Parts for 40, 400 (4 Cyl.) 2-Stroke Carbureted Mercury Outboard Motor Electrical Box Components

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > 40, 400 (4 Cyl.) > 0C159200 & Up - USA > Electrical Box Components

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Electrical Box Components

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	88807A14	CABLE ASSEMBLY (RING/MALE CONNECTOR) ELECTRIC (1 required per assembly)
		84-88807A14 - Cable, NLA [ More info ] Unavailable
#-	88807A15	CABLE ASSEMBLY (RING/FEMALE CONNECTOR) ELECTRIC (1 required per assembly)
		84-88807A15 - Cable, NLA [ More info ] Unavailable
#1	19106	COVER (1 required per assembly)
		19106 - Electrical Box Cover [ More info ] Unavailable
#2	418051	SCREW (#10-24 X .620) MERCURY SWITCH AND COVER (6 required per assembly) — Replaces: 41805
		10-41805 1 - Screw [ More info ] $2.79 Available to Order: Shipping delay up to 10 days.
#3	19639	SCREW (3 required per assembly)
		10-19639 - Screw, NLA [ More info ] $3.76 6 In Stock.
#4	812619	FUSE-YELLOW-20AMP ELECTRIC (2 required per assembly)
		88-812619 - Fuse - Yellow - 20 Amp [ More info ] $4.69 10+ In Stock.
#5	8M0058226	RECTIFIER ELECTRIC (1 required per assembly) — Replaces: 816770, 816770T
		8M0058226 - Rectifier - Outboard [ More info ] $99.99 In Stock
		18-99416 - Regulated Rectifier 445114, 193-5114 [ More info ] $119.79 $110.72 In Stock
		18-5707 - Rectifier 816770 [ More info ] $55.99 $54.04 1 In Stock.
		300-01404 - Rectifier, 8M0058226 [ More info ] $46.99 $42.60 1 In Stock.
		AR351 - Rectifier [ More info ] $49.15 $45.57 In Stock
#6	418051	SCREW (#10-24 X .620) MERCURY SWITCH AND COVER ELECTRIC (2 required per assembly) — Replaces: 41805
#7	45076	NUT @10 ELECTRIC (3 required per assembly)
		11-45076 - Nut (#10-32) (brass) [ More info ] $1.80 10+ In Stock.
#8	96054T	SOLENOID ELECTRIC (1 required per assembly) — Replaces: 96054
		89-96054T - Solenoid [ More info ] Unavailable
		18-5816 - Solenoid, 89-96054 [ More info ] $31.35 In Stock
		89-8M0185149 - Start Solenoid [ More info ] $38.99 Available to Order: Shipping delay up to 10 days.
		89-02719 - Solenoid, 89-96054T [ More info ] $20.72 10+ In Stock.
		SW054 - Solenoid [ More info ] $28.65 $27.68 In Stock
#9	41508	SCREW ELECTRIC (2 required per assembly)
		10-41508 - Screw [ More info ] $3.79 Available to Order: Shipping delay up to 10 days.
#10	26992	LOCKWASHER @5 ELECTRIC (2 required per assembly)
		13-26992 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#11	26419	NUT @5 ELECTRIC (2 required per assembly)
		11-26419 - Nut (#8-32) (brass) [ More info ] $1.70 10+ In Stock.
#12	26992	LOCKWASHER @5 ELECTRIC (2 required per assembly)
#13	64015	NUT @3 ELECTRIC (2 required per assembly)
		11-64015 - Nut (1 /4-20) [ More info ] $2.79 10+ In Stock.
#14	18672A2	HARNESS ASSEMBLY (USE WITH REF. #18) ELECTRIC (1 required per assembly)
		84-18672A 2 - Harness, NLA [ More info ] Unavailable
#14	18672A6	HARNESS ASSEMBLY (GRAY LEAD HAS RING TERMINAL) ELECTRIC (1 required per assembly)
		84-18672A 6 - Harness Assembly [ More info ] $111.50 Available to Order: Shipping delay up to 10 days.
#14	18672A8	HARNESS ASSEMBLY (GRAY LEAD HAS BULLET CONNECTOR) ELECTRIC (1 required per assembly)
		84-18672A 8 - Harness Assembly [ More info ] $585.99 1 In Stock.
#15	878608	SCREW @2 ELECTRIC (1 required per assembly) — Replaces: 812832
		10-878608 - Screw [ More info ] $1.70 Available to Order: Shipping delay up to 10 days.
