Parts for 75 (3 Cyl.) 2-Stroke Carbureted Mercury Outboard Motor Exhaust Plate
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 43004A99 | GASKET SET (1 required per assembly) — Replaces: 43004A90 |
  |
|
27-43004A99 - Engine Gasket Set [ More info ]
|
| #1 | 42954A5 | PLATE ASY-EXHAUST (1 required per assembly) |
  |
|
42954A 5 - Exhaust Plate Assembly [ More info ]
|
| #2 | 23784 | PIN DOWEL (5 required per assembly) |
  |
|
17-23784 - Pin, Dowel [ More info ]
|
| #3 | 40011151 | SCREW @5 (2 required per assembly) |
  |
|
10-40011151 - Screw [ More info ]
|
| #3 | 40011158 | SCREW (1 required per assembly) |
  |
|
10-40011158 - Screw [ More info ]
|
| #4 | 881900T | MOUNT (NON OIL INJECTION)(LL) (1 required per assembly) — Replaces: 443442, 44344T2 |
  |
881900T - Mount [ More info ] Unavailable |
|
  |
881900T01 - MOUNT [ More info ] Unavailable |
|
  |
881900T02 - MOUNT [ More info ] Unavailable |
|
  |
|
881900T03 - Mount [ More info ]
|
| #4 | 8M0021331 | ORD 881900T03 (OIL INJECTION) (JET 65) (1 required per assembly) — Replaces: 429492, 881901 |
  |
|
8M0021331 - Mount [ More info ] Unavailable |
| #5 | 4010750 | SCREW (4 required per assembly) |
  |
|
10-40107 50 - Screw [ More info ]
|
| #6 | 898487 | SCREW (2 required per assembly) — Replaces: 42974 |
  |
10-898487 - Screw [ More info ] Unavailable |
|
  |
|
10-8M0238139 - SCREW [ More info ]
|
| #7 | 32834 | WASHER @5 (2 required per assembly) — Replaces: 934161 |
  |
|
12-32834 - Washer, (.9375 X 1.750 X .172) [ More info ]
|
| #8 | 8M0204648 | WASHER @5 (2 required per assembly) — Replaces: 28421 |
  |
|
12-8M0204648 - ENGINE MOUNTING WASHER Note: Must be ordered in multiples of 5 O/B [ More info ]
|
| #9 | 896963 | NUT @6 (2 required per assembly) — Replaces: 90099, 859129 |
  |
|
11-896963 - Nut, (M12) [ More info ]
|
| #10 | 430086 | GASKET (1 required per assembly) |
  |
|
27-43008 6 - Gasket [ More info ]
|
| #11 | 87917216T | TUBE-EXHAUST (1 required per assembly) — Replaces: 429664 |
  |
|
87917216T - Exhaust Tube [ More info ]
|
| #11 | 42966A1 | TUBE KIT-EXHAUST (BELGIUM)(INCLUDES RESTRICTOR PLATE) (1 required per assembly) |
  |
|
42966A1 - TUBE KIT-EXHAUST,NLA [ More info ] Unavailable |
| #12 | 40011151 | SCREW @5 (6 required per assembly) |
| #13 | 8M0039075 | SEAL (1 required per assembly) — Replaces: 42962 |
  |
|
8M0039075 - Seal [ More info ]
|
| #14 | 89417004 | GROMMET (1 required per assembly) — Replaces: 894171 |
  |
|
25-89417004 - Grommet [ More info ]
|
| #15 | 8M0042791 | TUBE-WATER-LONG (13-1/4 IN.) (1 required per assembly) — Replaces: 8246601, 8812011 |
  |
|
32-8M0042791 - Water Tube - Long [ More info ]
|
| #15 | 8M0042793 | TUBE-WATER-LL (15-3/4 IN.) (1 required per assembly) — Replaces: 8246603, 8812013 |
  |
|
328M0042793 - Water Tube -ll [ More info ]
|
| #15 | 8M0042792 | TUBE-WATER-XL (18-1/4 IN.) (1 required per assembly) — Replaces: 8246602, 8812012 |
  |
|
32-8M0042792 - Water Tube -xl [ More info ]
|
| #16 | 824661 | CLAMP (1 required per assembly) |
  |
|
824661 - Water Tube Clamp [ More info ]
