Parts for 20XD (2 Cyl.) 2-Stroke Carbureted Mercury Outboard Motor Throttle & Shift Linkage (Electric)

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > 20XD (2 Cyl.) > 6443973 - 0B238463 - USA > Throttle & Shift Linkage (Electric)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Throttle & Shift Linkage (Electric)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	17764A2	CAM KIT-THROTTLE [US-0B114231/Aus-9467988/Can-0A719661] & Up (1 required per assembly) — Replaces: 42903, 429032
		17764A 2 - Throttle Cam Kit, NLA [ More info ] Unavailable
#2	400035	SCREW @2 [US-0B114230/Aus-9467987/Can-0A719660] & Below (1 required per assembly) — Replaces: 4000114
		10-40003 5 - Screw, NLA [ More info ] $2.59 10+ In Stock.
#2	4000117	SCREW [US-0B114231/Aus-9467988/Can-0A719661] & Up (1 required per assembly)
		10-40001 17 - Screw [ More info ] Unavailable
#3	87791	WASHER THROTTLE CAM SCREW (1 required per assembly)
		12-87791 - Washer, Throttle Cam Screw, NLA [ More info ] $5.56 $4.71 10+ In Stock.
#4	69150	WAVE WASHER THROTTLE CAM SCREW (1 required per assembly)
		13-69150 - Wave Washer - Priced Individually [ More info ] $3.79 10+ In Stock.
#5	17681A1	CAM ADJUSTER ASSY THROTTLE CAM SCREW (1 required per assembly) — Replaces: 86968, 14656A1
		17681A 1 - CAM ADJUSTER ASSY [ More info ] Unavailable
#6	92425	DASH POT (1 required per assembly)
		92425 - Dash Pot, NLA [ More info ] $91.12 10+ In Stock.
#7	93001	BRACKET DASHPOT (1 required per assembly)
		93001 - Bracket, NLA [ More info ] $20.00 1 In Stock.
#8	22053	NUT (.312-24) DASHPOT TERMINAL (2 required per assembly)
		11-22053 - Nut (5/16x24) [ More info ] $0.20 10+ In Stock.
#9	98463A2	LINK ASSY (1 required per assembly)
		98463A 2 - Link Assembly, NLA [ More info ] Unavailable
#10	68219	NUT (#10-32) STAINLESS STEEL LOCK-THROTTLE ROD (1 required per assembly)
		11-68219 - Nut (#10-32) [ More info ] $2.99 10+ In Stock.
#11	8M0084742	SOCKET THROTTLE ROD (2 required per assembly) — Replaces: 98465, 19384
		8M0084742 - Socket - Ball [ More info ] $2.49 10+ In Stock.
#12	433601	LEVER CONTROL CONTROL (1 required per assembly) — Replaces: 43360
		43360 1 - Control Lever [ More info ] $52.99 Available to Order: Shipping delay up to 10 days.
#13	817429	TIMING LINK (1 required per assembly) — Replaces: 98464A5
		817429 - Timing Link, NLA [ More info ] Unavailable
#15	8M0084742	SOCKET TIMING ROD (1 required per assembly) — Replaces: 98465, 19384
#16	42026A2	PLATFORM CONTROL (1 required per assembly) — Replaces: 420262
		42026A 2 - Platform Assembly [ More info ] $95.49 $22.82 9 In Stock.
#17	89540	SPRING SPARK ADVANCE (1 required per assembly)
		24-89540 - Spring, Spark Advance [ More info ] $9.79 2 In Stock.
#18	42343	LEVER ACTUATING (1 required per assembly)
		42343 - Actuating Lever [ More info ] Unavailable
#19	46250	RING RETAINING ACTUATING AND CONTROL LEVER (1 required per assembly)
		53-46250 - Retaining Ring, NLA [ More info ] $1.62 10+ In Stock.
#20	4000171	SCREW (M6 X 16) CONTROL PLATFORM (1 required per assembly)
		10-40001 71 - Screw - Priced Individually [ More info ] $1.10 $0.88 10+ In Stock.
#20	8M0206596	SCREW (M6 X 20) CONTROL PLATFORM (2 required per assembly) — Replaces: 4000174, 4000329
		56-8M0206596 - SCREW @4 [ More info ] Unavailable
#21	40007127	SCREW SHIFT LEVER TO PLATFORM (16MM) (1 required per assembly)
		10-40007127 - Screw, NLA [ More info ] Unavailable
#22	95093	WASHER SHIFT LEVER TO PLATFORM (1 required per assembly)
		12-95093 - Washer, Shift Lever To Platform [ More info ] $0.80 10+ In Stock.
#23	43424	LEVER SHIFT (1 required per assembly)
		43424 - Lever [ More info ] $28.01 3 In Stock.
#24	95091	SLEEVE SHIFT LEVER TO PLATFORM (1 required per assembly)
		23-95091 - Sleeve [ More info ] $10.75 10+ In Stock.
