Nozzle / Rudder Components (Splined Drive)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	820326	WASHER THRUST (1 required per assembly)
		12-820326 - Washer, Thrust, NLA [ More info ] $7.61 $6.45 10+ In Stock.
#2	828029T	IMPELLER STAINLESS STEEL - 5 BLADE SPLINED (1 required per assembly) — Replaces: 820626, 820626T
		47-828029T - Impeller, Splined [ More info ] Unavailable
		47-828989T - Impeller, Splined [ More info ] Unavailable
		47-828989 - Impeller [ More info ] Unavailable
		47-828989T 1 - Impeller [ More info ] $484.66 Available to Order: Shipping delay up to 10 days.
#3	820243T1	RING WEAR (Painted) (1 required per assembly) — Replaces: 820243, 820243T
		820243T 1 - RING-WEAR [ More info ] Unavailable
		820243T 2 - Ring Kit - Wear [ More info ] $915.49 Available to Order: Shipping delay up to 10 days.
#4	201951	O RING (1 required per assembly) — Replaces: 20195
		25-20195 1 - O-Ring [ More info ] $1.99 Available to Order: Shipping delay up to 10 days.
		18-7134-9 - O-Ring (PK5) 339543 [ More info ] $10.47 Available to Order: Shipping delay up to 10 days.
#5	8M0180564	PLUG @5 (1 required per assembly) — Replaces: 73379
		22-8M0180564 - Plug, Sold Individually [ More info ] $7.59 3 In Stock.
#6	830035A1	STATOR KIT (Painted) (1 required per assembly) — Replaces: 820245A3, 820245A5
		300-830035A 1 - Stator Kit [ More info ] $324.99 $275.26 10+ In Stock.
#7	820430	BUSHING STATOR REAR (2 required per assembly)
		23-820430 - Bushing [ More info ] $19.19 Available to Order: Shipping delay up to 10 days.
#8	819396	SEAL CRANKSHAFT LOWER (2 required per assembly)
		26-819396 - Seal [ More info ] $11.49 4 In Stock.
#9	8M0180564	PLUG @5 (1 required per assembly) — Replaces: 73379
#10	79953A2	SCREW KIT (.375-16 X .250) (1 required per assembly) — Replaces: 28634A1, 79953
		10-79953A 2 - Drain Screw Kit [ More info ] Unavailable
		10-79953Q 2 - Screw Kit - Priced Individually [ More info ] Unavailable
		10-79953Q04 - Screw Kit - Priced Individually [ More info ] $7.49 9 In Stock.
		18-2244 - Plug Kit, 10-79953A2 [ More info ] $3.79 10+ In Stock.
		10-79953K04 - Drain Screw - Priced Individually [ More info ] $8.19 10+ In Stock.
#11	8M0204684	O RING (1 required per assembly) — Replaces: 805726
		25-8M0204684 - O-RING FILL/DRAIN SCREW [ More info ] $2.49 4 In Stock.
#12	75677	SCREW (2 required per assembly)
		10-75677 - Screw [ More info ] $1.60 8 In Stock.
#14	820599	TAB LOCKING (1 required per assembly)
		14-820599 - Tab Washer [ More info ] $4.07 $3.45 10+ In Stock.
#15	820531	BRACKET SHIFT (Painted) (1 required per assembly)
		820531 - Bracket, NLA [ More info ] $33.54 5 In Stock.
#16	8M0207776	NUT (1 required per assembly) — Replaces: 814101
		118M0207776 - NUT [ More info ] $7.09 Available to Order: Shipping delay up to 10 days.
#17	8200281	SWIVEL CABLE CLAMP (1 required per assembly)
		820028 1 - Swivel [ More info ] $79.99 Available to Order: Shipping delay up to 10 days.
#18	F405457	SCREW PIVOT (1 required per assembly)
		10-F405457 - Screw, NLA [ More info ] $8.39 10+ In Stock.
#19	F2217-1	SCREW-W/LW (2 required per assembly)
		10-F2217-1 - 10-F2217-1 - SCREW (10-24 x .3 [ More info ] Unavailable Replaced by 10-F2217-1
#20	846341	BRACKET CABLE (1 required per assembly)
		54-846341 - Bracket - Cable [ More info ] $12.59 10+ In Stock.
#21	8M0012503	SCREW (4 required per assembly) — Replaces: 40108100
		10-8M0012503 - Screw [ More info ] $12.99 Available to Order: Shipping delay up to 10 days.
