Mercury Marine K-planes Trim / Tilt / Lift Systems & Components K Plane, 150s (845702A1 / 845703A1 / 845711A2)
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 846212A1 | PLATE ASSY-STBD (Starboard) (1 required per assembly) |
  |
|
846212A 1 - Plate - Starboard,NLA [ More info ] Unavailable |
| #- | 846214A1 | PLATE ASSY-PORT (Port) (1 required per assembly) |
  |
|
846214A 1 - Plate-PORT,NLA [ More info ] Unavailable |
| #1 | 847089T2 | PLATE ASSY-STBD (Starboard) (1 required per assembly) — Replaces: 847089A2 |
  |
|
847089T 2 - Plate Assembly - Stbd [ More info ] Unavailable |
| #1 | 847090T2 | PLATE ASSY-PORT (Port) (1 required per assembly) — Replaces: 847090A2 |
  |
|
847090T 2 - Plate Assembly - Port [ More info ] Unavailable |
| #2 | 8M0034461 | STUD (1 required per assembly) — Replaces: 21085 |
  |
|
16-8M0034461 - Stud [ More info ]
|
| #3 | 847266 | ANODE (1 required per assembly) |
  |
|
|
| #4 | 8267096 | NUT (#10-32) STAINLESS STEEL (1 required per assembly) — Replaces: 890371 |
  |
|
11-826709 6 - Nut [ More info ]
|
| #5 | 32804 | PLUG (.500-14) PIPE (2 required per assembly) |
  |
|
|
| #6 | 847018 | STUD (.625-11 X 4.500) HYDRAULIC HOSE (2 required per assembly) |
  |
|
16-847018 - Stud [ More info ]
|
| #7 | 844093 | NUT (.625-11) SPECIAL - HYDRAULIC HOSE (2 required per assembly) |
  |
|
11-844093 - Nut, (.625-11) Special - Hydraulic Hose [ More info ]
|
| #8 | 845975 | HOSE HYDRAULIC (9.375 INCHES) (2 required per assembly) |
  |
|
32-845975 - Hydraulic Hose, 9.375 Inch [ More info ]
|
| #9 | 8M0192218 | CYL ASSY-TRIM (1 required per assembly) — Replaces: 845739A10 |
  |
|
8M0192218 - CYL ASSY-TRIM [ More info ] Unavailable |
| #10 | 845709A1 | PLATE ASSEMBLY LOWER (1 required per assembly) |
  |
|
845709A 1 - Plate-LOWER,NLA [ More info ] Unavailable |
| #11 | 8M0034461 | STUD (1 required per assembly) — Replaces: 21085 |
| #12 | 847332 | ANODE (1 required per assembly) |
  |
|
847332 - Anode [ More info ] Unavailable |
| #13 | 8267096 | NUT (#10-32) STAINLESS STEEL (1 required per assembly) — Replaces: 890371 |
| #14 | 847196 | PIN UPPER TRIM CYLINDER MOUNT (1 required per assembly) |
  |
|
847196 - Pin, Upper Trim Cylinder Mount [ More info ]
|
| #15 | 847195 | PIN HINGE UPPER AND LOWER PLATE (1 required per assembly) |
  |
|
847195 - Hinge Pin [ More info ]
|
| #16 | 8M0143423 | NUT NYLON (6 required per assembly) — Replaces: 35053 |
  |
|
11-8M0143423 - NUT, Priced Individually [ More info ]
|
| #17 | 847197 | PIN LOWER TRIM CYLINDER MOUNT (1 required per assembly) |
  |
|
847197 - Pin, Lower Trim Cylinder Mount [ More info ]
|
| #18 | 846160A2 | HARNESS ASSY (2 required per assembly) — Replaces: 846160A1 |
  |
|
84-846160A 2 - Harness Assembly [ More info ]
