Parts for 50, 500 (4 Cyl.) 2-Stroke Carbureted Mercury Outboard Motor Carburetor Assembly (Tillotson)

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > 50, 500 (4 Cyl.) > 5531630 & Up - USA > Carburetor Assembly (Tillotson)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Carburetor Assembly (Tillotson)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	5198	GASKET SET (2 required per assembly)
		1399-5198 - Carburetor Gasket Set [ More info ] $17.69 Available to Order: Shipping delay up to 10 days.
		18-7007 - Carburetor Gasket Kit 1399-5135 or 1399-5198 [ More info ] $13.01 10+ In Stock.
		1300-36005 - Carburetor Gasket Kit [ More info ] $9.99 $9.40 Available to Order: Shipping delay up to 10 days.
#-	51991	REPAIR KIT-CARB [USA-5796396/Aus-8069215/Bel-9291996/Can-7165753] & Up (2 required per assembly) — Replaces: 9270, 8307
		1399-5199 1 - Carburetor Repair Kit [ More info ] $118.78 2 In Stock.
		18-97353 - Carb Kit, Mercury 1399-51991 [ More info ] $115.95 $113.03 10+ In Stock.
		1399-8307 - Carburetor Repair Kit [ More info ] $48.70 1 In Stock.
#-	5137	DIAPH/GASKET KIT (2 required per assembly)
		1399-5137 - Diaphragm/Gasket Kit [ More info ] $16.99 7 In Stock.
		18-7815 - Fuel Pump Kit, 1399-5137 [ More info ] $13.58 10+ In Stock.
#1	6517A25	CARBURETOR (ELECTRIC) (2 required per assembly) — Replaces: 6517A14, 6517A21, 6517A8
		1367-6517A25 - Carburetor [ More info ] Unavailable
		1367-6517A28 - Carburetor [ More info ] Unavailable
		1367-6517A57 - Carburetor [ More info ] Unavailable
		1367-6517A61 - Carburetor [ More info ] Unavailable
#2	NSS	NOT SOLD SEPARATE WELCH PLUG, BODY CHANNEL (LARGE) (2 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#3	NSS	NOT SOLD SEPARATE PLUG, BODY CHANNEL (6 required per assembly)
#4	9296A1	CHOKE SHAFT KIT (2 required per assembly) — Replaces: 96773A1
		1395-9296A 1 - Choke Shaft Kit, NLA [ More info ] Unavailable
#5	NSS	NOT SOLD SEPARATE SPRING, RETURN - THROTTLE SHAFT (2 required per assembly)
#6	NSS	NOT SOLD SEPARATE MAIN NOZZLE (NLA Per Service Bulletin 88-12) (2 required per assembly)
#7	814483	BAFFLE FUEL BOWL FUEL BOWL (2 required per assembly) — Replaces: 7211A1
		814483 - Baffle , NLA [ More info ] Unavailable
#8	9293	FLOAT (2 required per assembly)
		1395-9293 - Float Assembly [ More info ] $27.23 10 In Stock.
		18-7209 - Float 1395-9293 [ More info ] $20.92 10 In Stock.
#9	NSS	NOT SOLD SEPARATE PIN, FLOAT RETAINING (2 required per assembly)
#10	5127	BOWL FUEL (2 required per assembly)
		1399-5127 - Fuel Bowl, NLA [ More info ] Unavailable
#11	NSS	NOT SOLD SEPARATE GASKET, FUEL BOWL (2 required per assembly)
#12	5415	SCREW FUEL BOWL TO CARBURETOR (2 required per assembly)
		1399-5415 - Screw, NLA [ More info ] Unavailable
#13	NSS	NOT SOLD SEPARATE GASKET, FUEL BOWL SCREW (4 required per assembly)
#14	9022	NEEDLE AND SPRING INLET (2 required per assembly)
		1395-9022 - Inlet Needle [ More info ] $12.19 8 In Stock.
		18-7295 - Needle Valve, 1395-9022 [ More info ] $9.33 10+ In Stock.
#15	1655	JET MAIN FUEL (.055) (2 required per assembly)
		1399-1655 - Jet -.055, NLA [ More info ] $21.54 10+ In Stock.
#16	6249	JET MAIN (.096) [USA-5796395/Aus-8069214/Bel-9291995/Can-7165752] & Below (2 required per assembly)
		1399-6249 - Jet -.096 [ More info ] $15.99 8 In Stock.
#16	5733	JET MAIN (.092) [USA-5796396/Aus-8069215/Bel-9291996/Can-7165753] & Up (2 required per assembly)
		1395-5733 - Jet -.092 [ More info ] $4.09 6 In Stock.