#22	820469T1	NOZZLE (Painted) (1 required per assembly) — Replaces: 820469, 820469T
		820469T 1 - Nozzle [ More info ] Unavailable
		820469A 1 - Nozzle Assembly [ More info ] Unavailable
		830052A 1 - Nozzle Assembly [ More info ] $99.99 $84.68 4 In Stock.
#23	828913T	ANODE (1 required per assembly) — Replaces: 820444T, 820444T1
		828913T - Anode [ More info ] Unavailable
#24	4010835	SCREW (2 required per assembly)
		10-40108 35 - Screw [ More info ] $7.29 Available to Order: Shipping delay up to 10 days.
#25	828909A1	RUDDER KIT (Painted) (1 required per assembly) — Replaces: 820343A3, 820343A4
		828909A 1 - Rudder Kit, NLA [ More info ] Unavailable
#26	825158	BUSHING PIVOT (2 required per assembly) — Replaces: 820289
		23-825158 - Bushing [ More info ] Unavailable
#27	8205031	ANODE (1 required per assembly)
		978205031 - Anode [ More info ] $11.89 Available to Order: Shipping delay up to 10 days.
#28	824830	SCREW (M6 X 13) (1 required per assembly)
		10-824830 - Screw [ More info ] $6.89 10 In Stock.
#29	93702	WASHER (.250 EXTERNAL STAR) (1 required per assembly)
		13-93702 - LockWasher - Priced Individually [ More info ] $2.37 8 In Stock.
#30	820336	BOLT PIVOT (4 required per assembly)
		820336 - Bolt [ More info ] $25.59 Available to Order: Shipping delay up to 10 days.
#31	4010725	SCREW (3 required per assembly)
		10-40107 25 - Screw [ More info ] $5.79 Available to Order: Shipping delay up to 10 days.
#32	828909A1	RUDDER KIT STEERING (Painted) (1 required per assembly) — Replaces: 820462, 820462T
#33	828914A1	GATE ASSY (Painted) (1 required per assembly) — Replaces: 820483A2
		828914A 1 - Gate Assembly [ More info ] Unavailable
#34	825158	BUSHING (2 required per assembly) — Replaces: 820289
#35	824467	PIN CLEVIS (1 required per assembly)
		17-824467 - Clevis Pin [ More info ] $2.70 10+ In Stock.
#36	8M0204649	WASHER @10 (1 required per assembly) — Replaces: 29245
		12-8M0204649 - WASHER Note: Priced Individually [ More info ] $1.20 10+ In Stock.
#37	210711	COTTER PIN (1 required per assembly) — Replaces: 21071
		0210711 [ More info ] Unavailable Replaced by 0210710
		[ More info ] Unavailable
#38	8205031	ANODE (1 required per assembly)
#39	824830	SCREW (M6 X 13) (1 required per assembly)
#40	93702	WASHER (.250 EXTERNAL STAR) (1 required per assembly)
#44	820564	STOP REVERSE GATE (2 required per assembly)
		820564 - Stop [ More info ] $37.04 4 In Stock.
#45	36001	WASHER @3 (2 required per assembly)
		12-36001 - Washer - Priced Individually [ More info ] $1.50 10+ In Stock.
		18-4270 - Washer 12-36001 [ More info ] $1.25 $0.91 2 In Stock.
#46	4007154	SCREW (2 required per assembly)
		10-40071 54 - Screw [ More info ] $3.04 $0.88 5 In Stock.
#47	4010845	SCREW (2 required per assembly)
		10-40108 45 - Screw [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#48	820601	TAB LOCKING BOLT (1 required per assembly)
		14-820601 - Tab Washer, NLA [ More info ] $3.06 $2.59 10+ In Stock.
#49	820509	WASHER IMPELLER SHAFT (1 required per assembly)
		14-820509 - Tab Washer, NLA [ More info ] $11.70 10+ In Stock.
#50	820508	NUT IMPELLER SHAFT (1 required per assembly)
		11-820508 - Nut-impeller Shaft,NLA [ More info ] $14.31 10+ In Stock.
#--	820611A2	SEAL/GASKET SET DRIVE HOUSING (1 required per assembly)
		26-820611A 2 - Seal/Gasket Kit [ More info ] Unavailable
#--	820238A8	HOUSING KIT DRIVE (Complete) (Painted) (No Impeller) (1 required per assembly)
		1500-820238A 8 - Housing Kit-COMP,NLA [ More info ] Unavailable
