Parts for 40 Lightning (International) 2-Stroke Carbureted Mercury Outboard Motor Power Trim Components
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 851873A1 | POWER TRIM (1 required per assembly) |
  |
|
851873A 1 - POWER TRIM ASSEMB [ More info ] Unavailable |
| #1 | 8276751 | MOTOR (1 required per assembly) |
  |
|
827675 1 - Motor, NLA [ More info ] Unavailable |
| #2 | 8518662 | BOLT (3 required per assembly) |
  |
|
10-8518662 - BOLT NLA [ More info ] Unavailable |
| #3 | 9528620 | COLLAR (3 required per assembly) |
  |
|
23-95286 20 - Collar, NLA [ More info ]
|
| #4 | 827672A2 | RELIEF VALVE (DOWN) (1 required per assembly) |
  |
|
827672A 2 - VALVE-RELIEF,NLA [ More info ] Unavailable |
| #5 | 161314 | O-RING (1 required per assembly) |
  |
|
25-16131 4 - O-Ring [ More info ]
|
| #6 | 8276741 | PUMP (1 required per assembly) |
  |
|
8276741 - PUMP NLA [ More info ] Unavailable |
| #7 | 161314 | O-RING (2 required per assembly) |
| #8 | 8518663 | BOLT (1 required per assembly) |
  |
|
10-851866 3 - Bolt [ More info ]
|
| #9 | 8518664 | BOLT (2 required per assembly) |
  |
|
10-851866 4 - Bolt [ More info ]
|
| #10 | 851876 | FILTER (1 required per assembly) |
  |
|
851876 - FILTER [ More info ] Unavailable |
| #11 | 851877 | DRIVE JOINT (1 required per assembly) |
  |
|
851877 - Drive Joint [ More info ] Unavailable |
| #12 | 161315 | O-RING (1 required per assembly) |
  |
|
25-161315 - O RING [ More info ] Unavailable |
| #13 | 827672A3 | RELIEF VALVE (UP) (1 required per assembly) |
  |
|
827672A 3 - Relief Valve, NLA [ More info ] Unavailable |
| #14 | 8555541 | O-RING (1 required per assembly) |
  |
|
25-8555541 - O RING [ More info ] Unavailable |
| #15 | 161316 | O-RING (1 required per assembly) |
  |
|
25-161316 - O RING [ More info ] Unavailable |
| #16 | 851878 | FILTER (1 required per assembly) |
  |
|
851878 - Filter, NLA [ More info ] Unavailable |
| #17 | 851879A1 | VALVE SEAT ASSEMBLY (1 required per assembly) |
  |
|
851879A 1 - Valve Seat Assembly, NLA [ More info ] Unavailable |
| #18 | 161317 | O-RING (1 required per assembly) |
  |
|
25-161317 - O RING [ More info ] Unavailable |
| #19 | 161318 | O-RING (1 required per assembly) |
  |
|
25-161318 - O RING [ More info ] Unavailable |
| #20 | 851879A2 | VALVE SEAL ASSEMBLY (1 required per assembly) |
  |
|
851879A 2 - Valve Seat Assembly, NLA [ More info ] Unavailable |
| #21 | 161317 | O-RING (1 required per assembly) |
| #22 | 161318 | O-RING (1 required per assembly) |
| #23 | 851880 | SPOOL (1 required per assembly) |
  |
|
851880 - Spool, NLA [ More info ] Unavailable |
| #24 | 851881 | BACKUP RING (1 required per assembly) |
  |
|
851881 - Cover [ More info ] Unavailable |
| #25 | 851882 | SPRING (1 required per assembly) |
  |
|
24-851882 - Spring, NLA [ More info ] Unavailable |
| #26 | 827670T03 | SHOCK ROD (1 required per assembly) — Replaces: 827670A3 |
  |
|
827670T03 - SHOCK ROD NLA [ More info ] Unavailable |
| #27 | 8555542 | O-RING (1 required per assembly) |
  |
|
25-8555542 - O RING [ More info ] Unavailable |
| #28 | 8555543 | O-RING (1 required per assembly) |
  |
|
25-855554 3 - O-Ring [ More info ] Unavailable |
| #29 | 8518811 | BACKUP RING (1 required per assembly) |
  |
|
851881 1 - Back-up Ring, NLA [ More info ] Unavailable |
| #30 | 8276761 | PISTON (1 required per assembly) |
  |
|
827676 1 - Piston, NLA [ More info ] Unavailable |
| #31 | 8555543 | O-RING (1 required per assembly) |
| #32 | 8518811 | BACKUP RING (1 required per assembly) |
| #33 | 953929 | WASHER (2 required per assembly) |
  |
|
12-953929 - WASHER [ More info ] Unavailable |
| #34 | 9528618 | COLLAR (1 required per assembly) |
  |
|
23-9528618 - COLLAR [ More info ] Unavailable |
| #35 | 8518821 | SPRING (2 required per assembly) |
  |
|
24-8518821 - SPRING [ More info ] Unavailable |
| #36 | 161319 | O-RING (1 required per assembly) |
  |
|
25-161319 - O RING [ More info ] Unavailable |
| #37 | 8126411 | O-RING (1 required per assembly) |
  |
|
25-8126411 - O RING [ More info ] Unavailable |
| #38 | 8134421 | MANUAL VALVE (1 required per assembly) |
  |
|
813442 1 - Valve - Manual, NLA [ More info ] Unavailable |
| #39 | 953451 | C RING (1 required per assembly) |
  |
|
53-953451 - RING-C NLA [ More info ] Unavailable |
| #40 | 8555491 | PLUG (1 required per assembly) |
  |
|
19-855549 1 - Plug, NLA [ More info ]
|
| #41 | 1613110 | O-RING (1 required per assembly) |
  |
|
25-16131 10 - O-Ring [ More info ]
|