#25	35280	WASHER (.255 X .620 X .030) STAINLESS STEEL SHIFT LEVER TO SCREW (1 required per assembly)
		12-35280 - Washer, (.255 X .620 X .030) Stainless Steel [ More info ] $3.19 $2.56 10+ In Stock.
#26	40144	NUT (M6) SHIFT LEVER SCREW (1 required per assembly) — Replaces: 400634, 8268336
		11-40144 - NUT Note: Priced Individually [ More info ] Unavailable
		11-40138 6 - Nut - Priced Individually [ More info ] $5.09 9 In Stock.
#27	42846A2	COVER ASSY (1 required per assembly)
		42846A 2 - Cover Assembly [ More info ] $22.79 1 In Stock.
#28	39519	CUP RETAINER (1 required per assembly)
		39519 - Cup [ More info ] $5.39 Available to Order: Shipping delay up to 10 days.
#29	118591	SCREW (.190-32 X 1.750) IDLE STOP - CONTROL LEVER (1 required per assembly) — Replaces: 11859
		10-11859 1 - Screw, NLA [ More info ] $4.70 10+ In Stock.
#30	17724A1	LEVER ASSY (1 required per assembly) — Replaces: 43444
		17724A 1 - Lever,NLA [ More info ] Unavailable
#31	96202	BUSHING NYLON - SHIFT LINK (1 required per assembly)
		23-96202 - Bushing, NLA [ More info ] Unavailable
#32	89302	WASHER (.203 X .406 X .040) SHIFT LINK (2 required per assembly)
		12-89302 - Washer (.203 X .406 X .040) [ More info ] $1.80 10+ In Stock.
#33	210711	COTTER PIN SHIFT LINK (2 required per assembly) — Replaces: 21071
		0210711 [ More info ] Unavailable Replaced by 0210710
		[ More info ] Unavailable
#34	95027A6	SHIFT SHAFT HORIZONTAL (1 required per assembly) — Replaces: 95027A1
		95027A 6 - Shift Shaft Assembly [ More info ] $31.99 $27.09 10 In Stock.
#35	95023	LEVER SHIFT SHAFT (1 required per assembly)
		95023 - Lever [ More info ] $15.00 3 In Stock.
#36	95019	RING RETAINING LEVER TO SHIFT SHAFT (1 required per assembly)
		53-95019 - Ring - Retaining [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#37	60762	BUSHING SHIFT SHAFT (2 required per assembly)
		23-60762 - Bushing [ More info ] $5.09 Available to Order: Shipping delay up to 10 days.
#38	17724A1	LEVER ASSEMBLY SHIFT SHAFT (1 required per assembly) — Replaces: 95024
#39	401385	NUT (M5) STAINLESS STEEL SHIFT SHAFT (1 required per assembly) — Replaces: 400633
		11-40138 5 - Nut [ More info ] Unavailable
#40	424291	RETAINER CABLE (2 required per assembly) — Replaces: 42429
		42429 1 - Retainer [ More info ] $13.30 Available to Order: Shipping delay up to 10 days.
#41	96186A2	BRACKET ASSEMBLY ATTACHING (1 required per assembly) — Replaces: 96186A1
		96186A 2 - Bracket Kit - Black [ More info ] $43.32 Available to Order: Shipping delay up to 10 days.
#42	96201	STRAP KEY (1 required per assembly)
		96201 - Key Strap [ More info ] $1.94 $1.65 1 In Stock.
#43	1993325	SCREW (M10 X 25 MM) BRACKET (2 required per assembly) — Replaces: 4000376
		10-19933 25 - Screw [ More info ] $7.16 Available to Order: Shipping delay up to 10 days.
#44	41323A2	ATTACHING KIT STEERING LINK STEERING (1 required per assembly) — Replaces: 96487A1, 96487A2
		41323A 2 - Attaching Kit [ More info ] $56.25 1 In Stock.
		41323A03 - Steering Link Attaching Kit [ More info ] $140.16 Available to Order: Shipping delay up to 10 days.
#45	849838	SCREW (.375-24 X 1.250) LINK ROD (1 required per assembly) — Replaces: 14000
		10-849838 - Screw [ More info ] $22.61 6 In Stock.
#46	34931	WASHER (.406 X .734 X .063) STAINLESS STEEL SCREW AND LINK ROD (2 required per assembly)
		12-34931 - Washer, (.406 X .734 X .063 - Stainless Steel) [ More info ] $2.59 10+ In Stock.
#47	8M0042636	NUT (.375-24) BRASS SCREW AND LINK ROD (2 required per assembly) — Replaces: 34863, 826709113
		11-8M0042636 - Nut - Brass , Priced Individually [ More info ] Unavailable
		118M0204726 - NUT-BRASS Note: Priced Individually [ More info ] $1.80 10 In Stock.
