Parts for 50 (3 Cyl.) 2-Stroke Carbureted Mercury Outboard Motor Carburetor
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 812867A97 | GASKET SET (1 required per assembly) |
  |
|
27-812867A97 - Engine Overhaul Gasket Set [ More info ]
|
| #- | 8236354 | REPAIR KIT-CARB (1 required per assembly) |
  |
|
1395-823635 4 - Carburetor Repair Kit [ More info ]
|
| #- | 8112231 | GASKET KIT (1 required per assembly) |
  |
|
1395-811223 1 - Gasket Kit [ More info ]
|
  |
|
18-7211-1 - Carburetor Kit, 1395-811223 1 [ More info ]
|
  |
|
1300-03641 - Carburetor Gasket Kit Mercury Mariner [ More info ]
|
| #1 | 821679T17 | CARBURETOR (TOP) 50 - WME-43 (1 required per assembly) — Replaces: 821679A17 |
  |
|
3301-821679T17 - Carburetor, NLA [ More info ] Unavailable |
| #1 | 821679T18 | CARBURETOR (CENTER) 50 - WME-43 (1 required per assembly) — Replaces: 821679A18 |
  |
|
3301-821679T18 - Carburetor, NLA [ More info ] Unavailable |
| #1 | 821679T19 | CARBURETOR (BOTTOM) 50 - WME-43 (1 required per assembly) — Replaces: 821679A19 |
  |
|
3301-821679T19 - Carburetor, NLA [ More info ] Unavailable |
| #1 | 821946A45 | CARBURETOR KIT (TOP) 55/60 SEAPRO/MARATHON WME-44 (1 required per assembly) — Replaces: 821946A24, 821946T24 |
  |
|
3301-821946A45 - Carburetor Kit [ More info ] Unavailable |
| #1 | 821946A46 | CARBURETOR KIT (CENTER) 55/60 SEAPRO/MARATHON WME-44 (1 required per assembly) — Replaces: 821946A25, 821946T25 |
  |
|
3301-821946A46 - Carburetor Kit [ More info ] Unavailable |
| #1 | 821946A47 | CARBURETOR KIT (BOTTOM) 55/60 SEAPRO/MARATHON WME-44 (1 required per assembly) — Replaces: 821946A26, 821946T26 |
  |
|
3301-821946A47 - Carburetor Kit [ More info ] Unavailable |
| #1 | 821946T42 | CARBURETOR (TOP) 60 - WME-45 FORMULA/MAGNUM III BEACHING/PONTOON/BIG FOOT (1 required per assembly) — Replaces: 821946A27, 821946T27 |
  |
|
3301-821946T42 - Carburetor [ More info ]
|
| #1 | 821946T43 | CARBURETOR (CENTER) 60 - WME-45 FORMULA/MAGNUM III BEACHING/PONTOON/BIG FOOT (1 required per assembly) — Replaces: 821946A28, 821946T28 |
  |
|
3301-821946T43 - Carburetor [ More info ]
|
| #1 | 821946T44 | CARBURETOR (BOTTOM) 60 - WME-45 FORMULA/MAGNUM III BEACHING/PONTOON/BIG FOOT (1 required per assembly) — Replaces: 821946A29, 821946T29 |
  |
|
3301-821946T44 - Carburetor [ More info ]
|
| #2 | 823634 | SCREW (UPPER/BOTTOM) (2 required per assembly) |
  |
|
1395-823634 - Screw, NLA [ More info ]
|
| #3 | 823632 | SHAFT THROTTLE (UPPER/BOTTOM) WME-44 (2 required per assembly) |
  |
|
1395-823632 - Throttle Shaft [ More info ]
|
| #4 | 823633 | SHAFT THROTTLE (CENTER) WME-44 (1 required per assembly) |
  |
|
1395-823633 - Throttle Shaft [ More info ]
|
| #4 | 823636 | SHAFT THROTTLE (BOTTOM) 50/60 (1 required per assembly) |
  |
|
1395-823636 - Throttle Shaft [ More info ]
