Parts for 75 (3 Cyl.) 2-Stroke Carbureted Mercury Outboard Motor Exhaust Plate
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 43004A99 | GASKET SET ( required per assembly) — Replaces: 43004A86, 43004A90 |
  |
|
27-43004A99 - Engine Gasket Set [ More info ]
|
| #1 | 42954A1 | PLATE ASSEMBLY EXHAUST (1 required per assembly) |
  |
|
42954A 1 - Plate,NLA [ More info ] Unavailable |
| #2 | 23784 | PIN DOWEL (4 required per assembly) |
  |
|
17-23784 - Pin, Dowel [ More info ]
|
| #3 | 42939 | SEAL LOWER COWL (1 required per assembly) |
  |
|
42939 - Lower Cowl Seal, NLA [ More info ]
|
| #4 | 42949T1 | UPPER MOUNT UPPER (LONG) (1 required per assembly) — Replaces: 429491 |
  |
|
42949T 1 - Upper Mount [ More info ] Unavailable |
| #4 | 443441 | MOUNT (3.25 INCH) UPPER (X-LONG) (1 required per assembly) |
  |
|
44344 1 - MOUNT-UPPER,NLA [ More info ] Unavailable |
| #5 | 82155050 | SCREW (M8 X 50) STAINLESS STEEL UPPER MOUNT TO EXHAUST PLATE (4 required per assembly) — Replaces: 4011350, 81475250 |
  |
|
10-821550 50 - Screw [ More info ]
|
| #6 | 898487 | SCREW (M12 X 175) UPPER MOUNT (2 required per assembly) — Replaces: 42974 |
  |
10-898487 - Screw [ More info ] Unavailable |
|
  |
|
10-8M0238139 - SCREW [ More info ]
|
| #6 | 12515 | SCREW (M12 X 160) UPPER MOUNT (HANDLE MODELS) (2 required per assembly) |
  |
|
10-12515 - SCREW,NLA [ More info ] Unavailable |
| #7 | 32834 | WASHER (.9375 X 1.750 X .172) UPPER MOUNT SCREW (2 required per assembly) — Replaces: 93416, 934161 |
  |
|
12-32834 - Washer, (.9375 X 1.750 X .172) [ More info ]
|
| #8 | 8M0204648 | WASHER (1.5 X 3.05 X 0.13) STAINLESS STEEL UPPER MOUNT SCREW (2 required per assembly) — Replaces: 28421 |
  |
|
12-8M0204648 - ENGINE MOUNTING WASHER Note: Must be ordered in multiples of 5 O/B [ More info ]
|
| #9 | 896963 | NUT (M12) UPPER MOUNT SCREW (2 required per assembly) — Replaces: 90099, 859129 |
  |
|
11-896963 - Nut, (M12) [ More info ]
|
| #10 | 996642 | FITTING ELBOW 90 DEGREE (.125-27 X .250) NYLON EXHAUSE PLATE (1 required per assembly) — Replaces: 99664, 996641 |
  |
|
22-99664 2 - Elbow [ More info ]
|
| #11 | 82127335 | SCREW (M8 X 35 MM) EXHAUSE PLATE (2 required per assembly) — Replaces: 4011135, 81742735 |
  |
|
10-821273 35 - Screw [ More info ]
|
| #11 | 4010770 | SCREW (M8 X 70) EXHAUSE PLATE (1 required per assembly) |
  |
|
10-40107 70 - Screw [ More info ]
|
| #12 | 430085 | GASKET EXHAUST PLATE (1 required per assembly) — Replaces: 43008, 430083 |
  |
27-43008 5 - Gasket [ More info ] Unavailable |
|
  |
|
27-43008 6 - Gasket [ More info ]
|
| #13 | 42966T | EXHAUST TUBE (1 required per assembly) |
  |
|
42966T - Exhaust Tube, NLA [ More info ] Unavailable |
| #14 | 4010735 | SCREW (M8 X 35) EXHAUST TUBE TO PLATE (6 required per assembly) |
  |
|
10-40107 35 - Screw [ More info ]
|
