Parts for 80 Jet 2-Stroke Carbureted Mercury Outboard Motor Top Cowl (S/N USA-0G301750 / Bel-9885504 & Below)
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 828354A11 | COWL ASSY-BLK-B/F (BLACK) (1 required per assembly) |
  |
|
4026-828354A11 - Motor Cowl, Black, NLA [ More info ] Unavailable |
| #1 | 828354A12 | COWL ASSY-SIL-B/F (SILVER) (1 required per assembly) |
  |
|
4026-828354A12 - Motor Cowl, Silver, B/C, NLA [ More info ] Unavailable |
| #1 | 828354A13 | COWL ASSY-TRA-B/F (TRACKER GRAPHITE GRAY) (1 required per assembly) |
  |
|
4026-828354A13 - Motor Cowl, Tracking, Gray, NLA [ More info ] Unavailable |
| #2 | 819813T1 | BRACKET COVER LATCH (1 required per assembly) — Replaces: 8198131 |
  |
|
819813T 1 - Bracket [ More info ]
|
| #3 | 893763 | BRACKET ROLLER LATCH (1 required per assembly) — Replaces: 18173 |
  |
|
893763 - Roller Latch Bracket [ More info ]
|
| #4 | 53166 | LOCKWASHER (.312) (2 required per assembly) |
  |
|
13-53166 - LockWasher - Priced Individually [ More info ]
|
| #5 | 90285 | SCREW (.312-18 X .625) (2 required per assembly) |
  |
|
10-90285 - Screw [ More info ]
|
| #6 | F481434 | GUIDE COWL LATCH BRACKET (2 required per assembly) |
  |
|
F481434 - Engine Cover Guide [ More info ]
|
| #7 | 91925 | PUSH NUT (4 required per assembly) |
  |
|
11-91925 - Push Nut [ More info ]
|
| #8 | 822512 | SCREW (.250-20 X 1.00) (3 required per assembly) |
  |
|
10-822512 - Screw [ More info ]
|
| #9 | 823583A02 | SOUND BLANKET KIT (PRE-APPLIED PRESSURE SENSITIVE ADHESIVE) (1 required per assembly) — Replaces: 823583A1 |
  |
|
823583A02 - Sound Blanket Kit [ More info ]
|
| #10 | 821912A1 | TRAP DOOR (BLACK) (1 required per assembly) |
  |
|
821912A 1 - TRAP DOOR-Black, NLA [ More info ] Unavailable |
| #10 | 821912A2 | TRAP DOOR (SILVER) (1 required per assembly) |
  |
|
821912A 2 - Trap Door, Silver, NLA [ More info ]
|
| #10 | 821912A3 | TRAP DOOR (TRACKER GRAPHITE GRAY) (1 required per assembly) |
  |
|
821912A 3 - Trap Door-tracker, NLA [ More info ] Unavailable |
| #11 | 8239671 | SEAL TRAP DOOR (1 required per assembly) |
  |
|
823967 1 - Seal, NLA [ More info ]
|
| #12 | 8220551 | PIN HINGE (1 required per assembly) |
  |
|
17-822055 1 - Hinge Pin, NLA [ More info ]
|
| #13 | 82104512 | SCREW (M5 X 12) (2 required per assembly) |
  |
|
10-821045 12 - Screw [ More info ]
|
| #14 | 4002316 | WASHER (6.60 X 17.0 X 1.5SS) (2 required per assembly) |
  |
|
12-40023 16 - Washer - Priced Individually [ More info ]
|
  |
|
128M0214930 - WASHER Note: Must be ordered in multiples of 5 [ More info ]
|
| #15 | 8218751 | CAP-UPPER-BLACK (TRACKER GRAPHITE GRAY) (1 required per assembly) — Replaces: 821875F1, 821875F2, 821875F3 |
  |
|
8218751 - Cap - Upper- Black [ More info ]
|
| #16 | 401386 | NUT (M6) STAINLESS STEEL (2 required per assembly) — Replaces: 8268336, 40144 |
  |
|
11-40138 6 - Nut - Priced Individually [ More info ]
|
| #17 | 8239601 | CATCH (1 required per assembly) |
  |
|
823960 1 - Catch, NLA [ More info ]
|
| #18 | 878608 | SCREW (#10-16 X .500) (1 required per assembly) — Replaces: 812832 |
  |
|
10-878608 - Screw [ More info ]
|
| #19 | 823865 | CAP PLUG (2 required per assembly) |
  |
|
|
| #20 | 82130016 | SCREW (M6 X 16) (4 required per assembly) |
  |
|
10-821300 16 - Screw - Priced Individually [ More info ]
|
| #21 | 47341A11 | ROPE AND HANDLE (1 required per assembly) |
  |
|
47341A11 - Manual Start Rope And Handle [ More info ]
|
