K Plane, 110s (847219A1 / 847227A1)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	847230A1	PLATE ASSY-PORT (With Actuator) (Port) (1 required per assembly)
		847230A 1 - Plate-PORT,NLA [ More info ] Unavailable
#-	847230A2	PLATE ASSY-STBD (With Actuator) (Starboard) (1 required per assembly)
		847230A 2 - Plate - Starboard,NLA [ More info ] Unavailable
#-	847230A3	PLATE ASSY-PORT (Without Actuator) (Port) (1 required per assembly)
		847230A 3 - Plate-PORT,NLA [ More info ] Unavailable
#-	847230A4	PLATE ASSY-STBD (Without Actuator) (Starboard) (1 required per assembly)
		847230A 4 - Plate - Starboard,NLA [ More info ] Unavailable
#1	8472301	PLATE UPPER (1 required per assembly)
		847230 1 - PLATE-UPPER,NLA [ More info ] Unavailable
#2	8M0034461	STUD (1 required per assembly) — Replaces: 21085
		16-8M0034461 - Stud [ More info ] $21.59 7 In Stock.
#3	847266	ANODE (1 required per assembly)
		847266 - Anode [ More info ] $4.72 8 In Stock.
#4	8267096	NUT (#10-32) STAINLESS STEEL (1 required per assembly) — Replaces: 890371
		11-826709 6 - Nut [ More info ] $3.69 1 In Stock.
#5	842027	DECAL (1 required per assembly) — Replaces: 846874
		37842027 - Decal [ More info ] $5.41 Available to Order: Shipping delay up to 10 days.
#6	847231A1	PLATE ASSEMBLY LOWER (1 required per assembly)
		847231A 1 - Plate-LOWER,NLA [ More info ] Unavailable
#7	8M0034461	STUD (1 required per assembly) — Replaces: 21085
#8	847266	ANODE (1 required per assembly)
#9	8267096	NUT (#10-32) STAINLESS STEEL (1 required per assembly) — Replaces: 890371
#10	847241A1	MANIFOLD ASSEMBLY TRIM CYLINDER (1 required per assembly)
		847241A 1 - Manifold-TRI,NLA [ More info ] Unavailable
#11	8M0204681	O RING @5 (1 required per assembly) — Replaces: 45710, 457101
		25-8M0204681 - O RING Note: Priced Individually [ More info ] $3.79 Available to Order: Shipping delay up to 10 days.
#12	847233A1	HOUSING ASSEMBLY TRIM CYLINDER (1 required per assembly)
		847233A 1 - Trim Cylinder Housing, NLA [ More info ] Unavailable
#13	847234	BALL (1 required per assembly)
		30-847234 - BALL,NLA [ More info ] Unavailable
#14	845746	O-RING (1 required per assembly)
		25-845746 - O-ring, Oil Pick-up Plate [ More info ] $8.69 Available to Order: Shipping delay up to 10 days.
#15	847401	SCREW (#10-24 X .380) GROUND (1 required per assembly)
		10-847401 - Screw [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
#16	847235	RING CONTINUITY (1 required per assembly)
		847235 - RING,NLA [ More info ] Unavailable
#17	69029	SCREW (.250-28 X 1.750) (2 required per assembly)
		10-69029 - Screw, NLA [ More info ] $1.82 $1.54 10+ In Stock.
#18	846673	WASHER (.265 X .500 X .060) STAINLESS STEEL (4 required per assembly)
		12-846673 - Washer, (.265 X .500 X .060) Stainless Steel [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
#19	8472681	SCREW (.250-28 X 1.00) (2 required per assembly)
		10-847268 1 - Screw [ More info ] $0.99 $0.83 10+ In Stock.
#20	846673	WASHER (.265 X .500 X .060) STAINLESS STEEL (8 required per assembly)
#21	8472681	SCREW (.250-28 X 1.00) (4 required per assembly)
#22	8472691	SCREW (.250-28 X 2.750) (4 required per assembly)
		10-847269 1 - SCREW,NLA [ More info ] Unavailable
#23	48171	O-RING (.364. X .070) (1 required per assembly)
		25-48171 - O-Ring - Priced Individually [ More info ] $1.70 8 In Stock.