|
| #17 | 814080001 | SEAL (UPPER) (1 required per assembly) — Replaces: 814080 |
  |
|
814080001 - Upper Seal [ More info ]
|
| #18 | 4010750 | SCREW (2 required per assembly) |
| #19 | 42953A5 | BRACKET ASSEMBLY (LOWER) (BLACK) (1 required per assembly) |
  |
|
42953A 5 - Bracket - Black [ More info ]
|
| #19 | 42953A6 | BRACKET ASSEMBLY (LOWER) (GRAY) (1 required per assembly) |
  |
|
42953A 6 - Bracket-GRAY,NLA [ More info ] Unavailable |
| #19 | 42953A7 | BRACKET ASSEMBLY (LOWER) (TRACKER-GRAPHITE GRAY) (1 required per assembly) |
  |
|
42953A 7 - Bracket-TRACKER,NLA [ More info ] Unavailable |
| #20 | 43405 | SEAL (1 required per assembly) |
  |
|
43405 - Lower Cowl Bracket Seal [ More info ] Unavailable |
| #21 | 12602002 | GROMMET (Power Trim) [0G360002] & Below (1 required per assembly) — Replaces: 126021 |
  |
|
25-12602002 - Grommet (.44 I.d.) [ More info ]
|
| #21 | 8M0179867 | GROMMET (NON POWER TRIM/MANUAL TILT ASSIST) (1 required per assembly) — Replaces: 19564, 19564001 |
  |
|
258M0179867 - Grommet [ More info ]
|
| #22 | 19565002 | GROMMET (Power Trim) [0G360003] & Up (1 required per assembly) — Replaces: 19565 |
  |
|
25-19565002 - Grommet [ More info ]
|
| #23 | 81742750 | SCREW (3 required per assembly) |
  |
|
10-817427 50 - Screw [ More info ] Unavailable |
| #24 | 48237 | BUSHING (1 required per assembly) |
  |
|
23-48237 - Bushing [ More info ]
|
| #25 | 79932A9 | LEVER ASSY (UPPER - ELECTRIC) [USA-0G589999/BEL-9973099] & Below (1 required per assembly) |
  |
|
79932A 9 - LEVER ASSY [ More info ] Unavailable |
| #25 | 79932A20 | LEVER KIT-SHIFT (UPPER - ELECTRIC) [0G590000/BEL-9973100] & Up (1 required per assembly) — Replaces: 79932A19 |
  |
|
79932A20 - Shift Lever Kit [ More info ]
|
  |
|
92-205-07K - Mid Section Shift Shaft Kit [ More info ]
|
| #25 | 79932A23 | LEVER ASSY. SHIFT (UPPER - MANUAL) (1 required per assembly) — Replaces: 79932A13 |
  |
|
79932A23 - Lever Assembly Shift [ More info ]
|
| #26 | 42912A1 | LINK KIT-SHIFT [USA-0G589999/BEL-9973099] & Below (1 required per assembly) |
  |
|
42912A 1 - Shift Link Kit, NLA [ More info ]
|
| #26 | 42912A3 | SHIFT LINK KIT [0G590000/BEL-9973100] & Up (1 required per assembly) |
  |
|
42912A 3 - Shift Link Kit [ More info ]
|
| #27 | 48475 | BUSHING (2 required per assembly) |
  |
|
23-48475 - Bushing [ More info ]
|
| #28 | 401386 | NUT @5 (1 required per assembly) — Replaces: 8268336, 40144 |
  |
|
11-40138 6 - Nut - Priced Individually [ More info ]
|
| #29 | 813745 | SPACER (LONG) (1 required per assembly) |
  |
|
23-813745 - Spacer [ More info ]
|
| #29 | 11289 | SPACER (X-LONG)(LL) (1 required per assembly) |
  |
|
23-11289 - Spacer - Shift Shaft - XL [ More info ]
|
| #30 | 43585 | COUPLING (POWER TRIM/MANUAL TILT ASSIST) (1 required per assembly) |
  |
|
43585 - Shift Shaft Coupling [ More info ]
|
  |
|
18-1730 - Coupling, 43585 [ More info ]
|
  |
|
93-02639 - Shift Coupling 43585 [ More info ]
|
| #31 | 43053 | COUPLING (NON POWER TRIM) (1 required per assembly) |
  |
|
43053 - Coupling [ More info ]
|
