Parts for 45 Jet 2-Stroke Carbureted Mercury Outboard Motor Clamp Bracket (Manual)
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 8M0084195 | BRACKET-CLAMP-BLK (Black-Port) (1 required per assembly) — Replaces: 822868A1 |
  |
|
34208M0084195 - Bracket-Clamp-BLK [ More info ]
|
| #2 | 8M0169588 | FITTING (1 required per assembly) — Replaces: 98727 |
  |
|
22-8M0169588 - FITTING [ More info ] Unavailable |
| #3 | 99604 | PIN GROOVE (1 required per assembly) |
  |
|
17-99604 - Pin, Groove [ More info ]
|
| #4 | 822867F1 | BRACKET-CLAMP-BLK (Black) (1 required per assembly) |
  |
|
3419-822867F 1 - Clamp Bracket [ More info ]
|
| #5 | 893704T01 | TILT LOCK LEVER-PAINT (Black) (1 required per assembly) — Replaces: 19618A2 |
  |
|
893704T01 - Tilt Lock Lever [ More info ]
|
| #6 | 99622 | SPRING (1 required per assembly) |
  |
|
24-99622 - Spring, Tilt Lock Tension [ More info ]
|
| #7 | 65830 | NYLINER (1 required per assembly) |
  |
|
23-65830 - NyLiner [ More info ]
|
| #8 | 812708 | SPRING (1 required per assembly) |
  |
|
24-812708 - Spring [ More info ]
|
| #9 | 812709 | KNOB (Black) (1 required per assembly) — Replaces: 812709T |
  |
|
|
| #10 | 99615 | PIN-GROOVE (1 required per assembly) |
  |
|
17-99615 - Pin, Groove [ More info ]
|
| #11 | 19619 | WASHER (2 required per assembly) |
  |
|
12-19619 - Washer [ More info ]
|
| #12 | 18486A08 | ANCHOR BRACKET KIT-PAINT (Black) (1 required per assembly) — Replaces: 18486F5 |
  |
|
18486A08 - Anchor Bracket Ki [ More info ]
|
| #13 | 818298Q1 | ANODE KIT(ALUM) (1 required per assembly) |
  |
|
97-818298Q 1 - Anode Kit - Outboard Transom Aluminum [ More info ]
|
  |
|
18-6249A - Anode, Aluminum, 18-6249A [ More info ]
|
  |
|
18-6249 - Zinc Anode, 818298A1 [ More info ]
|
  |
|
97-818298T 1 - Anode - Outboard Transom Aluminum [ More info ]
|
| #14 | 8M0204707 | SCREW @5 (2 required per assembly) — Replaces: 4000330 |
  |
|
108M0204707 - SCREW Note: Priced Individually [ More info ]
|
| #15 | 8M0204649 | WASHER @10 (2 required per assembly) — Replaces: 29245 |
  |
|
12-8M0204649 - WASHER Note: Priced Individually [ More info ]
|
| #16 | 85594030 | SCREW (5 required per assembly) |
  |
|
10-855940 30 - Screw [ More info ]
|
| #17 | 8M0000586 | SCREW @10 (1 required per assembly) |
  |
|
10-8M0000586 - Screw - Priced Individually [ More info ]
|
| #18 | 843108 | WASHER (4 required per assembly) |
  |
|
12-843108 - Washer, (.330 X .560 X .060) Stainless Steel [ More info ]
|
| #19 | 401388 | NUT @5 (2 required per assembly) |
  |
|
11-40138 8 - Nut - Priced Individually [ More info ]
|
| #20 | 8M0026068 | PIN ASY-TILT (1 required per assembly) — Replaces: 49930A1 |
  |
|
17-8M0026068 - Pin Assembly - Tilt [ More info ]
|
| #21 | 821461 | SPRING (1 required per assembly) |
  |
|
24-821461 - Spring, Tilt Lock Pin (Manual Tilt Models) [ More info ]
|
| #22 | 8M0041938 | TILT TUBE EDP (1 required per assembly) — Replaces: 196141, 8M0035070 |
  |
|
8M0041938 - Tilt Tube [ More info ]
|
| #23 | 858869 | NUT @5 (2 required per assembly) |
  |
|
11-858869 - Nut, (.875-14) [ More info ]
|
| #24 | 814259 | SCREW (4 required per assembly) |
  |
|
10-814259 - Screw [ More info ]
|
| #25 | 8M0204648 | WASHER @5 (4 required per assembly) — Replaces: 28421 |
  |
|
12-8M0204648 - ENGINE MOUNTING WASHER Note: Must be ordered in multiples of 5 O/B [ More info ]
|
| #26 | 82671117 | NUT (4 required per assembly) |
  |
|
11-826711 17 - Nut, (.500-20) [ More info ]
|
| #27 | 8M0084737 | LINK (1 required per assembly) — Replaces: 1938525 |
  |
|
8M0084737 - LINK [ More info ]
|
| #28 | 19615A05 | TILT LEVER ASSY (1 required per assembly) — Replaces: 19615A4 |
  |
|
19615A05 - Tilt Lever Assembly [ More info ]
|
| #29 | 812707 | BUSHING (1 required per assembly) |
  |
|
23-812707 - Bushing [ More info ]
|
| #30 | 8M0042643 | WASHER (1 required per assembly) — Replaces: 19605 |
  |
|
12-8M0042643 - Washer [ More info ]
|
| #31 | 99611 | WASHER-WAVE (1 required per assembly) |
  |
|
13-99611 - Washer, NLA [ More info ]
|
| #32 | 8M0007469 | KNOB-TILT (1 required per assembly) — Replaces: 19621 |
  |
|
8M0007469 - Knob - Tilt [ More info ]
|
| #33 | 19611 | BOLT (1 required per assembly) |
  |
|
|
| #34 | 830253 | DECAL-TILT/LOCK (1 required per assembly) |
  |
|
37-830253 - Decal - Tilt/Lock [ More info ]
|
| #35 | NSS | NOT SOLD SEPARATE DECAL-WARNING (1 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #36 | 818883A1 | SCREW ASSY-THUMB (2 required per assembly) |
  |
|
10-818883A 1 - Thumb Screw Assembly, New Takeoff [ More info ]
|
| #37 | 818884 | WASHER (2 required per assembly) |
  |
|
12-818884 - Washer [ More info ]
|
| #38 | 768042 | SHOULDER SCREW HEX (2 required per assembly) |
  |
|
0768042 - T-SHRT-M-G.BASS [ More info ] Unavailable |
| #39 | NSS | NOT SOLD SEPARATE HANDLE (1 required per assembly) |
| #40 | NSS | NOT SOLD SEPARATE RIVET (1 required per assembly) |
