Parts for 30 (2 Cyl.) (2-Stroke) (International) 2-Stroke Carbureted Mercury Outboard Motor Gear Housing Driveshaft

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > 30 (2 Cyl.) (2-Stroke) (International) > 0N055505 & Up - Belgium > Gear Housing Driveshaft

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gear Housing Driveshaft

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	825132T37	GEAR HOUSING SHRT Short (1 required per assembly) — Replaces: 825132A6, 825132T06
		1668-825132T37 - 1668-825132T37 - GEAR HOUSING SHRT [ More info ] Unavailable Replaced by 1668-8M0057250
		1668-8M0057250 - 1668-8M0057250 - GEAR HOUSING SHRT [ More info ] Unavailable Replaced by 1668-8M0070907
		16688M0070907 - Gearcase 25/30 2S SH [ More info ] Unavailable
#-	825132T28	GC 25-30 2S LG BL Long [0N079615] & Below (1 required per assembly) — Replaces: 825132A8, 825132A28
		1668-825132T28 - GC 25-30 2S LG BL [ More info ] Unavailable
		1668-825132T38 - 1668-825132T38 - GC 25-30 2S LG BL [ More info ] Unavailable Replaced by 1668-8M0057251
		1668-8M0057251 - 1668-8M0057251 - GC 25-30 2S LG BL [ More info ] Unavailable Replaced by 1668-8M0070908
		16688M0070908 - Gearcase 25/30 2S LG [ More info ] Unavailable
#-	825132T38	GC 25-30 2S LG BL Long [0N079616] & Up (1 required per assembly) — Replaces: 825132A28, 825132T28
#-	853792T01	REPAIR KIT W/P (1 required per assembly) — Replaces: 853792A1
		853792T01 - Water Pump Repair Kit [ More info ] $70.49 Available to Order: Shipping delay up to 10 days.
#-	853792A2	CHROME W/P KIT (1 required per assembly)
		853792A 2 - Chrome Water Pump Kit [ More info ] Unavailable
#-	8M0089639	GASKET SET-L/U (1 required per assembly) — Replaces: 95220A1
		27-8M0089639 - Gasket Set - L/U [ More info ] $34.49 Available to Order: Shipping delay up to 10 days.
#1	825132T29	GEAR HSG.-BAS.BLA (1 required per assembly) — Replaces: 825132A4, 825132T04
		1668-825132T29 - Gear Housing.-BAS.BLA [ More info ] Unavailable
		1668-825132T34 - Gear Housing Basic [ More info ] Unavailable
		16688M0057242 - Gearcase Basic 25/30 4S [ More info ] $740.49 Available to Order: Shipping delay up to 10 days.
#2	813048006	BEARING (1 required per assembly) — Replaces: 8130484
		31-813048006 - Bearing [ More info ] $68.99 Available to Order: Shipping delay up to 10 days.
#3	953683	PLUG (2 required per assembly)
		22-95368 3 - Oil Plug [ More info ] Unavailable
		22-8M0229353 - PLUG [ More info ] $10.89 1 In Stock.
#4	8M0082880	SEAL KIT DRAIN PLUG (2 required per assembly) — Replaces: 95220
		8M0082880 - Seal - Priced Individually [ More info ] $6.09 10+ In Stock.
		18-60103 - Gasket, Drain Plug 332600060M [ More info ] $1.99 $1.70 Available to Order: Shipping delay up to 10 days.
#5	853763	STRAINER SET WATER (1 required per assembly)
		853763 - Strainer Set [ More info ] $29.49 Available to Order: Shipping delay up to 10 days.
#6	879194326	SCREW (1 required per assembly) — Replaces: 898101165
		10-879194326 - Screw [ More info ] $7.09 Available to Order: Shipping delay up to 10 days.
#7	85372210	NUT (1 required per assembly)
		11-853722 10 - Nut [ More info ] $8.79 Available to Order: Shipping delay up to 10 days.
#8	16133	STRAINER WATER (1 required per assembly)
		16133 - Water Strainer [ More info ] $20.79 Available to Order: Shipping delay up to 10 days.
#9	898101959	SCREW (1 required per assembly) — Replaces: 823042051, 879194324
		10-898101959 - Screw [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#10	853762	TRIM TAB (1 required per assembly)
		853762 - Trim Tab [ More info ] $26.59 Available to Order: Shipping delay up to 10 days.
#11	167051	BOLT (M6 X 20) (1 required per assembly)
		10-16705 1 - Bolt [ More info ] $6.09 Available to Order: Shipping delay up to 10 days.
#12	898103166	CLUTCH CAM (1 required per assembly) — Replaces: 161722, 898101028
		898103166 - Clutch Cam [ More info ] Unavailable
		8M0172382 - Clutch CAM [ More info ] $63.49 Available to Order: Shipping delay up to 10 days.
#13	161732	CAM ROD Short (1 required per assembly)
		16173 2 - Cam ROD-Short [ More info ] $24.29 Available to Order: Shipping delay up to 10 days.
#13	161742	CAM ROD Long (1 required per assembly)
		0161742 [ More info ] Unavailable Replaced by 0161647
		[ More info ] Unavailable
#13	161743	CAM ROD X-Long (1 required per assembly)
		16174 3 - Cam ROD [ More info ] $32.17 Available to Order: Shipping delay up to 10 days.
#13	161744	CAM ROD XX-Long (1 required per assembly)
		[ More info ] Unavailable
#14	16179	PIN (2 required per assembly)
		17-16179 - Pin [ More info ] $2.69 Available to Order: Shipping delay up to 10 days.
