Parts for 40 MXL Seapro 2-Stroke Carbureted Mercury Outboard Motor Transom & Swivel Brackets (Manual)

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > 40 MXL Seapro > 0N037781 - 0N056164 > Transom & Swivel Brackets (Manual)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Transom & Swivel Brackets (Manual)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	8M0151529	CLAMP BRKT STBD (Starboard) (1 required per assembly) — Replaces: 804038, 8M0082474
		14008M0151529 - CLAMP BRKT STBD [ More info ] $282.49 Available to Order: Shipping delay up to 10 days.
#2	8M0151531	CLAMP BRKT PORT (Port) (1 required per assembly) — Replaces: 804039, 8M0082473
		14008M0151531 - CLAMP BRKT PORT [ More info ] $254.49 Available to Order: Shipping delay up to 10 days.
#3	898101191	TILT TUBE (1 required per assembly) — Replaces: 853769
		898101191 - Tilt Tube [ More info ] $103.49 Available to Order: Shipping delay up to 10 days.
#4	85372214	CAP NUT (HANDLE) (2 required per assembly)
		11-853722 14 - Cap Nut [ More info ] $5.59 Available to Order: Shipping delay up to 10 days.
#5	853722029	NUT (1 required per assembly) — Replaces: 85372213
		11-853722029 - Nut, Nylon [ More info ] $23.09 Available to Order: Shipping delay up to 10 days.
#6	8537435	BUSHING (2 required per assembly)
		23-853743 5 - Bushing [ More info ] $13.59 Available to Order: Shipping delay up to 10 days.
#7	8113681	SLEEVE (1 required per assembly)
		23-811368 1 - Sleeve [ More info ] $7.09 Available to Order: Shipping delay up to 10 days.
#8	162638	BOLT (1 required per assembly)
		10-162638 - BOLT [ More info ] Unavailable
#9	804040	DISTANCE PIECE (1 required per assembly)
		804040 - DISTANCE PIECE [ More info ] Unavailable
#10	400256	LOCKWASHER @5 (1 required per assembly)
		13-40025 6 - LockWasher - Priced Individually [ More info ] $1.80 $1.01 10+ In Stock.
#11	400213	NUT @2 (1 required per assembly)
		11-40021 3 - Nut - Priced Individually [ More info ] $2.89 1 In Stock.
#12	8M0156644	CLAMP SCREW KIT (2 required per assembly) — Replaces: 804042A1, 8M0060118
		108M0156644 - 8M0161541 [ More info ] Unavailable
		8M0161541 - Clamp Screw Kit, One side only as shown [ More info ] Unavailable
		108M0176078 - Clamp Screw Kit [ More info ] $87.49 Available to Order: Shipping delay up to 10 days.
#13	95379	WASHER (2 required per assembly)
		12-95379 - Washer,Pad, Clamp Screw [ More info ] Unavailable
#14	804041	THRUST ROD (1 required per assembly)
		804041 - Thrust Rod [ More info ] $50.49 Available to Order: Shipping delay up to 10 days.
#15	8126455	SPRING (1 required per assembly)
		24-812645 5 - Spring [ More info ] $5.09 Available to Order: Shipping delay up to 10 days.
#16	851872	CAP-BLACK (1 required per assembly)
		851872 - 851872 - CAP [ More info ] Unavailable Replaced by -8M0222196
		8M0222196 - CAP-BLACK [ More info ] Unavailable
#17	82304215	BOLT (3 required per assembly)
		10-82304215 - BOLT [ More info ] Unavailable
#18	8M0115483	BOLT (2 required per assembly) — Replaces: 8129356
		108M0115483 - Bolt [ More info ] $17.89 Available to Order: Shipping delay up to 10 days.
#19	879194012	PLATE-LOCKING (1 required per assembly)
		879194012 - PLATE-LOCKING [ More info ] Unavailable
#20	851870	GROMMET (2 required per assembly)
		25-851870 - Grommet [ More info ] $11.89 Available to Order: Shipping delay up to 10 days.
#21	8M0079616	MOUNT (2 required per assembly) — Replaces: 8537713
		8M0079616 - Mount [ More info ] $37.49 Available to Order: Shipping delay up to 10 days.
#22	8M0075085	SWIVEL TUBE (1 required per assembly) — Replaces: 853770, 853770007
		8M0075085 - 8M0075085 - SWIVEL TUBE [ More info ] Unavailable Replaced by -8M0075036
		8M0075036 - Swivel Tube [ More info ] Unavailable
#23	162041	THRUST PLATE [0N005307] & Below (1 required per assembly) — Replaces: 162043
		16204 1 - Thrust Plate [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#24	8537436	BUSHING (2 required per assembly)
		23-853743 6 - Bushing [ More info ] $11.59 Available to Order: Shipping delay up to 10 days.
