Parts for 70, 700 (3 Cyl.) 2-Stroke Carbureted Mercury Outboard Motor Crankshaft, Pistons & Connecting Rods

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > 70, 700 (3 Cyl.) > 7145938 - 7208332 - Canada > Crankshaft, Pistons & Connecting Rods

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Crankshaft, Pistons & Connecting Rods

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	8839A2	CRANKSHAFT (1 required per assembly) — Replaces: 7574A2
		462-8839A 2 - CrankShaft, NLA [ More info ] Unavailable
#2	64424T	BALL BEARING BALL-LOWER AND UPPER (2 required per assembly) — Replaces: 64424
		30-64424T - Ball Bearing [ More info ] $29.99 $25.39 3 In Stock.
#3	22369A1	SHIM SET LOWER BEARING TO CRANKSHAFT (AR required per assembly)
		15-22369A 1 - Shim Set, NLA [ More info ] $7.00 $5.93 2 In Stock.
#6	7509A3	BEARING ASSEMBLY MAIN (VALVE TYPE) (2 required per assembly)
		542-7509A 3 - Reed Block Assembly, NLA [ More info ] $119.99 $101.62 2 In Stock.
#7	20032	PIN DOWEL MAIN BEARING (4 required per assembly)
		17-20032 - Pin -Dowel - Priced Individually [ More info ] $2.30 10+ In Stock.
#8	60282	PIN DOWEL (STEPPED) (2 required per assembly)
		17-60282 - Pin -Dowel, NLA [ More info ] $2.50 $2.13 10+ In Stock.
#9	65855	PIN DOWEL REED STOP (16 required per assembly)
		17-65855 - Pin, Dowel [ More info ] $3.80 Available to Order: Shipping delay up to 10 days.
#10	66051A1	REED SET MATCHED-MAIN BEARING (2 required per assembly)
		34-66051A 1 - Reed Kit [ More info ] $114.34 4 In Stock.
#11	65946	STOP REED (8 required per assembly)
		34-65946 - Reed Stop, NLA [ More info ] $3.26 $2.76 10+ In Stock.
#12	77280	SCREW (.190-32 X .560) REED STOP MOUNTING (8 required per assembly)
		10-77280 - Screw, NLA [ More info ] Unavailable
#13	20110	NUT (#10-32) REED STOP MOUNTING SCREW (8 required per assembly)
		11-20110 - Nut (M10X32) [ More info ] $1.70 10+ In Stock.
#14	45775	SCREW (#12-28 X .560) MAIN BEARING CLAMPING (4 required per assembly)
		10-45775 - Screw, NLA [ More info ] Unavailable
#15	45774	NUT MAIN BEARING SCREW CLAMPING (4 required per assembly)
		11-45774 - Nut - Priced Individually [ More info ] $4.99 $4.22 10+ In Stock.
#16	26113T	RACE-CENTER MAIN OUTER (PAIR) (2 required per assembly) — Replaces: 26113
		26113T - Race - Center Main [ More info ] $147.49 Available to Order: Shipping delay up to 10 days.
#17	26933	RING SNAP OUTER RACE CLAMPING (2 required per assembly)
		53-26933 - Ring -snap, NLA [ More info ] $4.68 10+ In Stock.
#18	714221	BEARING (112 required per assembly) — Replaces: 71422
		29-71422 1 - Needle Bearing - Priced Individually [ More info ] $0.30 $0.26 10+ In Stock.
#19	9137A12	PISTON ASSY-STD (STANDARD) (3 required per assembly) — Replaces: 7433A3, 8896A3
		774-9137A12 - Piston Assembly -STD [ More info ] Unavailable
#19	9137A13	PISTON ASSY-.015 (.015O.S.) (AR required per assembly) — Replaces: 7434A2, 8897A2
		774-9137A13 - Piston Assembly -.015 [ More info ] Unavailable
#19	9137A14	PISTON ASSY-.030 (.030 O.S.) (AR required per assembly) — Replaces: 7576A2, 8898A2
		774-9137A14 - Piston Assembly -.030 [ More info ] $165.99 Available to Order: Shipping delay up to 10 days.
#20	857196	LOCK RING PISTON PIN (6 required per assembly) — Replaces: 52035
		53-857196 - Lock Ring - Priced Individually [ More info ] $3.39 $2.72 10+ In Stock.
#21	78816A12	RING PISTON (STANDARD) (1 required per assembly)
		39-78816A12 - Rings - 12 Pcs [ More info ] $213.25 2 In Stock.
		18-3902 - Rings, 39-78816A12, 3 Rings Only [ More info ] $49.79 1 In Stock.
#21	78811A12	RING SET PISTON - .015 OVERSIZE (AR required per assembly)
		39-78811A12 - Rings - 12 Pcs [ More info ] $53.88 10 In Stock.
#21	88392A12	RING SET PISTON - .030 OVERSIZE (AR required per assembly)
		39-88392A12 - Piston Rings 12 Pcs. [ More info ] $73.72 10+ In Stock.
#22	8101A3	CONNECTING ROD (3 required per assembly)
		624-8101A 3 - Connecting Rod, NLA [ More info ] $102.99 $87.23 10+ In Stock.
#23	54803	SCREW (.250-28 X 1.500) CAP TO CONNECTING ROD W/NUT (6 required per assembly)
		10-54803 - Screw, NLA [ More info ] $6.10 10 In Stock.
#23	91012	SCREW (.250-28 SPECIAL) CAP TO CONNECTING ROD W/O NUT (6 required per assembly)
		10-91012 - Screw - Special - Priced Individually [ More info ] $7.89 4 In Stock.
#24	49091	NUT CONNECTING ROD SCREW (6 required per assembly)
		11-49091 - Nut - Priced Individually [ More info ] Unavailable
#25	62596A1	BEARING ASSEMBLY (3 required per assembly)
		31-62596A 1 - Connecting Rod Bearings And Cage, Single [ More info ] $48.49 10+ In Stock.
		18-4038 - Needle Bearings, Without Cage, 31-62596A1 [ More info ] $52.49 $47.55 2 In Stock.
#26	47270	BEARING NEEDLE-PISTON PIN (87 required per assembly)
		29-47270 - Needle Bearing [ More info ] $0.40 10+ In Stock.
		18-4036-9 - Bearing, 29-47270, 200PK [ More info ] $52.63 Available to Order: Shipping delay up to 10 days.
		29-8M0214934 - BRG-NEEDLE @200 [ More info ] Unavailable
#27	8M0032839	WASHER @5 NEEDLE LOCATING (6 required per assembly) — Replaces: 47247
		12-8M0032839 - Washer - Priced Individually [ More info ] $11.29 $9.04 10+ In Stock.
