Drive Housing Components (Threaded Drive)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	820242A1	PLATE ASSEMBLY ADAPTER (Painted) (1 required per assembly)
		820242A 1 - Plate,NLA [ More info ] Unavailable
#2	F695043	SLEEVE ADAPTER (1 required per assembly)
		F695043 - Sleeve [ More info ] Unavailable
#3	820339	BRACKET TOWERSHAFT BEARING (1 required per assembly)
		820339 - Bracket, NLA [ More info ] $2.50 $2.13 2 In Stock.
#4	4010610	SCREW (2 required per assembly)
		10-40106 10 - Screw [ More info ] $2.39 Available to Order: Shipping delay up to 10 days.
#5	F40689-1	BEARING TOWERSHAFT LOWER (1 required per assembly)
		23-F40689-1 - Bearing - Towershaft Lower [ More info ] $2.59 10+ In Stock.
#6	856774	WASHER @5 (10 required per assembly) — Replaces: 45175
		12-856774 - Washer, (.406 X .750 X .105) Stainless Steel [ More info ] Unavailable
		128M0214963 - WASHER Note: Priced Individually [ More info ] $2.59 10+ In Stock.
#7	35047	SCREW @2 (10 required per assembly)
		10-35047 - Screw - Priced Individually [ More info ] $3.79 Available to Order: Shipping delay up to 10 days.
#8	820244A5	COVER KIT DRIVE HOUSING (Painted) (1 required per assembly) — Replaces: 820244A1, 820244A4
		820244A 5 - Cover Kit [ More info ] Unavailable
		820244A 6 - Cover Kit [ More info ] Unavailable
#9	820504A2	SLEEVE ASSY COVER (1 required per assembly) — Replaces: 820504A1
		820504A 2 - Sleeve,NLA [ More info ] Unavailable
#10	8204511	STUD (M8 X 55) (4 required per assembly)
		16-820451 1 - Stud [ More info ] $8.79 Available to Order: Shipping delay up to 10 days.
#11	8204521	FITTING WATER HOSE (1 required per assembly) — Replaces: 820452
		22-820452 1 - Fitting [ More info ] $4.00 $3.39 10+ In Stock.
#12	19812T03	BRACKET ASSEMBLY CONTROL CABLE ANCHOR (1 required per assembly) — Replaces: 19812A2, 19812A1
		19812T03 - Bracket Assembly [ More info ] $53.49 Available to Order: Shipping delay up to 10 days.
#13	98889	LATCH CONTROL CABLE (1 required per assembly)
		98889 - Latch [ More info ] $3.79 5 In Stock.
#14	39519	CUP BARREL RETAINER (1 required per assembly)
		39519 - Cup [ More info ] $5.39 Available to Order: Shipping delay up to 10 days.
#15	F722932	SPACER (.750) (2 required per assembly)
		23-F722932 - Spacer, NLA [ More info ] $5.39 7 In Stock.
#16	4002317	WASHER (8.90 X 17.0 X 1.9SS) (2 required per assembly)
		12-40023 17 - Washer - Priced Individually [ More info ] $1.70 1 In Stock.
#17	400257	LOCKWASHER (M8) (2 required per assembly)
		13-40025 7 - LockWasher [ More info ] $3.79 Available to Order: Shipping delay up to 10 days.
#18	40011155	SCREW (M8 X 55) STAINLESS STEEL (2 required per assembly)
		10-40011155 - Screw [ More info ] $6.09 Available to Order: Shipping delay up to 10 days.
#19	820448	HOSE ASSEMBLY WATER INLET (1 required per assembly)
		32-820448 - Hose Assembly, NLA [ More info ] Unavailable
#20	820238A15	ORD1500-820238A14 DRIVE (Painted) (1 required per assembly) — Replaces: 820238A2, 820238A6
		1500-820238A15 - ORD1500-820238A1, NLA [ More info ] Unavailable
#20	820238A14	HOUSING KIT-COMP DRIVE (Complete) (Painted) (No Impeller) (1 required per assembly) — Replaces: 820238A4, 820238A5
		1500-820238A14 - Housing Kit-COMP,NLA [ More info ] Unavailable
#21	40120110	PIN DOWEL (2 required per assembly)
		17-40120110 - Pin -Dowel, NLA [ More info ] Unavailable
#22	94038	SEAL OIL (2 required per assembly)
		26-94038 - Seal - Priced Individually [ More info ] $18.49 $17.76 9 In Stock.
