Parts for 2.5 2-Stroke Carbureted Mercury Outboard Motor Gear Housing Assembly 3.3 Horsepower

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > 2.5 > 0T894577 & Up - USA > Gear Housing Assembly 3.3 Horsepower

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gear Housing Assembly 3.3 Horsepower

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0122311	GEAR HOUSING Short (1 required per assembly) — Replaces: 825126T04
		16008M0122311 - Gear Housing [ More info ] $407.15 Available to Order: Shipping delay up to 10 days.
#-	8M0122312	GEAR HOUSING Long (1 required per assembly) — Replaces: 825126T05
		1600-8M0122312 - GEAR HOUSING [ More info ] Unavailable
#-	8M0082881	GASKET SET (1 required per assembly) — Replaces: 95220A4
		278M0082881 - Gasket Set [ More info ] $51.49 Available to Order: Shipping delay up to 10 days.
#-	8M0080264	REPAIR KIT-W/P (1 required per assembly) — Replaces: 16159A2
		8M0080264 - Water Pump Repair Kit [ More info ] $96.99 In Stock
		46-46623 - Water Pump Kit 8M0080264 [ More info ] $35.99 $27.52 In Stock
#1	825126T06	GEAR HOUSING ASSEMBLY BASIC (1 required per assembly)
		1668-825126T06 - Gear Housing Assembly [ More info ] $116.99 Available to Order: Shipping delay up to 10 days.
#2	95342	BEARING BALL LOWER (1 required per assembly)
		30-95342 - Ball Bearing [ More info ] $26.19 Available to Order: Shipping delay up to 10 days.
#3	82304232	BOLT (2 required per assembly)
		10-823042 32 - Bolt [ More info ] $5.69 Available to Order: Shipping delay up to 10 days.
#4	953683	PLUG (2 required per assembly)
		22-95368 3 - Oil Plug [ More info ] Unavailable
		22-8M0229353 - PLUG [ More info ] Unavailable
#5	8M0082880	SEAL KIT DRAIN PLUG (2 required per assembly) — Replaces: 95220
		8M0082880 - Seal - Priced Individually [ More info ] Unavailable
		18-60103 - Gasket, Drain Plug 332600060M [ More info ] $1.99 $1.70 Available to Order: Shipping delay up to 10 days.
#6	16832	BOLT (M6 X 16) (1 required per assembly)
		10-16832 - Bolt [ More info ] $4.49 Available to Order: Shipping delay up to 10 days.
#7	823913Q	ANODE (1 required per assembly)
		97-823913Q - Anode, Aluminum [ More info ] $20.49 Available to Order: Shipping delay up to 10 days.
#8	8M0122680	GEAR ASSEMBLY (1 required per assembly) — Replaces: 16138
		438M0122680 - Gear Set, Three Gears [ More info ] $167.49 Available to Order: Shipping delay up to 10 days.
#9	8104711	SPACER (1 required per assembly)
		23-810471 1 - Spacer [ More info ] $14.59 Available to Order: Shipping delay up to 10 days.
#10	8M0116958	DRIVESHAFT Short (1 required per assembly) — Replaces: 823048
		458M0116958 - Drive Shaft [ More info ] $103.49 Available to Order: Shipping delay up to 10 days.
#10	8M0116959	DRIVESHAFT SHORT Long (1 required per assembly) — Replaces: 8230481
		458M0116959 - Drive Shaft SHORT [ More info ] Unavailable
		45-8M0227907 - DRIVESHAFT LONG [ More info ] Unavailable
#11	95342	BEARING BALL (1 required per assembly)
#12	16155	KEY (1 required per assembly)
		28-16155 - Key [ More info ] $3.99 2 In Stock.
#13	898101333	GASKET WATER PUMP HOUSING - LOWER (1 required per assembly) — Replaces: 161642
		27-898101333 - Water Pump Housing Gasket [ More info ] $6.79 Available to Order: Shipping delay up to 10 days.
#14	161621	SEAL OIL (1 required per assembly)
		26-16162 1 - Oil Seal [ More info ] $18.39 Available to Order: Shipping delay up to 10 days.
#15	815113T03	HOUSING W/P (1 required per assembly) — Replaces: 161613
		46-815113T03 - Water Pump Housing [ More info ] $91.99 Available to Order: Shipping delay up to 10 days.
#16	9521811	PIN ROLL - STAINLESS STEEL (2 required per assembly)
		17-95218 11 - Pin, Roll - Stainless Steel [ More info ] $4.09 1 In Stock.
#17	161603	GASKET (1 required per assembly)
		0161603 - Part (161603) [ More info ] Unavailable
#18	161591	GUIDE PLATE (1 required per assembly)
		[ More info ] Unavailable
#19	898101331	GASKET WATER PUMP HOUSING - UPPER (1 required per assembly) — Replaces: 161588
		27-898101331 - Water Pump Housing Gasket [ More info ] $4.99 2 In Stock.
#20	8M0204676	IMPELLER (1 required per assembly) — Replaces: 161543
		47-8M0204676 - Water Pump Impeller, Outboard, 2.5 - 6HP [ More info ] In Stock
		47-02170 - Mercury and Tohatsu Impeller [ More info ] $20.99 $20.46 3 In Stock.
#21	161571	LINER (1 required per assembly)