|
| #5 | NSS | NOT SOLD SEPARATE SPRING-THROTTLE RETURN (3 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #6 | 6247 | JET MAIN (.090) (50/60) (3 required per assembly) |
  |
|
1395-6247 - Jet -.090 [ More info ]
|
| #7 | NSS | NOT SOLD SEPARATE IDLE NEEDLE (3 required per assembly) |
| #8 | NSS | NOT SOLD SEPARATE SPRING-IDLE NEEDLE (3 required per assembly) |
| #9 | NSS | NOT SOLD SEPARATE GASKET-COVER PLATE (3 required per assembly) |
| #10 | 811221 | COVER PLATE (3 required per assembly) |
  |
|
1395-811221 - Cover Plate [ More info ]
|
| #11 | 811220 | SCREW COVER PLATE (6 required per assembly) |
  |
|
1395-811220 - Screw [ More info ]
|
| #12 | 8144461 | GASKET FLANGE (3 required per assembly) |
  |
|
27-814446 1 - Gasket [ More info ]
|
| #13 | 8113522 | LEVER OIL PUMP (WME43/45 - BOTTOM) (1 required per assembly) |
  |
|
1395-811352 2 - Lever [ More info ] Unavailable |
| #14 | 8086121 | SCREW LEVER RETAINER (WME43/45 - BOTTOM) (1 required per assembly) |
  |
|
1395-808612 1 - Screw, NLA [ More info ]
|
| #15 | F10155 | SCREW THROTTLE VALVE (6 required per assembly) |
  |
|
10-F10155 - Screw [ More info ]
|
| #16 | 879194023 | VALVE-THROTTLE (3 required per assembly) |
  |
|
1395-879194023 - Throttle Valve [ More info ] Unavailable |
| #17 | NSS | NOT SOLD SEPARATE RETAINING RING (3 required per assembly) |
| #18 | F10064 | SHAFT (3 required per assembly) |
  |
|
F10064 - Float Support Shaft [ More info ]
|
| #19 | NSS | NOT SOLD SEPARATE GASKET-NOZZLE WELL (3 required per assembly) |
| #20 | NSS | NOT SOLD SEPARATE GASKET-FUEL BOWL (3 required per assembly) |
| #21 | 879194011 | VALVE INLET (3 required per assembly) |
  |
|
1395-879194011 - Inlet Valve [ More info ]
|
| #22 | 9594 | FLOAT (3 required per assembly) |
  |
|
1395-9594 - Float [ More info ]
|
  |
|
18-72000 - Float, 1395-9594 [ More info ]
|
| #23 | 808612 | SCREW AND WASHER (#8-32 X .750) (12 required per assembly) |
  |
|
1395-808612 - Screw & Washer [ More info ]
|
| #24 | 811695 | BOWL FUEL (UPPER) (1 required per assembly) |
  |
|
1395-811695 - Fuel Bowl [ More info ]
|
| #24 | 811693 | BOWL FUEL (CENTER/BOTTOM) (2 required per assembly) |
  |
|
1395-811693 - Fuel Bowl, See detail page for important information [ More info ]
|
| #25 | 811694 | PLUG KIT (3 required per assembly) |
  |
|
1395-811694 - Bowl Drain Plug Kit [ More info ]
|
| #26 | NSS | NOT SOLD SEPARATE SEAL-BOWL DRAIN (3 required per assembly) |
| #27 | 6246 | JET (.048) (50) (3 required per assembly) |
  |
|
1395-6246 - Jet -.048 [ More info ]
|
| #27 | 6487 | JET MAIN (.060) (55/60 SEAPRO/MARATHON/PONTOON) (3 required per assembly) |
  |
|
1395-6487 - Jet -.060 [ More info ]
|
| #27 | 4217 | JET MAIN (.062) (60) (3 required per assembly) |
  |
|
1399-4217 - Jet -.062 [ More info ]
|
