Parts for 15 K 2-Stroke Carbureted Mercury Outboard Motor Clamp & Swivel Bracket

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > 15 K > 6m7k-100382 & Up - Belgium > Clamp & Swivel Bracket

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Clamp & Swivel Bracket

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	827437006	BRACKET-CLAMP STB (STARBOARD) (1 required per assembly)
		1484-827437006 - CLAMP BRACKET NLA [ More info ] Unavailable
#2	8527766	BOLT (4 required per assembly)
		10-8527766 - BOLT NLA [ More info ] Unavailable
#3	852823	LEVER (2 required per assembly)
		852823 - LEVER Tilt Stop NLA [ More info ] Unavailable
#4	804383	CABLE (1 required per assembly)
		84-804383 - CABLE NLA [ More info ] Unavailable
#5	19172M	SCREW (1 required per assembly)
		10-19172M - Screw, NLA [ More info ] Unavailable
#6	8528034	WASHER (2 required per assembly)
		12-8528034 - WASHER NLA [ More info ] Unavailable
#7	852814	BUSHING (1 required per assembly)
		23-852814 - Bushing [ More info ] Unavailable
#8	8528142	BUSHING (1 required per assembly)
		23-8528142 - BUSHING NLA [ More info ] Unavailable
#9	8112713	SHAFT (1 required per assembly)
		17-8112713 - SHAFT NLA [ More info ] Unavailable
#10	852818003	BRACKET-SWIVEL (1 required per assembly)
		1485-852818003 - SWIVEL BRACKET NLA [ More info ] Unavailable
#11	804384	SCREW (2 required per assembly)
		10-804384 - SCREW NLA [ More info ] Unavailable
#12	82330M	E RING @2 (1 required per assembly)
		53-82330M - E-Ring, NLA [ More info ] $2.17 $1.83 10+ In Stock.
#13	804388	COLLAR (1 required per assembly)
		23-804388 - COLLAR NLA [ More info ] Unavailable
#14	804387	WASHER (1 required per assembly)
		12-804387 - WASHER NLA [ More info ] Unavailable
#15	852814	BUSHING (1 required per assembly)
#16	94568M	COLLAR (1 required per assembly)
		23-94568M - Collar, NLA [ More info ] $6.52 $5.53 6 In Stock.
#17	84062M	BOLT (1 required per assembly)
		10-84062M - Bolt, NLA [ More info ] $3.02 $2.56 10+ In Stock.
#18	827120005	BRACKET-CLAMP POR (PORT) (1 required per assembly)
		1484-827120005 - CLAMP BRACKET NLA [ More info ] Unavailable
#19	852817	TILT ROD (1 required per assembly)
		17-852817 - Tilt ROD [ More info ] Unavailable
#20	852813001	STUD BOLT (1 required per assembly)
		16-852813001 - STUD NLA [ More info ] Unavailable
#21	19111M	PLATE (1 required per assembly)
		19111M - Plate [ More info ] $6.00 $5.08 2 In Stock.
#22	879172252	NUT (2 required per assembly) — Replaces: 852816, 81787M
		11-879172252 - Nut [ More info ] $34.25 $29.01 2 In Stock.
#23	82214M	WASHER @5 (1 required per assembly)
		12-82214M - Washer - Priced Individually [ More info ] $5.28 10+ In Stock.
#24	82390M	NUT @2 (1 required per assembly)
		11-82390M - Nut, (M6) [ More info ] $3.62 $3.06 10+ In Stock.
#25	804391	PLATE (1 required per assembly)
		804391 - Plate [ More info ] $10.00 $8.47 2 In Stock.
#26	804389010	PLATE (1 required per assembly)
		804389010 - TILT LOCK PLATE NLA [ More info ] Unavailable
#27	804392	SHAFT (1 required per assembly)
		17-804392 - SHAFT Tilt Lock NLA [ More info ] Unavailable
#28	82327M	E RING (1 required per assembly)
		53-82327M - E-Ring, NLA [ More info ] $2.93 10+ In Stock.
#29	804394002	SPRING (1 required per assembly)
		24-804394002 - SPRING NLA [ More info ] Unavailable
#30	804390	SPRING (1 required per assembly)
		24-804390 - SPRING NLA [ More info ] Unavailable
#31	8528201	BRACKET (1 required per assembly)
		8528201 - BRACKET NLA [ More info ] Unavailable
#32	8112711	SHAFT (1 required per assembly)
		17-8112711 - SHAFT NLA [ More info ] Unavailable
#33	804386001	TILT LEVER (1 required per assembly)
		804386001 - LEVER Tilt NLA [ More info ] Unavailable
#34	11932M	COVER (1 required per assembly)
		11932M - Cover [ More info ] Unavailable
#35	82330M	E RING @2 (2 required per assembly)
#36	811995001	SCREW (1 required per assembly)
		10-811995001 - SCREW NLA [ More info ] Unavailable
#37	852819002	TILT LEVER (1 required per assembly)
		852819002 - TILT Tilt NLA [ More info ] Unavailable
#38	8527785	SPRING (1 required per assembly)
		24-852778 5 - Spring [ More info ] $4.00 $3.39 2 In Stock.
#39	804393	ROD (1 required per assembly)
		804393 - ADJUSTING WASHER,NLA [ More info ] Unavailable
#40	91784M	HANDLE (2 required per assembly)
		91784M - Handle [ More info ] $14.09 Available to Order: Shipping delay up to 10 days.
#41	852812	PIN (2 required per assembly)
		17-852812 - Pin, NLA [ More info ] $3.99 $3.37 10+ In Stock.
#42	81756M	SCREW (2 required per assembly)
		10-81756M - Screw [ More info ] $44.75 Available to Order: Shipping delay up to 10 days.
#43	80638M	WASHER (2 required per assembly)
		12-80638M - Washer, Transom Screw [ More info ] $9.99 $8.45 3 In Stock.
