Parts for 60 (3 Cyl.) 2-Stroke Carbureted Mercury Outboard Motor Carburetor Assembly
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 6071A53 | CARBURETOR, TOP (50) (2 required per assembly) — Replaces: 6071A47 |
  |
|
1379-6071A53 - Carburetor, TOP,NLA [ More info ] Unavailable |
| #1 | 6071A39 | REF POB 95-13 (60) (2 required per assembly) |
  |
|
1379-6071A39 - REF PARTSBU,NLA [ More info ] Unavailable |
| #2 | 6249 | JET MAIN (.096) VENT BOWL (2 required per assembly) |
  |
|
1399-6249 - Jet -.096 [ More info ]
|
| #3 | 192711 | NEEDLE AND SEAT INLET (2 required per assembly) — Replaces: 19271 |
  |
|
19271 1 - Valve Seat Kit [ More info ]
|
| #4 | NSS | NOT SOLD SEPARATE GASKET-INLET NEEDLE AND SEAT (2 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #5 | 52106A1 | VENTURI PLASTIC (2 required per assembly) |
  |
|
52106A 1 - Venturi Assembly [ More info ]
|
| #6 | NSS | NOT SOLD SEPARATE NOZZLE (2 required per assembly) |
| #7 | NSS | NOT SOLD SEPARATE INLET NEEDLE (2 required per assembly) |
| #8 | NSS | NOT SOLD SEPARATE SPRING-IDLE MIXTURE (2 required per assembly) |
| #9 | NSS | NOT SOLD SEPARATE PIN-FLOAT (6 required per assembly) |
| #10 | NSS | NOT SOLD SEPARATE LEVER-FLOAT (2 required per assembly) |
| #11 | 19273 | FLOAT (2 required per assembly) — Replaces: 6197 |
  |
|
19273 - Float Kit [ More info ] Unavailable |
| #12 | 9483 | BOWL FUEL (50) (2 required per assembly) |
  |
|
1395-9483 - FUEL BOWL,NLA [ More info ] Unavailable |
| #12 | 7835 | BOWL FUEL (60) (2 required per assembly) |
  |
|
1395-7835 - FUEL BOWL,NLA [ More info ] Unavailable |
| #13 | NSS | NOT SOLD SEPARATE GASKET-FUEL BOWL (2 required per assembly) |
| #14 | NSS | NOT SOLD SEPARATE SCREW-FUEL BOWL (2 required per assembly) |
| #15 | 6199 | PLUG MAIN JET (2 required per assembly) |
  |
|
1395-6199 - Plug [ More info ] Unavailable |
| #16 | 7831 | JET MAIN FUEL (.058) (50) (2 required per assembly) |
  |
|
1395-7831 - Jet -.058 [ More info ]
|
| #16 | 6207 | JET (.072) MAIN (60) (2 required per assembly) |
  |
|
1395-6207 - Jet -.072 [ More info ]
|
| #17 | NSS | NOT SOLD SEPARATE GASKET-MAIN JET PLUG (2 required per assembly) |
| #19 | NSS | NOT SOLD SEPARATE WELCH PLUG (9/16") (4 required per assembly) |
| #20 | 4807 | SHAFT THROTTLE (2 required per assembly) |
  |
|
1395-4807 - Throttle Shaft [ More info ]
|
| #21 | 9484 | VALVE THROTTLE (50) (2 required per assembly) |
  |
|
1395-9484 - THROTTLE Valve, NLA [ More info ] Unavailable |
| #21 | 7833 | VALVE THROTTLE (60) (2 required per assembly) |
  |
|
1395-7833 - Valve, NLA [ More info ] Unavailable |
| #22 | NSS | NOT SOLD SEPARATE SCREW-VALVE TO THROTTLE SHAFT (4 required per assembly) |
| #23 | 6204 | SEAL THROTTLE SHAFT (2 required per assembly) |
  |
|
1395-6204 - Carburetor Seal [ More info ]
|
| #24 | 6203 | WASHER THROTTLE SHAFT (2 required per assembly) |
  |
|
1395-6203 - Washer, Throttle Shaft, NLA [ More info ]
|
| #25 | NSS | NOT SOLD SEPARATE SPRING-THROTTLE RETURN (2 required per assembly) |
| #26 | 6198 | VALVE ASSEMBLY ENRICHMENT (2 required per assembly) |
  |
|
1395-6198 - Valve Assembly, NLA [ More info ] Unavailable |
| #27 | NSS | NOT SOLD SEPARATE SCREW-ENRICHMENT BRACKET (2 required per assembly) |
| #28 | NSS | NOT SOLD SEPARATE WELCH PLUG (7/16") (2 required per assembly) |
| #29 | 733771 | GASKET CARBURETOR (2 required per assembly) — Replaces: 73377 |
  |
|
27-73377 1 - Gasket [ More info ]
|
| #-- | 6200 | GASKET SET (2 required per assembly) |
  |
|
1395-6200 - Carburetor Gasket Kit [ More info ]
|
  |
|
18-7004 - Carburetor Kit 1395-6200 [ More info ]
|
  |
|
1300-00134 - CARB KIT MC [ More info ]
|
| #-- | 812953 | REPAIR KIT - CARB (2 required per assembly) — Replaces: 8982, 19274 |
  |
|
812953 - Carburetor Repair Kit [ More info ]
|
