Parts for 40 (Twin Carb) (w / Oil Injection) 2-Stroke Carbureted Mercury Outboard Motor Bottom Cowling
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 814524M | BOTTOM COWL (MANUAL) (1 required per assembly) |
  |
|
2168-814524M - BOTTOM COWL,NLA [ More info ] Unavailable |
| #1 | 814525M | BOTTOM COWL (ELECTRIC) (1 required per assembly) |
  |
|
2168-814525M - BOTTOM COWL,NLA [ More info ] Unavailable |
| #2 | 83616M | FITTING (1 required per assembly) |
  |
|
22-83616M - Fitting, NLA [ More info ]
|
| #3 | 95409M | LEVER (1 required per assembly) |
  |
|
95409M - Lever [ More info ] Unavailable |
| #4 | 81869M | WASHER-WAVE @2 (1 required per assembly) |
  |
|
13-81869M - Wave Washer, NLA [ More info ]
|
| #5 | 81949M | BUSHING (2 required per assembly) |
  |
|
23-81949M - Bushing [ More info ] Unavailable |
| #6 | 84914M | CLAMP (1 required per assembly) |
  |
|
54-84914M - Clamp [ More info ] Unavailable |
| #7 | 81794M | WASHER @5 (1 required per assembly) |
  |
|
12-81794M - Washer, Cowl Clamp Lever [ More info ]
|
| #8 | 84088M | BOLT (1 required per assembly) — Replaces: 84315M |
  |
|
10-84088M - Bolt [ More info ]
|
| #9 | 82212M | LOCKWASHER @5 (1 required per assembly) |
  |
|
13-82212M - LockWasher - Priced Individually [ More info ]
|
| #10 | 93104M | PLATE (1 required per assembly) |
  |
|
93104M - PLATE,NLA [ More info ] Unavailable |
| #11 | 83285M | SCREW @5 (5 required per assembly) |
  |
|
10-83285M - Screw - Priced Individually [ More info ]
|
| #12 | 82214M | WASHER @5 (5 required per assembly) |
  |
|
12-82214M - Washer - Priced Individually [ More info ]
|
| #13 | 97674M | SEAL (1 required per assembly) |
  |
|
97674M - Seal, NLA [ More info ]
|
| #14 | 93100M | GROMMET (1 required per assembly) |
  |
|
25-93100M - Grommet, NLA [ More info ]
|
| #15 | 814526M | GROMMET (1 required per assembly) |
  |
|
25-814526M - Grommet, NLA [ More info ]
|
| #16 | 83608M | GROMMET (1 required per assembly) |
  |
|
25-83608M - Grommet, NLA [ More info ]
|
| #17 | 83609M | GROMMET (1 required per assembly) |
  |
|
25-83609M - Grommet, NLA [ More info ] Unavailable |
| #18 | 97675M | GROMMET (4 required per assembly) |
  |
|
25-97675M - Grommet, NLA [ More info ]
|
| #19 | 97676M | BUSHING (4 required per assembly) |
  |
|
23-97676M - Bushing [ More info ]
|
| #20 | 83728M | GROMMET (W/O MANUAL STEERING) (1 required per assembly) |
  |
|
25-83728M - Grommet (w/o Manual Steering) NLA [ More info ] Unavailable |
| #21 | 81796M | WASHER @2 (4 required per assembly) |
  |
|
12-81796M - Washer, Apron Bolt, NLA [ More info ]
|
| #22 | 41308M | INDICATOR (ELECTRIC) (1 required per assembly) |
  |
|
41308M - Emergency Signal, NLA [ More info ] Unavailable |
| #23 | 42436M | BRACKET [M-015616/ML-351381/E-150276/EL-451766] & Up (1 required per assembly) |
  |
|
42436M - Bracket, NLA [ More info ] Unavailable |
| #24 | 82389M | NUT @2 (4 required per assembly) |
  |
|
11-82389M - Nut, NLA [ More info ] Unavailable |
| #25 | 83761M | DECAL (2 required per assembly) |
  |
|
37-83761M - Decal, NLA [ More info ] Unavailable |
| #26 | 94476M | GROMMET (ELECTRIC) (1 required per assembly) |
  |
|
25-94476M - Grommet, NLA [ More info ] Unavailable |
| #27 | 82066M | GROMMET (ELECTRIC) (1 required per assembly) |
  |
|
82066M - Plug, NLA [ More info ] Unavailable |
| #28 | 814527M | DECAL (ELECTRIC) (1 required per assembly) |
  |
|
37-814527M - Decal, NLA [ More info ]
|
| #29 | 97726M | GROMMET (ELECTRIC) (1 required per assembly) |
  |
|
25-97726M - Grommet, NLA Z [ More info ]
|
| #30 | 14222M | SWITCH (1 required per assembly) |
  |
|
87-14222M - Switch [ More info ] Unavailable |
| #31 | 97756M | STOPPER (1 required per assembly) |
  |
|
97756M - Lanyard Stopper [ More info ]
|
