Parts for 40 (2 Cyl.) 2-Stroke Carbureted Mercury Outboard Motor Manual Start Components
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 816728T14 | STARTER ASY-RECOI (1 required per assembly) |
  |
|
816728T14 - Recoil Starter Assembly [ More info ]
|
| #1 | 8M0043416 | SEAL-HANDLE REST HANDLE REST (1 required per assembly) — Replaces: 8249951 |
  |
|
8M0043416 - Seal - Handle Rest [ More info ]
|
| #2 | 822392 | SPACER HANDLE REST (2 required per assembly) |
  |
|
23-822392 - Spacer - Handle Rest [ More info ]
|
| #3 | 821788T02 | REST STARTER HANDLE (1 required per assembly) — Replaces: 8217882 |
  |
|
821788T02 - Rest [ More info ]
|
| #4 | 85174A1 | HANDLE ASSY-START (1 required per assembly) |
  |
|
85174A 1 - Handle Assembly -start [ More info ]
|
| #5 | NSS | NOT SOLD SEPARATE RETAINER (1 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #6 | 401366 | NUT @5 (4 required per assembly) — Replaces: 400264 |
  |
|
11-40136 6 - Nut - Priced Individually [ More info ]
|
| #7 | 858779 | WASHER @5 (4 required per assembly) |
  |
|
12-858779 - Washer, (.265 X .750 X .048) [ More info ]
|
| #8 | 8157951 | GROMMET (4 required per assembly) |
  |
|
25-815795 1 - Grommet [ More info ]
|
| #9 | 816086 | BUSHING @5 (4 required per assembly) |
  |
|
23-816086 - Bushing [ More info ]
|
| #10 | 8157951 | GROMMET (4 required per assembly) |
| #11 | 858779 | WASHER @5 (4 required per assembly) |
| #12 | 816728T05 | HOUSING (1 required per assembly) — Replaces: 8167285 |
  |
|
816728T05 - Starter Housing [ More info ]
|
| #13 | 818853 | RING RETAINING (1 required per assembly) |
  |
|
53-818853 - Ring - Retaining [ More info ]
|
| #14 | 8M0183792 | ROPE BUSHING (1 required per assembly) — Replaces: 42690 |
  |
|
8M0183792 - ROPE BUSHING [ More info ] Unavailable |
| #15 | 826229 | LOCKWASHER (1 required per assembly) |
  |
|
13-826229 - Spring, Lockwasher [ More info ]
|
| #16 | 86857T01 | SPRING (1 required per assembly) — Replaces: 868571 |
  |
|
24-86857T01 - Spring [ More info ]
|
| #17 | 825269T01 | SHEAVE STARTR ASU (1 required per assembly) — Replaces: 825269A1 |
  |
|
50-825269T01 - Starter Sheave [ More info ]
|
| #18 | 12066Q10 | ROPE-STARTR @2 (1 required per assembly) — Replaces: 12066Q9 |
  |
|
50-12066Q10 - Starter Rope - Priced Individually [ More info ]
|
  |
|
18-4915 - Pull Rope, 50-12066Q9 [ More info ]
|
  |
|
50-12066K10 - Starter Rope - Priced Individually [ More info ]
|
| #19 | 868523 | SPRING (1 required per assembly) |
  |
|
24-86852 3 - Spring [ More info ]
|
| #20 | 86853T01 | CAM (1 required per assembly) — Replaces: 868531 |
  |
|
|
| #21 | 826253 | SCREW (.250-20 X .625) (1 required per assembly) |
  |
|
10-826253 - Screw [ More info ] Unavailable |
| #22 | 86849T01 | RING @2 (2 required per assembly) — Replaces: 868491 |
  |
|
53-86849T01 - Ring - Priced Individually [ More info ]
|
| #23 | 868501 | CAM (2 required per assembly) |
  |
|
86850 1 - Cam Dog [ More info ]
|
| #24 | 86851T02 | SPRING @2 (2 required per assembly) — Replaces: 868512 |
  |
|
24-86851T02 - Spring - Priced Individually [ More info ]
|
| #25 | 8182491 | SCREW (#10-16 X 1.00) (3 required per assembly) |
  |
|
10-818249 1 - Screw [ More info ]
|
| #26 | 816711 | RETAINER (1 required per assembly) |
  |
|
816711 - Retainer [ More info ]
|
| #27 | 816712T01 | CAM (1 required per assembly) — Replaces: 8167121 |
  |
|
|
| #28 | 8166903 | LEVER (1 required per assembly) |
  |
|
816690 3 - Interlock Lever [ More info ]
|
| #29 | 826791 | SPRING (1 required per assembly) |
  |
|
24-826791 - Spring [ More info ]
|
| #30 | 8567542 | CABLE INTERLOCK INTERLOCK (1 required per assembly) |
  |
|
856754 2 - Cable - Interlock [ More info ] Unavailable |
| #31 | 878608 | SCREW @2 (1 required per assembly) |
  |
|
10-878608 - Screw [ More info ]
|
| #32 | 73288 | WASHER (1 required per assembly) |
  |
|
12-73288 - Washer, (.220 X .500 X .030) Stainless Steel [ More info ]
|
| #33 | 8214281 | SCREW (1 required per assembly) |
  |
|
10-821428 1 - Screw [ More info ]
|
| #34 | 26811 | PIN-COTTER (1 required per assembly) |
  |
|
18-26811 - Pigtail, GM HEI 2 Terminal [ More info ]
|
| #35 | 856985A6 | REF SOB 09-18 (1999) (1 required per assembly) |
  |
|
37-856985A 6 - Decal -epa, NLA [ More info ] Unavailable |
| #35 | 804664A00 | REF SOB 09-18 (2000) (1 required per assembly) |
  |
|
37-804664A00 - REF OB SB 09-18,NLA [ More info ] Unavailable |
| #35 | 804664A01 | REF SOB 09-18 (2001) (1 required per assembly) |
  |
|
37-804664A01 - REF OB SB 09-18,NLA [ More info ] Unavailable |
| #35 | 804664A02 | REF SOB 09-18 (2002) (1 required per assembly) |
  |
|
37-804664A02 - REF OB SB 09-18,NLA [ More info ] Unavailable |
| #35 | 804664A03 | REF SOB 09-18 (2003) (1 required per assembly) |
  |
|
37-804664A03 - REF OB SB 09-18,NLA [ More info ] Unavailable |
| #35 | 804664A04 | REF SOB 09-18 (2004) (1 required per assembly) |
  |
|
37-804664A04 - REF OB SB 09-18,NLA [ More info ] Unavailable |
| #36 | 8272822 | DECAL WARNING HIGH VOLTAGE (1 required per assembly) |
  |
|
37-827282 2 - Decal - Warning [ More info ]
|
| #37 | NSS | NOT SOLD SEPARATE DECAL-CAUTION IN GEAR IDLE (1 required per assembly) |
| #38 | NSS | NOT SOLD SEPARATE DECAL-TIMING (1 required per assembly) |
