Parts for 250 / 275 2-Stroke Carbureted Mercury Outboard Motor Carburetor Assembly
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 9482 | REPAIR KIT - CARB (1 required per assembly) |
  |
|
1395-9482 - Carburetor Repair Kit,NLA [ More info ] Unavailable |
| #- | 9062 | GASKET SET (1 required per assembly) |
  |
|
1395-9062 - Carburetor Gasket Set [ More info ] Unavailable |
| #- | 88605A89 | GASKET SET (1 required per assembly) |
  |
|
27-88605A89 - Gasket Set [ More info ]
|
| #1 | 7785A55 | CARBURETOR ASSEMBLY (9-1) 275-WO-9/9A (1 required per assembly) |
  |
|
1387-7785A55 - Carburetor [ More info ] Unavailable |
| #1 | 7785A56 | CARBURETOR ASSEMBLY (9-2) 275-WO-9/9A (1 required per assembly) |
  |
|
1387-7785A56 - Carburetor [ More info ] Unavailable |
| #1 | 7785A57 | CARBURETOR ASSEMBLY (9-3) 275-WO-9/9A (1 required per assembly) |
  |
|
1387-7785A57 - Carburetor [ More info ] Unavailable |
| #1 | 7785A58 | CARBURETOR ASSEMBLY (9-4) 275-WO-9/9A (1 required per assembly) |
  |
|
1387-7785A58 - Carburetor [ More info ] Unavailable |
| #1 | 7785A59 | CARBURETOR ASSEMBLY (9-5) 275-WO-9/9A (1 required per assembly) |
  |
|
1387-7785A59 - Carburetor [ More info ] Unavailable |
| #1 | 7785A60 | CARBURETOR ASSEMBLY (9-6) 275-WO-9/9A (1 required per assembly) |
  |
|
1387-7785A60 - Carburetor [ More info ] Unavailable |
| #1 | 7785A61 | CARBURETOR ASSEMBLY (8-1) 250-WO-8A (1 required per assembly) |
  |
|
1387-7785A61 - Carburetor [ More info ] Unavailable |
| #1 | 7785A62 | CARBURETOR ASSEMBLY (8-2) 250-WO-8A (1 required per assembly) |
  |
|
1387-7785A62 - Carburetor [ More info ] Unavailable |
| #1 | 7785A63 | CARBURETOR ASSEMBLY (8-3) 250-WO-8A (1 required per assembly) |
  |
|
1387-7785A63 - Carburetor [ More info ] Unavailable |
| #1 | 7785A64 | CARBURETOR ASSEMBLY (8-4) 250-WO-8A (1 required per assembly) |
  |
|
1387-7785A64 - Carburetor [ More info ] Unavailable |
| #1 | 7785A65 | CARBURETOR ASSEMBLY (8-5) 250-WO-8A (1 required per assembly) |
  |
|
1387-7785A65 - Carburetor [ More info ] Unavailable |
| #1 | 7785A66 | CARBURETOR ASSEMBLY (8-6) 250-WO-8A (1 required per assembly) |
  |
|
1387-7785A66 - Carburetor [ More info ] Unavailable |
| #2 | 6201 | JET (.080) VENT BOWL (WO-8A) (6 required per assembly) |
  |
|
1395-6201 - Jet -.080 - Priced Individually [ More info ]
|
| #3 | NSS | NOT SOLD SEPARATE GASKET (6 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #4 | 9122 | COVER PLATE (6 required per assembly) |
  |
|
1395-9122 - PLATE,NLA [ More info ] Unavailable |
| #5 | NSS | NOT SOLD SEPARATE SCREW (24 required per assembly) |
| #6 | 813274 | VENTURI (WO-8A) (6 required per assembly) |
  |
|
813274 - VENTURI,NLA [ More info ] Unavailable |
| #6 | 9481 | VENTURI (WO-9/9A) (6 required per assembly) |
  |
|
1395-9481 - VENTURI,NLA [ More info ] Unavailable |
| #7 | 9478 | BOWL FUEL (WO-8A-2/3/4/5/6)(WO-9/9A-2/4/6) (5 required per assembly) |
  |