#16	638131	BLOCK-TERMINAL MANUAL (1 required per assembly)
		86-63813 1 - Terminal Block [ More info ] $2.39 10+ In Stock.
#17	418051	SCREW (#10-24 X .620) MERCURY SWITCH AND COVER MANUAL (2 required per assembly) — Replaces: 41805
#17	62568	SCREW @4 MANUAL (2 required per assembly)
		10-62568 - Screw - Priced Individually [ More info ] $1.10 $0.88 10+ In Stock.
#18	16731T01	SWITCH ASSY (1 required per assembly) — Replaces: 16731A1
		16731T01 - Switch Assembly [ More info ] $83.99 Available to Order: Shipping delay up to 10 days.
#19	832757A4	COIL KIT (4 required per assembly) — Replaces: 7370A13
		339-832757A 4 - Ignition Coil [ More info ] Unavailable
		18-5186 - Ignition Coil 339-7370A13 [ More info ] $61.99 $58.62 9 In Stock.
		8M0230859 - Ignition Coil [ More info ] $124.33 2 In Stock.
#20	60466A19	WIRE ASSY (4 required per assembly)
		84-60466A19 - Wire Assembly, NLA [ More info ] Unavailable
#21	45076	NUT @10 (8 required per assembly)
#22	813715A12	CABLE SET-IGN (1 required per assembly)
		84-813715A12 - Ignition Cable Set [ More info ] $77.49 Available to Order: Shipping delay up to 10 days.
#23	63709A1	BOOT KIT-BLK@10 (4 required per assembly)
		85-63709A 1 - Boot Kit - Black - Priced Individually [ More info ] $8.19 10 In Stock.
#24	97182Q	NGK BUHW-2 @10 (4 required per assembly) — Replaces: 97182
		33-97182Q - NGK Spark Plug BUHW-2 - Priced Individually [ More info ] Unavailable
		L78V - Champion Spark Plug ( #833M) [ More info ] $15.33 10+ In Stock.
		33-896329833 - Spark Plug - L78V - Priced Individually [ More info ] Unavailable
#24	896329898	SP #QL76V @4 (BELGIUM AND CANADA) (4 required per assembly) — Replaces: 14103550
		33-896329898 - Spark Plug - QL76V - Priced Individually [ More info ] Unavailable
		QL76V - Champion Spark Plug ( #898M) [ More info ] $23.44 10+ In Stock.
#25	5772A7	SWITCHBOX (1 required per assembly) — Replaces: 5772A5
		332-5772A 7 - Switch Box [ More info ] $461.49 In Stock
		18-5881-1 - Switch Box 332-5772A5, 114-5772 [ More info ] $309.70 2 In Stock.
		18-5881-1 - Switch Box 332-5772A5, 114-5772 [ More info ] $319.99 $309.70 5 In Stock.
#26	812987	SCREW (4 required per assembly)
		10-812987 - Screw [ More info ] $1.00 $0.21 10+ In Stock.
#27	45076	NUT @10 (13 required per assembly)
#28	88818A1	CABLE ASSEMBLY (GREEN) (1 required per assembly)
		84-88818A 1 - Cable [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#28	88819A1	CABLE ASSEMBLY (GREEN/WHITE) (1 required per assembly)
		84-88819A 1 - Cable, NLA [ More info ] $2.00 $1.69 2 In Stock.
#28	88820A1	CABLE ASSEMBLY (GREEN/BLACK) (1 required per assembly)
		84-88820A 1 - Cable,NLA [ More info ] Unavailable
#28	88821A1	CABLE ASSEMBLY (GREEN/RED) (1 required per assembly)
		84-88821A 1 - Cable, NLA [ More info ] $2.00 $1.69 2 In Stock.
#29	88807A30	CABLE ASSEMBLY (BLACK) MANUAL (1 required per assembly)
		84-88807A30 - Cable Assembly, NLA [ More info ] $7.00 $5.93 2 In Stock.
#30	878608	SCREW @2 MANUAL (1 required per assembly) — Replaces: 812832
#31	813060A1	CABLE MANUAL (1 required per assembly)
		84-813060A 1 - Cable, NLA [ More info ] Unavailable
#32	14857A16	MODULE-OILWARNING ELECTRIC (1 required per assembly) — Replaces: 14857A10
		14857A16 - Oil Warning Module [ More info ] $195.99 In Stock
		18-99411 - Oil Warning Module, 14857A16, 144-4857-16 [ More info ] $182.98 2 In Stock.
