Mercury Marine K-planes Trim / Tilt / Lift Systems & Components K Plane, 150s (Trim Tab) (841944A01 / 841944A02)

Revise Search: Accessories 1994 & Up > Trim / Tilt / Lift Systems & Components > K-planes > 1994 & Up > K Plane, 150s (Trim Tab) (841944A01 / 841944A02)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

K Plane, 150s (Trim Tab) (841944A01 / 841944A02)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	841944A02	K PLANE 150S DIG (SmartCraft Compatibility) For Digital Component Breakdown, See Digital Tab Position Indicator Components Section.) (1 required per assembly) — Replaces: 841944A01
		841944A02 - K Plane 150S Dig [ More info ] Unavailable
#-	845532A02	ACTUATOR KIT (STAINLESS STEEL GRIP) (See Actuator Kit (845532A02 and 845630A02) for Parts Break Down) (AR required per assembly)
		845532A02 - Actuator Kit, Stainless Steel [ More info ] $453.06 Available to Order: Shipping delay up to 10 days.
#-	845630A02	ACTUATOR KIT (PLASTIC GRIP) (See Actuator Kit (845532A02 and 845630A02) for Parts Break Down) (AR required per assembly)
		845630A02 - Actuator Kit, Plastic Grip [ More info ] $267.68 Available to Order: Shipping delay up to 10 days.
#-	884359A03	GAUGE DRIVER KIT (AR required per assembly)
		884359A03 - Gauge Driver Kit [ More info ] $377.59 2 In Stock.
#1	841215T01	PLATE ASSEMBLY UPPER (Starboard) (1 required per assembly)
		841215T01 - Upper Plate Assembly [ More info ] $527.00 Available to Order: Shipping delay up to 10 days.
#1	841215T02	PLATE ASSEMBLY UPPER (Port) (1 required per assembly)
		841215T02 - Upper Plate Assembly [ More info ] $527.44 Available to Order: Shipping delay up to 10 days.
#2	8M0034461	STUD (2 required per assembly) — Replaces: 21085
		16-8M0034461 - Stud [ More info ] $21.59 7 In Stock.
#3	847266	ANODE (1 required per assembly)
		847266 - Anode [ More info ] $4.72 8 In Stock.
#4	8267096	NUT (#10-32) STAINLESS STEEL (2 required per assembly)
		11-826709 6 - Nut [ More info ] $3.69 1 In Stock.
#5	844127	PLUG (.50-14) PIPE (2 required per assembly)
		22-844127 - Plug [ More info ] $19.89 Available to Order: Shipping delay up to 10 days.
#6	844142A01	STUD WITH INSERT (2 required per assembly)
		16-844142A01 - Stud [ More info ] $95.49 Available to Order: Shipping delay up to 10 days.
#7	845975	HOSE HYDRAULIC (9.375 INCHES) (2 required per assembly)
		32-845975 - Hydraulic Hose, 9.375 Inch [ More info ] $54.34 Available to Order: Shipping delay up to 10 days.
#8	845760T09	CYLINDER ASSEMBLY TRIM TAB (See Cylinder Assembly, Hydraulic (845760T09) Section for Parts Break Down) (1 required per assembly)
		845760T09 - Trim Cylinder Assembly Tab [ More info ] $746.66 Available to Order: Shipping delay up to 10 days.
#9	842729T01	PLATE ASSEMBLY LOWER (1 required per assembly)
		842729T01 - Lower Plate Assembly [ More info ] $923.87 Available to Order: Shipping delay up to 10 days.
#10	88238A13	CABLE ASSEMBLY GROUND (1 required per assembly)
		88238A13 - Cable Assembly, Priced Individually [ More info ] $13.60 3 In Stock.
		8M0207768 - CABLE ASSY @5 [ More info ] Unavailable
#11	68513	SCREW (#10-32 X .375) STAINLESS STEEL (1 required per assembly)
		10-68513 - Screw [ More info ] $1.40 10 In Stock.
#12	8M0034465	STUD (1 required per assembly) — Replaces: 842724
		16-8M0034465 - Stud [ More info ] $17.79 Available to Order: Shipping delay up to 10 days.
#13	848653T	ANODE (1 required per assembly)
		848653T - Anode [ More info ] In Stock
#14	8M0204726	NUT-BRASS @3 (1 required per assembly) — Replaces: 826709113, 8M0042636
		118M0204726 - NUT-BRASS Note: Priced Individually [ More info ] $1.80 10 In Stock.
#15	8M0008636	PIN UPPER AND LOWER TRIM CYLINDER MOUNT (2 required per assembly) — Replaces: 891579
		17-8M0008636 - Pin [ More info ] $51.34 1 In Stock.
#16	35000	NUT (.500-20) STAINLESS STEEL (4 required per assembly)
		11-35000 - Nut,(1/2-20 ) [ More info ] $14.59 $10.51 10+ In Stock.
#17	847195T01	PIN HINGE UPPER AND LOWER PLATE (1 required per assembly)
		847195T01 - Hinge Pin [ More info ] $104.64 Available to Order: Shipping delay up to 10 days.
