Parts for 9.9 2-Stroke Carbureted Mercury Outboard Motor Manual Starter (Design I)

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > 9.9 > 9461526 - 9792199 - Belgium > Manual Starter (Design I)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Manual Starter (Design I)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	42207A1	HOUSING ASSEMBLY STARTER (1 required per assembly)
		42207A 1 - Housing,NLA [ More info ] Unavailable
#2	8M0183792	ROPE BUSHING STARTER ROPE (1 required per assembly) — Replaces: 42690
		8M0183792 - ROPE BUSHING [ More info ] Unavailable
#3	818853	RING RETAINING (1 required per assembly) — Replaces: 42689
		53-818853 - Ring - Retaining [ More info ] $1.80 1 In Stock.
#4	42194A2	SPRING ASSEMBLY RECOIL STARTER (1 required per assembly)
		42194A 2 - Spring Assembly, NLA [ More info ] Unavailable
#6	42171T	LEVER LOCK (UPPER) (1 required per assembly) — Replaces: 42171
		42171T - Lever [ More info ] $16.69 Available to Order: Shipping delay up to 10 days.
#7	8M0204666	WASHER @5 UPPER LOCK LEVER (1 required per assembly) — Replaces: 56681
		128M0204666 - WASHER Note: Priced Individually [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#8	42173T	LEVER LOCK (LOWER) (1 required per assembly) — Replaces: 42173
		42173T - Lever [ More info ] $5.69 Available to Order: Shipping delay up to 10 days.
#9	48408	SCREW (#10-16 X .500) LOWER LOCK LEVER (1 required per assembly)
		10-48408 - Screw - Priced Individually [ More info ] $2.29 Available to Order: Shipping delay up to 10 days.
#10	43787	SPACER STARTER HOUSING SCREW (3 required per assembly)
		23-43787 - SPACER,NLA [ More info ] $1.25 $1.06 1 In Stock.
#11	8M0204741	SCREW @4 STARTER HOUSING ATTACHING (3 required per assembly) — Replaces: 40011128, 8M4503518
		108M0204741 - SCREW Note: Priced Individually [ More info ] $4.59 Available to Order: Shipping delay up to 10 days.
#12	19018T	REST-STARTER HDL (ROPE BUSHING IS MOLDED) (1 required per assembly) — Replaces: 42094, 19018
		19018T - Rest - Starter Handle [ More info ] $28.09 Available to Order: Shipping delay up to 10 days.
#13	44180	BUSHING (ROPE BUSHING IS SEPARATE) (1 required per assembly)
		44180 - Rope Bushing [ More info ] $15.39 Available to Order: Shipping delay up to 10 days.
#14	4002313	WASHER REST SCREW (ROPE BUSHING IS SEPARATE) (2 required per assembly)
		12-40023 13 - Washer, Rest Screw [ More info ] $19.09 $4.58 10 In Stock.
#15	12674	SUPPORT (1 required per assembly)
		12674 - Support [ More info ] $9.69 Available to Order: Shipping delay up to 10 days.
#16	40019111	SCREW (M5 X 35) REST TO STARTER HOUSING (2 required per assembly)
		10-40019111 - Screw [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
#17	309772	SPACER REST SCREW (4 required per assembly)
		23-30977 2 - Spacer [ More info ] $4.79 2 In Stock.
#18	401385	NUT (M5) STAINLESS STEEL REST SCREW (2 required per assembly) — Replaces: 400633
		11-40138 5 - Nut [ More info ] Unavailable
#19	42034A2	PULLEY ASSEMBLY STARTER REWIND STARTER (1 required per assembly) — Replaces: 42034A1
		42034A 2 - Starter Sheave [ More info ] Unavailable
#20	427071	CAP STARTER SHEAVE (1 required per assembly)
		19-42707 1 - Cap, NLA [ More info ] $1.77 $1.49 10+ In Stock.
#20	817362	CAP STARTER SHEAVE (CAP PLUG) (1 required per assembly)
		19-817362 - Plug [ More info ] Unavailable
#21	42209	TAB STARTER SHEAVE (3 required per assembly)
		42209 - TAB,NLA [ More info ] Unavailable
#22	48408	SCREW (#10-16 X .500) TAB (3 required per assembly)
#23	12066Q10	ROPE-STARTR @2 STARTER (1 required per assembly) — Replaces: 12066A9, 12066Q9
		50-12066Q10 - Starter Rope - Priced Individually [ More info ] $13.59 6 In Stock.
		18-4915 - Pull Rope, 50-12066Q9 [ More info ] $4.79 $4.53 4 In Stock.
		50-12066K10 - Starter Rope - Priced Individually [ More info ] $14.99 3 In Stock.
#24	85174A1	HANDLE ASSEMBLY STARTER ROPE (1 required per assembly)
		85174A 1 - Handle Assembly -start [ More info ] $28.29 Available to Order: Shipping delay up to 10 days.