#33	812987	SCREW ELECTRIC (2 required per assembly)
#34	19637	SOCKET ELECTRIC (1 required per assembly)
		88-19637 - Socket [ More info ] $39.08 Available to Order: Shipping delay up to 10 days.
#35	18758T1	BOX-ELECTRICAL (1 required per assembly) — Replaces: 187581
		18758T 1 - Box - Electrical [ More info ] Unavailable
#36	18895A1	HARNESS ASSY POWER TRIM (1 required per assembly)
		84-18895A 1 - Harness Assembly [ More info ] $98.49 Available to Order: Shipping delay up to 10 days.
#37	19761	RELAY POWER TRIM (2 required per assembly)
		87-19761 - Relay [ More info ] $71.49 $70.22 10+ In Stock.
		18-5737 - Relay, 87-19761 [ More info ] $62.02 4 In Stock.
#38	812850	SUPPORT-RELAY POWER TRIM (1 required per assembly)
		812850 - Support - Relay [ More info ] $9.99 Available to Order: Shipping delay up to 10 days.
#39	88890A2	SWITCH ASSY ELECTRIC HANDLE W/ PT (1 required per assembly)
		87-88890A 2 - Switch Assembly [ More info ] $149.99 $143.92 8 In Stock.
#40	74605A8	SWITCH ASSY ELECTRIC HANDLE W/ PT (1 required per assembly)
		87-74605A 8 - Switch Assembly, NLA [ More info ] Unavailable
#41	90342	SCREW @2 ELECTRIC HANDLE W/ PT (2 required per assembly)
		10-90342 - Screw, NLA [ More info ] $1.88 $1.59 8 In Stock.
#42	24832	NUT @2 ELECTRIC HANDLE W/ PT (2 required per assembly)
		11-24832 - Nut (4X40) [ More info ] $2.14 10+ In Stock.
#43	11149A1	CABLE ASSY ELECTRIC HANDLE W/ PT (1 required per assembly)
		84-11149A 1 - Cable Assembly [ More info ] $4.89 Available to Order: Shipping delay up to 10 days.
#44	818999A2	SOLENOID ASSY DESIGN II (1 required per assembly)
		89-818999A 2 - Solenoid Assembly [ More info ] $65.49 $53.18 1 In Stock.
		18-5820 - Solenoid Switch 89-818999 [ More info ] $53.12 6 In Stock.
		SW099 - Solenoid [ More info ] $43.00 $42.29 In Stock
#45	818968	BUSHING DESIGN II (2 required per assembly)
		23-818968 - Bushing [ More info ] Unavailable
		238M0214955 - Bushing [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
#46	8M0207785	GROMMET DESIGN II (2 required per assembly) — Replaces: 818967
		258M0207785 - Grommet [ More info ] $9.89 Available to Order: Shipping delay up to 10 days.
#47	28667	SCREW @5 DESIGN II (2 required per assembly)
		10-28667 - Screw - Priced Individually [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
#48	88439A11	CABLE ASSEMBLY (BLACK) DESIGN II (1 required per assembly)
		84-88439A11 - Cable Assembly, NLA [ More info ] $15.22 $12.89 2 In Stock.
#49	8301792	REGULATOR-VOLTAGE DESIGN II (1 required per assembly) — Replaces: 815279T, 8152795
		830179 2 - Voltage Regulator [ More info ] Unavailable
		854515 - Voltage Regulator [ More info ] Unavailable
		854515T 1 - Voltage Regulator [ More info ] Unavailable
		883072T - Voltage Regulator [ More info ] Unavailable
		8M0084173 - Voltage Regulator [ More info ] $285.99 In Stock
		18-5743-1 - Voltage Regulator, Mercury [ More info ] $199.66 $184.76 Available to Order: Shipping delay up to 10 days.
		18-5743 - Voltage Regulator, 815279-3, 81527 [ More info ] $216.99 $204.88 10+ In Stock.
		300-76382 - Rectifier/Regulator, Mercury Mariner, EMP [ More info ] $134.99 $103.22 1 In Stock.
#50	822970	SCREW DESIGN II (2 required per assembly)
		10-822970 - Screw [ More info ] $1.80 $1.44 4 In Stock.
#51	813524A2	CABLE ASSY DESIGN II (1 required per assembly)
		84-813524A 2 - Cable Assembly [ More info ] $25.49 $24.48 2 In Stock.
