Parts for 25 K 2-Stroke Carbureted Mercury Outboard Motor Driveshaft Housing
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 827109A02 | GASKET SET (1 required per assembly) |
  |
|
27-827109A02 - GASKET SET Lower NLA [ More info ] Unavailable |
| #1 | 95206M | BOLT (1 required per assembly) |
  |
|
10-95206M - Bolt, NLA [ More info ]
|
| #2 | 82217M | WASHER @5 (1 required per assembly) |
  |
|
12-82217M - Washer, NLA [ More info ]
|
| #3 | 84778001 | GUIDE (1 required per assembly) |
  |
|
84778001 - GUIDE Exhaust NLA [ More info ] Unavailable |
| #4 | 83870M | SCREW (4 required per assembly) |
  |
|
10-83870M - Screw, NLA [ More info ]
|
| #5 | 811170001 | MANIFOLD (1 required per assembly) |
  |
|
811170001 - MANIFOLD NLA [ More info ] Unavailable |
| #6 | 97635M | SEAL (1 required per assembly) |
  |
|
26-97635M - Seal, NLA [ More info ]
|
| #7 | 89961 | PIN-COTTER (1 required per assembly) — Replaces: 82132M |
  |
18-89961 - Cotter Pin [ More info ] Unavailable |
|
  |
|
188M0214988 - PIN-COTTER [ More info ]
|
| #8 | 84780001 | SEAL (1 required per assembly) |
  |
|
26-84780001 - SEAL NLA [ More info ] Unavailable |
| #9 | 84781001 | SEAL (1 required per assembly) |
  |
|
26-84781001 - SEAL NLA [ More info ] Unavailable |
| #10 | 826991001 | GASKET (1 required per assembly) |
  |
|
27-826991001 - GASKET NLA [ More info ] Unavailable |
| #11 | 827111A10 | HOUSING-DRIVESHAF (1 required per assembly) |
  |
|
1587-827111A10 - HOUSING ASSEMBLY NLA [ More info ] Unavailable |
| #12 | 82364M | PIN-DOWEL @2 (2 required per assembly) |
  |
|
17-82364M - Pin -Dowel - Priced Individually [ More info ]
|
| #13 | 889483 | GROMMET (RUBBER) (2 required per assembly) |
  |
|
25-889483 - GROMMET NLA [ More info ] Unavailable |
| #14 | 82217M | WASHER @5 (6 required per assembly) |
| #15 | 95416M | BOLT (6 required per assembly) |
  |
|
10-95416M - Bolt [ More info ]
|
| #16 | 889484 | PLATE (1 required per assembly) |
  |
|
889484 - GUIDE PLATE NLA [ More info ] Unavailable |
| #17 | 889485 | SEAL (1 required per assembly) |
  |
|
26-889485 - SEAL NLA [ More info ] Unavailable |
| #18 | 889486 | SEAL (1 required per assembly) |
  |
|
26-889486 - SEAL NLA [ More info ] Unavailable |
| #19 | 889487 | BOLT (1 required per assembly) |
  |
|
10-889487 - BOLT NLA [ More info ] Unavailable |
| #20 | 889488 | DAMPER (2 required per assembly) |
  |
|
25-889488 - DAMPER NLA [ More info ] Unavailable |