		18-2007 - Seal 26-94038 [ More info ] $15.99 $14.69 2 In Stock.
#23	820292	BEARING BALL (1 required per assembly)
		30-820292 - Ball Bearing [ More info ] $68.99 Available to Order: Shipping delay up to 10 days.
#24	8M0051043	RETAINING RING (1 required per assembly) — Replaces: 23721
		53-8M0051043 - Retainer Ring [ More info ] $2.49 Available to Order: Shipping delay up to 10 days.
#25	831976	FOAM EXHAUST DEFLECTOR (2 required per assembly) — Replaces: 823611
		831976 - Foam - Deflector [ More info ] Unavailable
#26	79953Q2	SCREW KIT (.375-16 X .250) DRAIN (Style I) (1 required per assembly) — Replaces: 79953, 79953A2
		10-79953Q 2 - Screw Kit - Priced Individually [ More info ] Unavailable
		10-79953Q04 - Screw Kit - Priced Individually [ More info ] $7.49 9 In Stock.
		18-2244 - Plug Kit, 10-79953A2 [ More info ] $3.79 10+ In Stock.
		10-79953K04 - Drain Screw - Priced Individually [ More info ] $8.19 10+ In Stock.
#26	79953A2	SCREW KIT (.375-16 X .250) (Style II) (1 required per assembly) — Replaces: 28634A1, 79953
		10-79953A 2 - Drain Screw Kit [ More info ] Unavailable
#27	820258	GASKET DRIVE HOUSING (1 required per assembly)
		27-820258 - Drive Housing Gasket [ More info ] Unavailable
#28	8233581	STUD (M10 X 72) (5 required per assembly) — Replaces: 823358
		16-823358 1 - Stud, NLA [ More info ] $3.00 $2.54 10+ In Stock.
#29	8233575	NUT (5 required per assembly)
		11-823357 5 - Nut, NLA [ More info ] $2.50 $2.13 10 In Stock.
#30	8233573	NUT (4 required per assembly)
		11-823357 3 - Nut, NLA [ More info ] $2.50 $2.13 10+ In Stock.
#31	38101	O RING @2 (1 required per assembly)
		25-38101 - O-ring, (.674 X .103) [ More info ] $1.80 10+ In Stock.
#32	4010875	SCREW (1 required per assembly)
		10-40108 75 - Screw [ More info ] $15.19 Available to Order: Shipping delay up to 10 days.
#33	4010835	SCREW (2 required per assembly)
		10-40108 35 - Screw [ More info ] $7.29 Available to Order: Shipping delay up to 10 days.
#34	820663500	GROMMET (.500) PUMP MOUNT (AR required per assembly)
		25-820663500 - Grommet-pump Mount [ More info ] $124.49 Available to Order: Shipping delay up to 10 days.
#34	820663375	GROMMET (.375) PUMP MOUNT (AR required per assembly)
		25-820663375 - Grommet-pump Mount [ More info ] $29.99 $25.39 2 In Stock.
#34	820663250	GROMMET (.250) PUMP MOUNT (AR required per assembly)
		25-820663250 - Grommet-Pump Mount [ More info ] $173.49 Available to Order: Shipping delay up to 10 days.
#35	820342	BAFFLE EXHAUST (Painted) (2 required per assembly)
		820342 - Exhaust Baffle, NLA [ More info ] Unavailable
#36	4010610	SCREW (Bottom) (4 required per assembly)
#37	82130025	SCREW @5 (Top) (4 required per assembly) — Replaces: 4010625
		10-821300 25 - Screw [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#38	820495	BAFFLE EXHAUST (1 required per assembly)
		820495 - Drive Housing Baffle, NLA [ More info ] $14.00 $11.86 10 In Stock.
#39	400256	LOCKWASHER @5 (4 required per assembly)
		13-40025 6 - LockWasher - Priced Individually [ More info ] $1.80 $1.01 10+ In Stock.
#40	400212	NUT (4 required per assembly)
		11-40021 2 - Nut [ More info ] $2.89 2 In Stock.
#41	8204631	BRACKET STEERING (Painted) (1 required per assembly) — Replaces: 820463
		820463 1 - Steering Bracket, NLA [ More info ] $7.55 10+ In Stock.
#42	4010716	SCREW (3 required per assembly)
		10-40107 16 - Screw [ More info ] $4.49 1 In Stock.
#43	8205911	TAB LOCKING (1 required per assembly) — Replaces: 820591
		14-820591 1 - Tab- Locking, NLA [ More info ] $2.50 $2.13 10+ In Stock.