|
1395-9478 - FUEL BOWL,NLA [ More info ] Unavailable |
| #8 | NSS | NOT SOLD SEPARATE SCREW (24 required per assembly) |
| #9 | 6199 | PLUG MAIN JET (6 required per assembly) |
  |
|
1395-6199 - Plug [ More info ] Unavailable |
| #10 | NSS | NOT SOLD SEPARATE GASKET, MAIN JET (6 required per assembly) |
| #11 | 6680 | JET (.078) MAIN FUEL (WO-8A-1/2/3/4/6) (5 required per assembly) |
  |
|
1395-6680 - Jet -.078 [ More info ]
|
| #11 | 3517 | JET (.084) MAIN FUEL (WO-8A-5) (1 required per assembly) |
  |
|
1399-3517 - Jet -.084 [ More info ]
|
| #11 | 6202 | JET MAIN MAIN FUEL (.088-WO-9/9A-5) (1 required per assembly) |
  |
|
1395-6202 - Jet -.088 [ More info ] Unavailable |
| #11 | 3518 | JET (.082) MAIN FUEL (WO-9/9A-1/2/3/4/6) (5 required per assembly) |
  |
|
1399-3518 - Jet -.082 [ More info ]
|
| #12 | NSS | NOT SOLD SEPARATE GASKET, FUEL BOWL (6 required per assembly) |
| #13 | 813470 | FLOAT (6 required per assembly) |
  |
|
813470 - Float, NLA [ More info ] Unavailable |
| #14 | NSS | NOT SOLD SEPARATE FLOAT PIN (6 required per assembly) |
| #15 | NSS | NOT SOLD SEPARATE FLOAT LEVER (6 required per assembly) |
| #16 | NSS | NOT SOLD SEPARATE PIN (6 required per assembly) |
| #17 | NSS | NOT SOLD SEPARATE MAIN NOZZLE (6 required per assembly) |
| #18 | 83181 | VALVE SEAT KIT (6 required per assembly) — Replaces: 8318 |
  |
|
1395-8318 1 - Valve Seat Kit [ More info ]
|
  |
|
18-7061 - Needle And Seat 1395-8318 [ More info ]
|
| #19 | NSS | NOT SOLD SEPARATE GASKET (6 required per assembly) |
| #20 | 9118 | SHAFT THROTTLE (WO-8A-5)(WO-9/9A-5) (1 required per assembly) |
  |
|
1395-9118 - Throttle Shaft,NLA [ More info ] Unavailable |
| #20 | 9117 | SHAFT THROTTLE (5 required per assembly) |
  |
|
1395-9117 - Throttle Shaft,NLA [ More info ] Unavailable |
| #21 | 814679 | LEVER (QTY. OF 5 ON WO-8A) (6 required per assembly) |
  |
|
814679 - Throttle Lever, NLA [ More info ] Unavailable |
| #21 | 814677 | LEVER THROTTLE (WO-8A-5) (1 required per assembly) |
  |
|
814677 - Throttle Lever, NLA [ More info ] Unavailable |
| #22 | NSS | NOT SOLD SEPARATE SCREW (6 required per assembly) |
| #23 | NSS | NOT SOLD SEPARATE SPRING (6 required per assembly) |
| #24 | NSS | NOT SOLD SEPARATE SPACER (6 required per assembly) |
| #25 | 9480 | VALVE THROTTLE (6 required per assembly) |
  |
|
1395-9480 - THROTTLE Valve, NLA [ More info ]
|
| #26 | NSS | NOT SOLD SEPARATE SCREW (12 required per assembly) |
| #27 | 886111 | GASKET (6 required per assembly) |
  |
|
27-88611 1 - Gasket [ More info ]
|
| #28 | NSS | NOT SOLD SEPARATE PLUG, IDLE AIR JET (6 required per assembly) |
| #29 | NSS | NOT SOLD SEPARATE GASKET (6 required per assembly) |
| #30 | 6487 | JET MAIN (.060) IDLE (WO-8A/9A) (6 required per assembly) |
  |
|
1395-6487 - Jet -.060 [ More info ]
|
| #30 | 7831 | JET MAIN FUEL (.058) IDLE (WO-9) (6 required per assembly) |
  |
|
1395-7831 - Jet -.058 [ More info ]
|
