Parts for 25 (2 Cyl.) 2-Stroke Carbureted Mercury Outboard Motor Crankshaft Pistons & Flywheel

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > 25 (2 Cyl.) > 0P325500 & Up - Belgium > Crankshaft Pistons & Flywheel

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Crankshaft Pistons & Flywheel

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	41499A88	GASKET SET (1 required per assembly)
		27-41499A88 - Engine Gasket Set [ More info ] $154.49 Available to Order: Shipping delay up to 10 days.
#-	804946T02	POWERHEAD ASSEMBLY (1 required per assembly)
		804946T02 - Powerhead 25 2ST, NLA [ More info ] Unavailable
#1	97359A1	SCREW (1 required per assembly)
		10-97359A 1 - Screw, NLA [ More info ] $10.76 10+ In Stock.
#1	40001248	SCREW (1 required per assembly)
		10-40001248 - Screw [ More info ] $3.19 Available to Order: Shipping delay up to 10 days.
#2	86496	WASHER (1 required per assembly)
		12-86496 - Washer, Flywheel Screw [ More info ] $3.99 Available to Order: Shipping delay up to 10 days.
#3	859232T14	FLYWHEEL (Non-Commercial) ( required per assembly) — Replaces: 859232T10
		258-859232T14 - Flywheel [ More info ] $244.49 Available to Order: Shipping delay up to 10 days.
#3	859232T13	FLYWHEEL ASSY (Commercial) (1 required per assembly) — Replaces: 818354T10
		258-859232T13 - Flywheel Assembly [ More info ] $343.49 Available to Order: Shipping delay up to 10 days.
#4	NSS	NOT SOLD SEPARATE DECAL-WARNING (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#5	NSS	NOT SOLD SEPARATE DECAL-WARNING (1 required per assembly)
#6	99301	GEAR-RING (Electric) (1 required per assembly)
		43-99301 - Ring Gear [ More info ] $356.49 Available to Order: Shipping delay up to 10 days.
#7	88190313	SCREW (Electric) (4 required per assembly)
		10-881903 13 - Screw [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#8	859741	SEAL (1 required per assembly)
		26-85974 1 - Seal [ More info ] $18.89 Available to Order: Shipping delay up to 10 days.
#9	85114T	BEARING (1 required per assembly)
		31-85114T - Bearing - Roller - Upper [ More info ] $30.49 Available to Order: Shipping delay up to 10 days.
#10	20094	KEY @5 (1 required per assembly)
		28-20094 - Key - Priced Individually [ More info ] $1.80 10+ In Stock.
#11	8978T2	CRANKSHAFT (1 required per assembly)
		464-8978T 2 - CrankShaft [ More info ] Unavailable
#12	822445A1	WEAR SLEEVE (1 required per assembly)
		822445A 1 - Wear Sleeve Kit [ More info ] $19.19 Available to Order: Shipping delay up to 10 days.
#13	NSS	NOT SOLD SEPARATE O-RING (1 required per assembly)
#14	85107	SEAL OIL LOWER (1 required per assembly)
		26-85107 - Seal [ More info ] $16.79 Available to Order: Shipping delay up to 10 days.
		18-0537 - Seal, 26-85107 [ More info ] $16.96 In Stock
#15	85113T	BEARING (1 required per assembly)
		31-85113T - Bearing - Roller - Lower [ More info ] $27.69 Available to Order: Shipping delay up to 10 days.
#16	8835A4	CONNECTING ROD (2 required per assembly)
		630-8835A 4 - Connecting Rod [ More info ] Unavailable
#17	91012	SCREW (.250-28 SPECIAL) (4 required per assembly)
		10-91012 - Screw - Special - Priced Individually [ More info ] $7.89 Available to Order: Shipping delay up to 10 days.
#18	879877A1	BEARING ASSEMBLY ROLLER (2 required per assembly)
		31-879877A 1 - Bearing - Roller [ More info ] $43.49 Available to Order: Shipping delay up to 10 days.
#19	NSS	NOT SOLD SEPARATE ROLLER (24 required per assembly)
#20	98295	BEARING NEEDLE (54 required per assembly)
		29-98295 - Needle Bearing [ More info ] $0.20 $0.05 10+ In Stock.
#21	8M0012294	WASHER-THRUST (4 required per assembly) — Replaces: 42025
		12-8M0012294 - Thrust Washer [ More info ] $6.09 2 In Stock.
#22	879878T5	PISTON ASSY (Standard) (2 required per assembly)
		767-879878T 5 - Piston Assembly [ More info ] $170.49 4 In Stock.
#22	9104T19	PISTON ASSY (Seapro/Marathon-Chrome Bore) (2 required per assembly)
		767-9104T19 - Piston Assembly [ More info ] $169.42 $162.64 4 In Stock.
#22	879878A6	PISTON-.030 O/S (.030 Oversize) (2 required per assembly)
		767-879878A 6 - Piston - .030 O/S [ More info ] $207.35 2 In Stock.
#23	828119	LOCK RING PISTON PIN (4 required per assembly)
		40-828119 - Lock Ring [ More info ] $3.19 Available to Order: Shipping delay up to 10 days.
#24	827491A12	RING SET PISTON (Standard) (1 required per assembly)
		39-827491A12 - Piston Rings - 12 Rings in this set [ More info ] $266.31 1 In Stock.
#24	18652A2	RING SET PISTON (.030 Oversize) (1 required per assembly)
		39-18652A 2 - Rings - .030 Oversize [ More info ] $168.49 Available to Order: Shipping delay up to 10 days.
#25	NSS	NOT SOLD SEPARATE PISTON RING (2 required per assembly)
#26	8M0113968	BEARING-CENTER/MA (1 required per assembly) — Replaces: 86992A5
		8M0113968 - Bearing, Center/Main [ More info ] Unavailable
#27	NSS	NOT SOLD SEPARATE BEARING (1 required per assembly)
#28	NSS	NOT SOLD SEPARATE THRUST WASHER (1 required per assembly)
#29	NSS	NOT SOLD SEPARATE THRUST WASHER (1 required per assembly)
#30	NSS	NOT SOLD SEPARATE NEEDLE ROLLER (1 required per assembly)
#31	NSS	NOT SOLD SEPARATE THRUST WASHER (1 required per assembly)
#32	NSS	NOT SOLD SEPARATE NEEDLE ROLLER (1 required per assembly)
#33	NSS	NOT SOLD SEPARATE THRUST WASHER (1 required per assembly)