#18	842751	NUT (.437-20) (2 required per assembly)
		11-842751 - Nut, (.437-20) [ More info ] $10.52 Available to Order: Shipping delay up to 10 days.
#19	895741	BUSHING (6 required per assembly)
		23-89574 1 - Bushing [ More info ] $6.19 Available to Order: Shipping delay up to 10 days.
#20	846377	WASHER (.531 X 1.06 X .095) STAINLESS STEEL (4 required per assembly)
		12-846377 - Washer, (.531 X 1.06 X .095) Stainless Steel [ More info ] $12.99 Available to Order: Shipping delay up to 10 days.
#21	891576	SPACER (.875 X .635) (4 required per assembly)
		23-891576 - Spacer - .875 X .635 [ More info ] $6.70 Available to Order: Shipping delay up to 10 days.
#22	841388	WASHER (.410 X .810 X .050) STAINLESS STEEL MOUNTING (8 required per assembly)
		12-841388 - Washer, (.410 X .810 X .050) Stainless Steel [ More info ] $0.90 Available to Order: Shipping delay up to 10 days.
#23	845998	WASHER (.406 X 1.250 X .089) MOUNTING (8 required per assembly)
		12-845998 - Washer, (.406 X 1.250 X .089) [ More info ] $3.79 Available to Order: Shipping delay up to 10 days.
#24	82670912	NUT (.375-16) STAINLESS STEEL MOUNTING (8 required per assembly)
		11-826709 12 - Nut, (.375-16) Stainless Steel [ More info ] $6.79 $3.81 10+ In Stock.
#25	845997	NUT (.625-18) MOUNTING (8 required per assembly)
		11-845997 - Nut, (.625-18) [ More info ] $5.09 Available to Order: Shipping delay up to 10 days.
#26	844850	WASHER (.660 X 1.310 X .09) STAINLESS STEEL MOUNTING (4 required per assembly)
		12-844850 - Washer, (.660 X 1.310 X .09) Stainless Steel [ More info ] $1.24 Available to Order: Shipping delay up to 10 days.
#27	843373	SCREW (.375-16 X 3.500) MOUNTING (4 required per assembly)
		10-843373 - Screw [ More info ] $4.49 Available to Order: Shipping delay up to 10 days.
#28	843575	SCREW (.375-16 X 4.00) STAINLESS STEEL MOUNTING (4 required per assembly)
		10-843575 - Screw [ More info ] $8.69 Available to Order: Shipping delay up to 10 days.
#29	8M0083288	PUMP ASY-TRIM PLASTIC (See Pump/Motor Assembly Section for Parts Break Down) (2 required per assembly) — Replaces: 849670A05
		8M0083288 - Pump Assembly -Trim [ More info ] $1,351.64 Available to Order: Shipping delay up to 10 days.
#30	846160A2	HARNESS ASSEMBLY (2 required per assembly)
		84-846160A 2 - Harness Assembly [ More info ] $110.25 Available to Order: Shipping delay up to 10 days.
#31	846159	FUSE 10 AMPERE (1 required per assembly)
		89-846159 - Fuse - 10 Amp [ More info ] $1.53 Available to Order: Shipping delay up to 10 days.
#32	895820T02	HARNESS ASSEMBLY (FOR USE ON 841945A02 -DIGITAL TAB POSITION INDICATOR MODEL) (1 required per assembly)
		84-895820T02 - Harness Assembly [ More info ] $249.90 Available to Order: Shipping delay up to 10 days.
#33	843556A1	HOSE KIT-30 INCH (OPT required per assembly)
		32-843556A 1 - Hose Kit -30 Inch [ More info ] $307.77 Available to Order: Shipping delay up to 10 days.
#33	843675A1	HOSE KIT-60 INCH (OPT required per assembly)
		32-843675A 1 - Hose Kit -60 Inch [ More info ] $388.39 Available to Order: Shipping delay up to 10 days.
#33	845976	HOSE ASSEMBLY HYDRAULIC (30.00 INCHES) (4 required per assembly)
		32-845976 - Hose - Hydraulic - 30 Inch [ More info ] $76.97 Available to Order: Shipping delay up to 10 days.
#33	845977	HOSE HYDRAULIC (60.00 INCHES BULK) (4 required per assembly)
		32-845977 - Hydraulic Hose -60 In. [ More info ] $119.39 Available to Order: Shipping delay up to 10 days.
#33	846051	HOSE-HYD-96 IN (OPT required per assembly)
		32-846051 - Hydraulic Hose -96 In [ More info ] $156.43 Available to Order: Shipping delay up to 10 days.
#33	848789	HYD HOSE-115 IN. (OPT required per assembly)
		32-848789 - Hydraulic Hose -115 In. [ More info ] $197.49 Available to Order: Shipping delay up to 10 days.
#34	38402	FITTING (.375-24 X 6.250) BRASS (4 required per assembly)
		22-38402 - Fitting [ More info ] $10.29 Available to Order: Shipping delay up to 10 days.
