE FOR TEMP. GUAGE. (1 required per assembly)
		13536A 7 - Temperature Sensor Assembly [ More info ] $61.36 1 In Stock.
#37	137151	RETAINER (QTY. OF 1 W/OYSTER) USED WITH REF. #5 (2 required per assembly) — Replaces: 13715
		13715 1 - Retainer [ More info ] $4.29 Available to Order: Shipping delay up to 10 days.
#38	98257	SCREW (QTY. OF 1 W/OYSTER)(USED WITH REF. #5) (2 required per assembly)
		10-98257 - Screw [ More info ] $1.10 9 In Stock.
#39	187531	SENDER TEMPERATURE (OYSTER) (1 required per assembly)
		18753 1 - Temperature Sender, NLA [ More info ] Unavailable
#40	88824A8	CABLE ASSEMBLY TEMPERATURE SENDER - (OYSTER) (1 required per assembly)
		84-88824A 8 - Cable, NLA [ More info ] $8.00 $6.78 2 In Stock.
#41	75692	THERMOSTAT-143 (2 required per assembly)
		75692 - Thermostat, 147 Degrees [ More info ] $31.59 $26.99 10+ In Stock.
		18-3553 - Thermostat, 143 Degrees, 75692 [ More info ] $25.99 $23.96 6 In Stock.
		75-02658 - OMC Thermostat Kit, 5005440 (dual) [ More info ] $47.99 $43.31 Available to Order: Shipping delay up to 10 days.
		75-00456-IR - Thermostat Kit, 75692Q03,T2,Q2 [ More info ] $22.99 $20.63 In Stock
		75-00403 - Thermostat, 5005440 [ More info ] $23.99 $18.35 10+ In Stock.