#15	161762	BUSHING (1 required per assembly)
		23-16176 2 - Bushing [ More info ] $28.99 Available to Order: Shipping delay up to 10 days.
#16	161772	O-RING (1 required per assembly)
		[ More info ] Unavailable
#17	161782	O-RING (1 required per assembly)
		0161782 [ More info ] Unavailable Replaced by 0161911
		[ More info ] Unavailable
#18	8230427	BOLT ASSEMBLY (M6 X 12) (1 required per assembly) — Replaces: 162111, 8M0088179
		10-823042 7 - Bolt [ More info ] $4.09 $2.30 10+ In Stock.
#19	953921	WASHER STAINLESS STEEL (1 required per assembly) — Replaces: 895118002
		12-95392 1 - Washer [ More info ] $5.59 Available to Order: Shipping delay up to 10 days.
#20	853794	RETAINER XX-Long (1 required per assembly)
		853794 - Retainer [ More info ] $3.29 Available to Order: Shipping delay up to 10 days.
#21	85372211	NUT (1 required per assembly)
		11-853722 11 - Nut, Pinion [ More info ] $22.39 Available to Order: Shipping delay up to 10 days.
#22	16138T01	GEAR PINION (12 TEETH) (1 required per assembly)
		43-16138T01 - Gear, Pinion (12 Teeth) [ More info ] $158.99 Available to Order: Shipping delay up to 10 days.
#23	8126454	SPRING (1 required per assembly)
		24-812645 4 - Spring [ More info ] $9.39 Available to Order: Shipping delay up to 10 days.
#24	853765T	GUIDE (1 required per assembly) — Replaces: 853765
		853765T - Guide [ More info ] $13.59 Available to Order: Shipping delay up to 10 days.
#25	161352	DRIVESHAFT Short (1 required per assembly)
		45-16135 2 - Drive Shaft - Short [ More info ] $331.49 Available to Order: Shipping delay up to 10 days.
#25	16136T02	DRIVESHAFT LONG Long (1 required per assembly) — Replaces: 161362
		45-16136T02 - Drive Shaft - Long [ More info ] $747.49 Available to Order: Shipping delay up to 10 days.
#25	161363	DRIVESHAFT X-Long (1 required per assembly)
		45-16136 3 - Drive Shaft-XL [ More info ] $290.99 Available to Order: Shipping delay up to 10 days.
#25	161364	DRIVESHAFT XX-Long (1 required per assembly)
		45-16136 4 - Drive Shaft-XXL [ More info ] $155.99 Available to Order: Shipping delay up to 10 days.
#26	161551	KEY (1 required per assembly)
		0161551 [ More info ] Unavailable Replaced by 0112379
		0112379 - Mount (112379) [ More info ] Unavailable
#27	16128T02	BEARING ASSEMBLY (1 required per assembly) — Replaces: 161282
		30-16128T02 - Bearing [ More info ] $77.49 Available to Order: Shipping delay up to 10 days.
#28	813276001	SHIM (0.1) (AR required per assembly)
		15-813276001 - Shim [ More info ] $9.49 Available to Order: Shipping delay up to 10 days.
#28	813276015	SHIM (0.15) (AR required per assembly)
		15-813276015 - Shim (.15) [ More info ] $9.39 Available to Order: Shipping delay up to 10 days.
#28	813276003	SHIM (0.3) (AR required per assembly)
		15-813276003 - Shim (.3) [ More info ] $8.99 Available to Order: Shipping delay up to 10 days.
#28	813276005	SHIM (0.5) (AR required per assembly)
		15-813276005 - Shim (.5) [ More info ] $5.29 Available to Order: Shipping delay up to 10 days.
#29	161622	SEAL OIL (1 required per assembly)
		26-16162 2 - Oil Seal [ More info ] $19.37 3 In Stock.
#30	8537096	O-RING (1 required per assembly)
		25-853709 6 - O-Ring [ More info ] $5.69 3 In Stock.
#31	952188	PIN DOWEL (2 required per assembly)
		17-95218 8 - Dowel Pin [ More info ] $13.79 Available to Order: Shipping delay up to 10 days.
#32	8260531	HOUSING WATER PUMP (1 required per assembly)
		46-826053 1 - Water Pump Housing [ More info ] $53.49 Available to Order: Shipping delay up to 10 days.
#33	161602	GASKET (1 required per assembly)
		27-16160 2 - Gasket [ More info ] $8.79 Available to Order: Shipping delay up to 10 days.
#34	161592	WEAR PLATE (1 required per assembly)
		0161592 - L/P 4.95 [ More info ] Unavailable
#35	161582	GASKET (1 required per assembly)
		27-16158 2 - Gasket [ More info ] $3.19 $2.56 10+ In Stock.
#36	16154 1	IMPELLER (1 required per assembly)
		47-16154 1 - Impeller [ More info ] Unavailable
		47-8M0214912 - Mercury Water Pump Impeller 25/30HP EFI 4STROKE [ More info ] $33.99 4 In Stock.
#37	161572	INSERT (1 required per assembly)
		16157 2 - Insert [ More info ] $16.79 Available to Order: Shipping delay up to 10 days.
#38	161562	HOUSING UPPER WATER PUMP (1 required per assembly)
		0161562 - Part (161562) [ More info ] Unavailable
#39	823042046	BOLT (4 required per assembly)
		10-823042046 - Bolt [ More info ] Unavailable
		10-879194269 - Bolt [ More info ] $6.09 Available to Order: Shipping delay up to 10 days.
#40	161681	SEAL (1 required per assembly)
		26-16168 1 - Seal [ More info ] $8.89 3 In Stock.