#17	64677	VENTURI (2 required per assembly)
		64677 - Venturi [ More info ] $10.19 8 In Stock.
#18	5194	VALVE CHOKE RELIEF - ELECTRIC (2 required per assembly)
		1399-5194 - Relief Valve, NLA [ More info ] Unavailable
#19	5414	SPRING CHOKE RELIEF VALVE - ELECTRIC (2 required per assembly)
		1399-5414 - SPRING,NLA [ More info ] Unavailable
#20	5197	SHUTTER CHOKE (ELECTRIC) (2 required per assembly)
		1399-5197 - CHOKE SHUTTER,NLA [ More info ] Unavailable
#20	8665	SHUTTER CHOKE (MANUAL) (2 required per assembly)
		1399-8665 - Choke Shutter [ More info ] $2.50 $2.13 10+ In Stock.
#21	N.S.S.	NOT SOLD SEPARATE CHOKE SHUTTER (TILLOTSON #25B-312) (4 required per assembly)
		N.S.S. - Not Sold Separate [ More info ] Unavailable
#22	NSS	NOT SOLD SEPARATE SCREW, IDLE MIXTURE (2 required per assembly)
#23	NSS	NOT SOLD SEPARATE SPRING, IDLE MIXTURE SCREW (2 required per assembly)
#24	NSS	NOT SOLD SEPARATE GASKET, FUEL PUMP DIAPHRAGM (2 required per assembly)
#25	NSS	NOT SOLD SEPARATE DIAPHRAGM, FUEL PUMP (2 required per assembly)
#26	5129	BODY FUEL PUMP (2 required per assembly)
		1399-5129 - Fuel Pump Body, NLA [ More info ] Unavailable
#27	NSS	NOT SOLD SEPARATE GASKET, FUEL PUMP ATTACHING (2 required per assembly)
#28	NSS	NOT SOLD SEPARATE DIAPHRAGM, FUEL PUMP (2 required per assembly)
#29	5131	BODY STRAINER (2 required per assembly)
		1399-5131 - Strainer Body, NLA [ More info ] Unavailable
#30	808612	SCREW AND WASHER (#8-32 X .750) STRAINER BODY TO CARBURETOR (8 required per assembly) — Replaces: 5132
		1395-808612 - Screw & Washer [ More info ] $2.69 10+ In Stock.
#31	5758	SCREEN STRAINER (2 required per assembly)
		1399-5758 - Screen [ More info ] $6.79 7 In Stock.
#32	5207	GASKET STRAINER COVER (2 required per assembly)
		1399-5207 - Fuel Pump Gasket [ More info ] $5.39 8 In Stock.
#33	99941	COVER INLET (2 required per assembly) — Replaces: 4236
		99941 - Cover [ More info ] $13.39 8 In Stock.
#34	NSS	NOT SOLD SEPARATE SCREW, STRAINER COVER TO BODY (2 required per assembly)
#35	2012	SHAFT THROTTLE (2 required per assembly)
		1399-2012 - Throttle Shaft [ More info ] $17.78 $15.06 10+ In Stock.
#36	74371	LEVER THROTTLE (UPPER CARBURETOR) (1 required per assembly)
		74371 - Lever [ More info ] Unavailable
#36	8146791	LEVER THROTTLE THROTTLE (LOWER CARBURETOR) (1 required per assembly) — Replaces: 97
		814679 1 - Throttle Lever [ More info ] $9.58 10 In Stock.
#37	6027	SCREW THROTTLE LEVER ATTACHING (2 required per assembly) — Replaces: 20847
		1395-6027 - Screw [ More info ] Unavailable
#38	NSS	NOT SOLD SEPARATE IDLE TUBE (NLA Per Service Bulletin 88-12) (2 required per assembly)
#39	NSS	NOT SOLD SEPARATE GASKET, IDLE TUBE (2 required per assembly)
#40	6225	SHUTTER THROTTLE (2 required per assembly)
		1399-6225 - Throttle Shutter [ More info ] Unavailable
#41	NSS	NOT SOLD SEPARATE SCREW, THROTTLE SHUTTER TO THROTTLE SHAFT (4 required per assembly)
#42	757911	GASKET (2 required per assembly) — Replaces: 75791
		27-75791 1 - Gasket [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#43	64809	NUT CARBURETOR MOUNTING STUD (4 required per assembly)
		11-64809 - Nut (5/16 In.) [ More info ] Unavailable