		0161571 - L/P 432.40 [ More info ] Unavailable
#22	161561	HOUSING UPPER WATER PUMP (1 required per assembly)
		0161561 - Part (161561) [ More info ] Unavailable
#23	161771	O-RING (1 required per assembly)
		0161771 - Part (161771) [ More info ] In Stock
#24	161781	O-RING (1 required per assembly)
		25-16178 1 - O-Ring [ More info ] $5.09 Available to Order: Shipping delay up to 10 days.
#25	161761	BUSHING (1 required per assembly)
		23-16176 1 - Bushing [ More info ] $5.79 Available to Order: Shipping delay up to 10 days.
#26	953611	GROMMET (1 required per assembly)
		25-95361 1 - Grommet [ More info ] Unavailable
#27	8M0063198	BOLT (4 required per assembly) — Replaces: 161251
		108M0063198 - Bolt [ More info ] $7.09 Available to Order: Shipping delay up to 10 days.
#28	16826	WASHER STAINLESS STEEL (4 required per assembly)
		12-16826 - Washer, Stainless Steel [ More info ] $3.29 Available to Order: Shipping delay up to 10 days.
#29	400256	LOCKWASHER (M6) (4 required per assembly)
		13-40025 6 - LockWasher - Priced Individually [ More info ] $1.80 $1.01 10+ In Stock.
#30	953591	TUBE WATER Short (1 required per assembly)
		32-95359 1 - Tubing [ More info ] $38.99 Available to Order: Shipping delay up to 10 days.
#30	953592	TUBE WATER Long (1 required per assembly)
		32-95359 2 - Tubing, NLA [ More info ] Unavailable
#31	953601	GROMMET (1 required per assembly)
		25-95360 1 - Grommet [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#32	16128	BEARING BALL (1 required per assembly)
		30-16128 - Ball Bearing [ More info ] $29.69 Available to Order: Shipping delay up to 10 days.
#33	16141	SHIM (0.1) (AR required per assembly)
		15-16141 - Shim [ More info ] $1.90 Available to Order: Shipping delay up to 10 days.
#33	813277	SHIM (0.15) (AR required per assembly)
		15-813277 - Shim [ More info ] $9.69 Available to Order: Shipping delay up to 10 days.
#34	8M0109578	FORWARD GEAR (1 required per assembly) — Replaces: 878343, 8M0109577
		43-8M0109578 - 43-8M0109578 - FORWARD GEAR [ More info ] Unavailable Replaced by 43-812944
		43-812944 - NLA-Gear Set Part Number 438M0122680 [ More info ] Unavailable
#35	823050	PUSH ROD (1 required per assembly)
		823050 - Push Rod [ More info ] $17.39 Available to Order: Shipping delay up to 10 days.
#36	176671	SPRING (1 required per assembly)
		24-17667 1 - Spring [ More info ] $5.49 1 In Stock.
#37	952911	PROPELLER SHAFT (1 required per assembly)
		44-95291 1 - Propeller Shaft [ More info ] $205.99 Available to Order: Shipping delay up to 10 days.
#38	823049	CLUTCH (1 required per assembly)
		52-823049 - Clutch [ More info ] $88.99 Available to Order: Shipping delay up to 10 days.
#39	95344	BEARING BALL (1 required per assembly)
		30-95344 - Ball Bearing [ More info ] $26.49 Available to Order: Shipping delay up to 10 days.
#40	95348	SEAL OIL (1 required per assembly)
		26-95348 - Oil Seal [ More info ] $15.99 1 In Stock.
#41	16131	O-RING (1 required per assembly)
		25-16131 - O-ring, Propeller Shaft Housing [ More info ] $9.89 4 In Stock.
#42	825116	HOUSING (1 required per assembly)
		825116 - Housing - Black [ More info ] $60.99 Available to Order: Shipping delay up to 10 days.
#43	167051	BOLT (M6 X 20) (2 required per assembly)
		10-16705 1 - Bolt [ More info ] $6.09 Available to Order: Shipping delay up to 10 days.
#44	815084A02	BLKMAX 7 3/8 X 7 RH (1 required per assembly) — Replaces: 8150841
		48-815084A02 - Black Max Prop 7 3/8 X 7 [ More info ] $108.15 Available to Order: Shipping delay up to 10 days.
#44	815083A02	BLKMAX 7 3/8 X 7 RH (1 required per assembly) — Replaces: 8150831
		48-815083A02 - Black Max Prop 7 3/8 X 7 [ More info ] $75.43 Available to Order: Shipping delay up to 10 days.
#45	815111Q02	SHEAR PIN KT@2 (1 required per assembly) — Replaces: 815111, 815111002
		17-815111Q02 - Shear Pin Kit - Priced Individually [ More info ] $12.88 1 In Stock.
#45	815111002	SHEAR PIN @5 (1 required per assembly) — Replaces: 8151111, 815111
		17-815111002 - SHEAR PIN Note: Priced Individually [ More info ] Unavailable
#46	95295	PIN-COTTER @5 (1 required per assembly)
		18-95295 - Cotter Pin - Priced Individually [ More info ] $7.55 Available to Order: Shipping delay up to 10 days.
		18-95295Q - Cotter Pin - Priced Individually [ More info ] $7.55 Available to Order: Shipping delay up to 10 days.