| #15 | 8M0039075 | SEAL EXHAUST TUBE (1 required per assembly) — Replaces: 42962 |
  |
|
8M0039075 - Seal [ More info ]
|
| #16 | 430141 | TUBING (LONG) (1 required per assembly) |
  |
|
32-43014 1 - Tubing, NLA [ More info ] Unavailable |
| #16 | 430142 | TUBING (X-LONG) (1 required per assembly) |
  |
|
32-43014 2 - Tubing, NLA [ More info ] Unavailable |
| #17 | 99019 | CLAMP WATER TUBE SEAL (1 required per assembly) |
  |
|
99019 - Water Tube Clamp [ More info ]
|
| #18 | 42941001 | SEAL WATER TUBE (UPPER) (1 required per assembly) — Replaces: 42941 |
  |
|
42941001 - Water Tube Seal [ More info ]
|
| #19 | 4010750 | SCREW (M8 X 50) CLAMP (2 required per assembly) |
  |
|
10-40107 50 - Screw [ More info ]
|
| #20 | 93221002 | GROMMET WATER TUBE (1 required per assembly) — Replaces: 93221 |
  |
|
25-93221002 - Water Tube Grommet [ More info ]
|
| #21 | 42953A2 | BRACKET ASSEMBLY COWL (LOWER) (1 required per assembly) — Replaces: 42953A1 |
  |
|
42953A 2 - Bracket Assembly, NLA [ More info ] Unavailable |
| #22 | 43405 | SEAL LOWER COWL BRACKET (1 required per assembly) |
  |
|
43405 - Lower Cowl Bracket Seal [ More info ] Unavailable |
| #23 | 81742755 | SCREW (M8 X 55) LOWER COWL BRACKET (3 required per assembly) — Replaces: 4009555 |
  |
|
10-817427 55 - Screw [ More info ]
|
| #24 | 48237 | BUSHING SHIFT SHAFT (1 required per assembly) |
  |
|
23-48237 - Bushing [ More info ]
|
| #25 | 79932A9 | SHIFT SHAFT ASSEMBLY (UPPER) (1 required per assembly) |
  |
|
79932A 9 - LEVER ASSY [ More info ] Unavailable |
| #26 | 42994 | BUSHING SHIFT SHAFT (1 required per assembly) |
  |
|
23-42994 - Bushing [ More info ]
|
| #27 | 42912A1 | LINK KIT-SHIFT (1 required per assembly) — Replaces: 429121 |
  |
|
42912A 1 - Shift Link Kit, NLA [ More info ]
|
| #28 | 29720 | WAVE WASHER SHIFT SHAFT (1 required per assembly) |
  |
|
13-29720 - Wave Washer - Priced Individually [ More info ]
|
| #29 | 24664 | WASHER (M4 X 20) SHIFT SHAFT (1 required per assembly) |
  |
|
12-24664 - Washer, (M4 X 20) [ More info ]
|
| #30 | 40144 | NUT (M6) SHIFT SHAFT (1 required per assembly) — Replaces: 400634, 8268336 |
  |
11-40144 - NUT Note: Priced Individually [ More info ] Unavailable |
|
  |
|
11-40138 6 - Nut - Priced Individually [ More info ]
|
| #31 | 813745 | SPACER SHIFT SHAFT (LONG) (1 required per assembly) — Replaces: 43041 |
  |
|
23-813745 - Spacer [ More info ]
|
| #31 | 11289 | SPACER SHIFT SHAFT (X-LONG) (1 required per assembly) |
  |
|
23-11289 - Spacer - Shift Shaft - XL [ More info ]
|
| #32 | 43053 | COUPLING SHIFT SHAFT ) (NON POWER TRIM (1 required per assembly) |
  |
|
43053 - Coupling [ More info ]
|
| #33 | 43585 | COUPLING SHIFT SHAFT (POWER TRIM) (1 required per assembly) |
  |
|
43585 - Shift Shaft Coupling [ More info ]
|
  |
|
18-1730 - Coupling, 43585 [ More info ]
|
  |
|
93-02639 - Shift Coupling 43585 [ More info ]
|
