Parts for Sst 120 2-Stroke Carbureted Mercury Outboard Motor Swivel Bracket Assembly
Tap to zoom. Scroll down to order.
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 11167A1 | O-RING KIT (1 required per assembly) |
  |
|
25-11167A 1 - Swivel Bracket Ki [ More info ]
|
| #1 | 8M0050234 | SWIVEL BRKT ASSY (COMPLETE) (1 required per assembly) — Replaces: 821921A15 |
  |
|
3405-8M0050234 - Swivel Bracket Assembly [ More info ] Unavailable |
| #2 | 822043 | ROD (1 required per assembly) |
  |
|
|
| #3 | NSS | NOT SOLD SEPARATE QUAD RING (1 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #4 | NSS | NOT SOLD SEPARATE QUAD RING (2 required per assembly) |
| #5 | NSS | NOT SOLD SEPARATE O-RING (1 required per assembly) |
| #6 | NSS | NOT SOLD SEPARATE SCRAPER (2 required per assembly) |
| #7 | 79869 | WASHER (2 required per assembly) |
  |
|
12-79869 - Washer [ More info ] Unavailable |
| #8 | 798701 | RING RETAINING (2 required per assembly) |
  |
|
53-79870 1 - Ring - Retaining [ More info ] Unavailable |
| #9 | NSS | NOT SOLD SEPARATE ROD GUIDE (1 required per assembly) |
| #10 | 86843 | SCREW (#10-24 X .500) (4 required per assembly) |
  |
|
10-86843 - Screw [ More info ]
|
| #11 | 441321 | WEAR PAD (PORT) (1 required per assembly) |
  |
|
44132 1 - Wear Pad [ More info ] Unavailable |
| #11 | 441322 | WEAR PAD (STARBOARD) (1 required per assembly) |
  |
|
44132 2 - Wear Pad [ More info ] Unavailable |
| #12 | 822037 | SCREW (2 required per assembly) |
  |
|
10-822037 - Screw [ More info ] Unavailable |
| #13 | 848691 | PLATE (1 required per assembly) |
  |
|
|