		18-7168-9 - O-Ring (PK5) 202893, 25-48171 [ More info ] $5.64 Available to Order: Shipping delay up to 10 days.
#24	8M0143423	NUT (2 required per assembly) — Replaces: 35053
		11-8M0143423 - NUT, Priced Individually [ More info ] $9.49 1 In Stock.
#25	847244	PIN UPPER (1 required per assembly)
		847244 - PIN-UPPER,NLA [ More info ] Unavailable
#26	847277	WASHER (2 required per assembly)
		12-847277 - WASHER,NLA [ More info ] Unavailable
#27	847237	ROD HYDRAULIC PISTON (1 required per assembly)
		847237 - ROD-HYD Piston, NLA [ More info ] Unavailable
#28	847242	BUSHING (1 required per assembly)
		847242 - Bushing,NLA [ More info ] Unavailable
#29	8M0143423	NUT NYLON (2 required per assembly) — Replaces: 35053
#30	847243	PIN HINGE (1 required per assembly)
		847243 - PIN-HINGE,NLA [ More info ] Unavailable
#31	847267	SCREW (.312-18 X 1.00) (4 required per assembly)
		10-847267 - SCREW,NLA [ More info ] Unavailable
#32	841284	WASHER (.340 X .750 X .050) MOUNTING (4 required per assembly)
		12-841284 - Washer, (.340 X .750 X .050) Mounting [ More info ] Unavailable
#33	845751	SCRAPER ROD (1 required per assembly)
		845751 - Scraper [ More info ] $62.43 2 In Stock.
#34	86391	O-RING (1 required per assembly)
		25-86391 - O-ring,Transfer Port Cover [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#35	847236A1	PISTON ASSEMBLY HYDRAULIC CYLINDER (1 required per assembly)
		847236A 1 - Piston-HYD,NLA [ More info ] Unavailable
#36	847261	O-RING (1 required per assembly)
		25-847261 - O RING,NLA [ More info ] Unavailable
#37	847249	WIPER TRIM CYLINDER (Late Design) (2 required per assembly)
		847249 - WIPER-Trim Cylinder,NLA [ More info ] Unavailable
#38	847290	TAB WASHER (Late Design) (2 required per assembly)
		14-847290 - WASHER-TAB,NLA [ More info ] Unavailable
#39	69022	SCREW (#10-32 X .500) STAINLESS STEEL (Late Design) (2 required per assembly)
		10-69022 - Screw [ More info ] $1.10 $0.62 10+ In Stock.
#40	847295A1	SENSOR KIT TWO LINEAR RESISTOR SENSORS (847230A1 AND 847230A2) (1 required per assembly) — Replaces: 847248
		847295A 1 - Sensor Kit,NLA [ More info ] Unavailable
#41	847273	PLUG ASSEMBLY (847230A3 AND 847230A4) (1 required per assembly)
		22-847273 - PLUG,NLA [ More info ] Unavailable
#42	48171	O-RING (.364. X .070) (1 required per assembly)
#43	847245A1	PUMP ASSY-HYD (2 required per assembly)
		847245A 1 - Pump-HYD,NLA [ More info ] Unavailable
#44	847262	O-RING (2 required per assembly)
		25-847262 - O RING,NLA [ More info ] Unavailable
#45	8M0050389	MOTOR-TRIM PUMP (1 required per assembly) — Replaces: 849150
		8M0050389 - Motor-Trim Pump [ More info ] Unavailable
#46	847270	SCREW (8 required per assembly)
		10-847270 - SCREW,NLA [ More info ] Unavailable
#47	841284	WASHER (8 required per assembly)
#48	847271	WASHER (8 required per assembly)
		12-847271 - WASHER,NLA [ More info ] Unavailable
#49	82670910	NUT @2 (8 required per assembly) — Replaces: 67980
		11-826709 10 - Nut, (.312-18) Stainless Steel [ More info ] $7.19 1 In Stock.
#NS	847295A1	SENSOR KIT TWO LINEAR RESISTOR SENSORS (OPT required per assembly)
#NS	842773	DECAL MERCURY RACING (1 required per assembly) — Replaces: 847313
		37-842773 - Decal (Mercury) [ More info ] $10.71 Available to Order: Shipping delay up to 10 days.