|
| #19 | 846158 | HOLDER ASSEMBLY FUSE - WITH CLIPS (1 required per assembly) |
  |
|
846158 - FUSEHOLDER ASSY,NLA [ More info ] Unavailable |
| #20 | 846159 | FUSE 10 AMPERE (1 required per assembly) |
  |
|
89-846159 - Fuse - 10 Amp [ More info ]
|
| #21 | 843373 | SCREW (.375-16 X 3.500) MOUNTING (4 required per assembly) |
  |
|
10-843373 - Screw [ More info ]
|
| #22 | 843575 | SCREW (.375-16 X 4.00) STAINLESS STEEL MOUNTING (4 required per assembly) |
  |
|
10-843575 - Screw [ More info ]
|
| #23 | 841388 | WASHER (.410 X .810 X .050) STAINLESS STEEL MOUNTING (8 required per assembly) |
  |
|
12-841388 - Washer, (.410 X .810 X .050) Stainless Steel [ More info ]
|
| #24 | 845998 | WASHER (.406 X 1.250 X .089) MOUNTING (8 required per assembly) |
  |
|
12-845998 - Washer, (.406 X 1.250 X .089) [ More info ]
|
| #25 | 82670912 | NUT (.375-16) STAINLESS STEEL MOUNTING (8 required per assembly) — Replaces: 68411 |
  |
|
11-826709 12 - Nut, (.375-16) Stainless Steel [ More info ]
|
| #26 | 845997 | NUT (.625-18) MOUNTING (8 required per assembly) |
  |
|
11-845997 - Nut, (.625-18) [ More info ]
|
| #27 | 844850 | WASHER (.660 X 1.310 X .09) STAINLESS STEEL MOUNTING (4 required per assembly) |
  |
|
12-844850 - Washer, (.660 X 1.310 X .09) Stainless Steel [ More info ]
|
| #28 | 849670A05 | PUMP ASSY-TRIM (2 required per assembly) — Replaces: 846183A1, 846183A2 |
  |
849670A05 - Trim Pump Assembly [ More info ] Unavailable |
|
  |
|
8M0083288 - Pump Assembly -Trim [ More info ]
|
| #28 | 8M0083288 | PUMP ASY-TRIM PLASTIC (2 required per assembly) — Replaces: 846183A2, 849670A05 |
| #29 | 843556A1 | HOSE KIT-30 INCH (OPT required per assembly) |
  |
|
32-843556A 1 - Hose Kit -30 Inch [ More info ]
|
| #29 | 843675A1 | HOSE KIT-60 INCH (OPT required per assembly) |
  |
|
32-843675A 1 - Hose Kit -60 Inch [ More info ]
|
| #29 | 845976 | HOSE ASSEMBLY HYDRAULIC (30.00 INCHES) (4 required per assembly) |
  |
|
32-845976 - Hose - Hydraulic - 30 Inch [ More info ]
|
| #29 | 845977 | HOSE HYDRAULIC (60.00 INCHES BULK) (4 required per assembly) |
  |
|
32-845977 - Hydraulic Hose -60 In. [ More info ]
|
| #29 | 846051 | HOSE-HYD-96 IN (OPT required per assembly) |
  |
|
32-846051 - Hydraulic Hose -96 In [ More info ]
|
| #29 | 848789 | HYD HOSE-115 IN. (OPT required per assembly) |
  |
|
32-848789 - Hydraulic Hose -115 In. [ More info ]
|
| #30 | 845521A1 | STUD KIT-HYD-5.50 (OPT required per assembly) |
  |
|
16-845521A 1 - Stud Kit - Hydraulic -5.50 [ More info ]
|
| #30 | 845525A1 | STUD KIT-HYD-6.00 (OPT required per assembly) |
  |
|
16-845525A 1 - Stud Kit - Hydraulic -6.00 [ More info ]
|
| #31 | 844093 | NUT (.625-11) SPECIAL - HYDRAULIC HOSE (2 required per assembly) |