#25	162052	FRICTION PLATE (1 required per assembly)
		16205 2 - Friction Plate [ More info ] $8.09 Available to Order: Shipping delay up to 10 days.
#26	813029A12	SWIVEL BRKT KIT [0N005307] & Below (1 required per assembly) — Replaces: 81302911
		3407-813029A12 - Swivel Bracket Kit [ More info ] $533.99 Available to Order: Shipping delay up to 10 days.
#27	4000354	SCREW @5 (1 required per assembly)
		10-40003 54 - Screw - Priced Individually [ More info ] $4.79 7 In Stock.
#28	953831	SPRING (1 required per assembly)
		24-95383 1 - Spring [ More info ] $7.29 Available to Order: Shipping delay up to 10 days.
#29	898101089	WIRE-GROUND (1 required per assembly) — Replaces: 8537401
		84-898101089 - Wire - Ground [ More info ] $14.39 Available to Order: Shipping delay up to 10 days.
#30	8230427	BOLT (2 required per assembly)
		10-823042 7 - Bolt [ More info ] $4.09 $2.30 10+ In Stock.
#31	8239121	ANODE (1 required per assembly)
		823912 1 - Anode, NLA [ More info ] $4.00 $3.39 10+ In Stock.
#32	400256	LOCKWASHER @5 (2 required per assembly)
#33	16830	BOLT (2 required per assembly)
		10-16830 - Bolt [ More info ] $5.29 Available to Order: Shipping delay up to 10 days.
#34	16109003	O RING (1 required per assembly) — Replaces: 161313
		25-16109003 - O-Ring [ More info ] $4.79 Available to Order: Shipping delay up to 10 days.
#35	16204004	THRUST PLATE (1 required per assembly) — Replaces: 162042
		16204004 - Thrust Plate [ More info ] $8.19 2 In Stock.
#36	851866012	SCREW (2 required per assembly) — Replaces: 8518661
		10-851866012 - Screw [ More info ] $11.89 Available to Order: Shipping delay up to 10 days.
#37	953928	WASHER (2 required per assembly)
		12-95392 8 - Washer [ More info ] $13.59 $10.88 4 In Stock.
#38	851867	WASHER (2 required per assembly)
		12-851867 - Washer [ More info ] $15.09 Available to Order: Shipping delay up to 10 days.
#39	8M0075315	MOUNT (2 required per assembly) — Replaces: 8537712
		8M0075315 - Mount [ More info ] $57.49 Available to Order: Shipping delay up to 10 days.
#40	879194343	WASHER (4 required per assembly) — Replaces: 851868, 95392014
		12-879194343 - Washer [ More info ] $7.19 Available to Order: Shipping delay up to 10 days.
#41	8M0064214	BOTTOM YOKE (1 required per assembly) — Replaces: 8537862, 853786007
		8M0064214 - Bottom Yoke [ More info ] $227.99 Available to Order: Shipping delay up to 10 days.
#42	8537142	CLIP (1 required per assembly)
		53-853714 2 - Clip [ More info ] $2.59 Available to Order: Shipping delay up to 10 days.
#43	8537732	DAMPER (1 required per assembly)
		853773 2 - Damper [ More info ] $11.89 Available to Order: Shipping delay up to 10 days.
#44	85372218	NUT (2 required per assembly)
		11-853722 18 - Nut [ More info ] $6.29 Available to Order: Shipping delay up to 10 days.
#45	851869	COVER-BLACK (2 required per assembly)
		851869 - COVER [ More info ] Unavailable
#46	167051	BOLT (4 required per assembly)
		10-16705 1 - Bolt [ More info ] $6.09 Available to Order: Shipping delay up to 10 days.
#47	8537405	WIRE-GROUND (1 required per assembly)
		84-853740 5 - Wire-Ground [ More info ] $6.89 Available to Order: Shipping delay up to 10 days.
#48	16826	WASHER (1 required per assembly)
		12-16826 - Washer, Stainless Steel [ More info ] $3.29 Available to Order: Shipping delay up to 10 days.
#49	824969	FITTING (1 required per assembly)
		22-824969 - Fitting [ More info ] $8.99 3 In Stock.
#50	808599	CAP (1 required per assembly)
		808599 - Cap, NLA [ More info ] Unavailable
#51	804043	ANODE (1 required per assembly)
		97804043 - Anode [ More info ] $19.29 Available to Order: Shipping delay up to 10 days.
#52	8M0098606	BOLT (1 required per assembly) — Replaces: 82304230, 879194265
		108M0098606 - Bolt [ More info ] Unavailable
		10-8M0147119 - BOLT [ More info ] Unavailable
