Parts for 15 K 2-Stroke Carbureted Mercury Outboard Motor Cowling
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 852825A1 | DECAL SET (SIDE/REAR) (1 required per assembly) |
  |
|
37-852825A 1 - DECAL SET NLA [ More info ] Unavailable |
| #- | 8528251 | DECAL FRONT (1 required per assembly) |
  |
|
37-8528251 - DECAL-FRONT NLA [ More info ] Unavailable |
| #1 | 852762A02 | TOP COWL (1 required per assembly) |
  |
|
2168-852762A02 - TOP COWL ASSEMBLY NLA [ More info ] Unavailable |
| #2 | 852766001 | MOLDING (1 required per assembly) |
  |
|
852766001 - MOLDING NLA [ More info ] Unavailable |
| #3 | 814489M | RIVET (4 required per assembly) |
  |
|
17-814489M - Rivet, NLA [ More info ] Unavailable |
| #4 | 852764 | HOOK (1 required per assembly) |
  |
|
852764 - HOOK NLA [ More info ] Unavailable |
| #5 | 8527641 | HOOK (1 required per assembly) |
  |
|
8527641 - BRACKET NLA [ More info ] Unavailable |
| #6 | 811188T | BOLT (4 required per assembly) — Replaces: 811188M |
  |
|
10-811188T - Bolt [ More info ] Unavailable |
| #7 | 852763 | SEAL (1 required per assembly) |
  |
|
852763 - Seal [ More info ] Unavailable |
| #8 | 852767 | COWL-BOTTOM (1 required per assembly) |
  |
|
2168-852767 - BOTTOM COWL NLA [ More info ] Unavailable |
| #9 | 83988M | GROMMET (1 required per assembly) |
  |
|
25-83988M - Grommet, Bottom Cowl (manual) NLA [ More info ]
|
| #10 | 18927M | GROMMET (1 required per assembly) |
  |
|
25-18927M - Grommet, NLA [ More info ]
|
| #11 | 852768 | GROMMET (1 required per assembly) |
  |
|
25-852768 - GROMMET NLA [ More info ] Unavailable |
| #12 | 96596M | GROMMET (1 required per assembly) |
  |
|
25-96596M - Grommet, NLA [ More info ]
|
| #13 | 11414M | GROMMET (2 required per assembly) |
  |
|
25-11414M - Grommet, NLA [ More info ]
|
| #14 | 16634M | GROMMET (2 required per assembly) |
  |
|
25-16634M - Grommet,NLA [ More info ]
|
| #15 | 852772 | CLAMP (1 required per assembly) |
  |
|
852772 - BRACKET NLA [ More info ] Unavailable |
| #16 | 852771 | CONNECTOR (1 required per assembly) |
  |
|
22-852771 - CONNECTOR NLA [ More info ] Unavailable |
| #17 | 82405M | SCREW @2 (4 required per assembly) |
  |
|
10-82405M - Screw, NLA [ More info ]
|
| #18 | 82214M | WASHER @5 (4 required per assembly) |
  |
|
12-82214M - Washer - Priced Individually [ More info ]
|
| #19 | 11420M | COLLAR (4 required per assembly) |
  |
|
23-11420M - Collar, NLA [ More info ] Unavailable |
| #20 | 11416T | GROMMET (4 required per assembly) — Replaces: 11416M |
  |
|
25-11416T - Grommet [ More info ]
|
| #21 | 11409M | BUSHING (2 required per assembly) |
  |
|
23-11409M - Bushing, NLA [ More info ]
|
| #22 | 95463M | CLAMP (1 required per assembly) |
  |
|
95463M - Clamp [ More info ] Unavailable |
| #23 | 81794M | WASHER @5 (1 required per assembly) |
  |
|
12-81794M - Washer, Cowl Clamp Lever [ More info ]
|
| #24 | 82390M | NUT @2 (1 required per assembly) |
  |
|
11-82390M - Nut, (M6) [ More info ]
|
| #25 | 82405M | SCREW @2 (1 required per assembly) |
| #26 | 8527691 | LEVER (1 required per assembly) |
  |
|
8527691 - LEVER NLA [ More info ] Unavailable |
| #27 | 81869M | WASHER-WAVE @2 (1 required per assembly) |
  |
|
13-81869M - Wave Washer, NLA [ More info ]
|
| #28 | 852770 | SEAL (1 required per assembly) |
  |
|
26-852770 - SEAL NLA [ More info ] Unavailable |