#45	8202531	SCREEN INLET (Painted) (1 required per assembly)
		820253 1 - Inlet Screen [ More info ] $183.24 10+ In Stock.
#46	824830	SCREW (With Nylon Patch) (4 required per assembly)
		10-824830 - Screw [ More info ] $6.89 10 In Stock.
#47	824829	SCREW (With Nylon Patch) (2 required per assembly)
		10-824829 - Screw [ More info ] $1.70 10+ In Stock.
#48	920071	FITTING (2 required per assembly) — Replaces: 92007
		22-92007 1 - Fitting [ More info ] $54.49 Available to Order: Shipping delay up to 10 days.
#49	815504104	CLAMP (2 required per assembly)
		54-815504104 - Clamp [ More info ] $6.79 $5.44 10+ In Stock.
#50	8M0062600	HOSE-LOCK ON (Cut to 12.00 Inch Length) (1 required per assembly) — Replaces: 1940964, 1940971
		32-8M0062600 - Hose - Lock On [ More info ] Unavailable
		32-8M0040618 - Oil Reservoir Hose, 54 inch [ More info ] Unavailable
		32-8M0214996 - OIL RESERVIOR HOSE 54IN ZZ [ More info ] $30.79 4 In Stock.
#51	820488	ADAPTER OIL VENT (Painted) (1 required per assembly)
		820488 - Adapter - Oil Vent, NLA [ More info ] Unavailable
#52	79953A2	SCREW KIT-DRAIN (Style II) (1 required per assembly) — Replaces: 28634A1, 79953
#52	79953Q2	SCREW KIT @2 (Style I) (1 required per assembly) — Replaces: 79953, 79953A2
#53	191833	SEAL-BLUE @15 (Style I) (1 required per assembly) — Replaces: 19183, 191832
		12-19183 3 - Seal -Blue - Priced Individually [ More info ] Unavailable
		18-2945-9 - Gasket 12-19183 2-Pack [ More info ] $2.41 10+ In Stock.
		12-19183Q02 - Seals, Pack of 4 (yes this is actually a pack of 4) [ More info ] $6.69 5 In Stock.
		12-19183K02 - Seal, Pack of 4 [ More info ] $7.29 8 In Stock.
		12-8M0187157 - SEAL-BLUE, Sold Individually [ More info ] $1.49 10+ In Stock.
		12-02108-1 - Drain Gasket (1 piece) [ More info ] $1.20 $0.85 10+ In Stock.
#53	8M0204684	O RING (Style II) (1 required per assembly) — Replaces: 805726
		25-8M0204684 - O-RING FILL/DRAIN SCREW [ More info ] $2.49 4 In Stock.
#54	820472A3	RIDE PLATE KIT (Painted) (1 required per assembly)
		820472A 3 - Ride Plate Kit [ More info ] Unavailable
#55	8301231	SEAL RIDE PLATE (1 required per assembly) — Replaces: 8204891, 820489T1
		830123 1 - Seal [ More info ] Unavailable
#56	824830	SCREW (M6 X 13) (With Nylon Patch) (10 required per assembly)
#57	824829	SCREW (M6 X 20) (With Nylon Patch) (2 required per assembly)
#58	820611A1	SEAL/GASKET SET DRIVE HOUSING (1 required per assembly)
		26-820611A 1 - Seal/Gasket Kit [ More info ] Unavailable
#59	35280	WASHER (OPT required per assembly)
		12-35280 - Washer, (.255 X .620 X .030) Stainless Steel [ More info ] $3.19 $2.56 10+ In Stock.
#--	820611A1	SEAL/GASKET SET DRIVE HOUSING (1 required per assembly)
#--	820238A14	HOUSING KIT-COMP DRIVE (Complete) (Painted) (No Impeller) (1 required per assembly) — Replaces: 820238A4, 820238A5
#--	820630R6	POWERHEAD-REMAN (Oil Injection) (1 required per assembly) — Replaces: 820630A3, 820630A7
		800-820630R 6 - Powerhead-REMAN,NLA [ More info ] Unavailable
#--	818153R31	POWERHEAD-REMAN (Non Oil Injection) (1 required per assembly) — Replaces: 817608A14, 818153A32
		800-818153R31 - Powerhead-REMAN,NLA [ More info ] Unavailable
#26A	191833	SEAL (Style I) (1 required per assembly) — Replaces: 19183, 191832
#26A	8M0204684	O RING (Style II) (1 required per assembly) — Replaces: 805726
