Parts for 140 Jet 2-Stroke Carbureted Mercury Outboard Motor Flywheel / Starter Motor

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > 140 Jet > 0G960500 - 0T178499 - USA > Flywheel / Starter Motor

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Flywheel / Starter Motor

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	18896A1	COVER KIT-F WHEEL (1 required per assembly)
		18896A 1 - Flywheel Cover Kit [ More info ] $110.49 Available to Order: Shipping delay up to 10 days.
#2	79022	MARKER (1 required per assembly)
		79022 - Timing Marker [ More info ] $37.49 Available to Order: Shipping delay up to 10 days.
#3	37572	SCREW (.190-32 X .380) (2 required per assembly)
		10-37572 - Screw [ More info ] $1.10 $0.88 1 In Stock.
#4	72761	WASHER (.203 X .562 X .060) STAINLESS STEEL (2 required per assembly)
		12-72761 - Washer, (.203 X .562 X .060) Stainless Steel [ More info ] $1.63 10+ In Stock.
#5	45907	PLUG (1 required per assembly)
		19-45907 - Plug [ More info ] $7.09 2 In Stock.
#6	52901	NUT (1 required per assembly)
		11-52901 - Nut (5/8-18) [ More info ] $13.19 Available to Order: Shipping delay up to 10 days.
#7	33001	WASHER @2 (1 required per assembly) — Replaces: 68229
		12-33001 - Washer, Flywheel Nut [ More info ] $11.59 Available to Order: Shipping delay up to 10 days.
#8	859238T17	FLYWHEEL ASY [0T801000] & Up (1 required per assembly) — Replaces: 859238T4, 859238T15
		271-859238T17 - Flywheel Assembly [ More info ] $698.49 Available to Order: Shipping delay up to 10 days.
#9	858404T4	STATOR ASSY [0T598999] & Below (1 required per assembly) — Replaces: 858404T3
		398-858404T 4 - Stator Assembly [ More info ] $824.49 Available to Order: Shipping delay up to 10 days.
		18-99215 - Stator 398-858404T 4, 174-0002 [ More info ] $872.13 $787.55 In Stock
#10	90045	SCREW (5 required per assembly)
		10-90045 - Screw [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#11	26996	LOCKWASHER @15 (5 required per assembly)
		13-26996 - LockWasher - Priced Individually [ More info ] $1.20 Available to Order: Shipping delay up to 10 days.
#12	96455T18	TRIGGER ASSY (1 required per assembly) — Replaces: 96455A18
		96455T18 - Trigger Assembly [ More info ] $273.49 In Stock
		18-99397 - Trigger V, 96455A18, 134-6456-18 [ More info ] $251.05 4 In Stock.
#13	74897T	PIVOT (1 required per assembly) — Replaces: 74897
		74897T - Pivot [ More info ] $12.89 Available to Order: Shipping delay up to 10 days.
#14	45076	NUT (#10-32) BRASS (1 required per assembly)
		11-45076 - Nut (#10-32) (brass) [ More info ] $1.80 10+ In Stock.
#15	76035	ROD (1 required per assembly)
		76035 - Link Rod [ More info ] Unavailable
#16	62459T	BALL JOINT ASSY (1 required per assembly) — Replaces: 62459
		62459T - Ball Joint Assembly [ More info ] $26.59 Available to Order: Shipping delay up to 10 days.
#17	893893	STARTER MOTOR [0T409000] THRU [0T469022] (1 required per assembly) — Replaces: 79472T2, 884238T
		50-893893 - Starter Motor [ More info ] Unavailable
		18-5608 - Starter, 50-79472 [ More info ] $259.99 $253.99 3 In Stock.
		5380 - Starter, 50-79472 1 [ More info ] $255.39 5 In Stock.
#17	79472T2	STARTER MOTOR [0T408999] & Below (1 required per assembly) — Replaces: 794721, 884238T
		50-79472T 2 - Starter Motor [ More info ] Unavailable
#18	8M0034918	COLLAR (2 required per assembly) — Replaces: 56703, 8M0001391
		23-8M0034918 - Collar [ More info ] $9.29 3 In Stock.
#19	8M0043376	STOP RUBBER (2 required per assembly) — Replaces: 68042
		8M0043376 - Stop [ More info ] $47.11 2 In Stock.
#20	69035	SCREW/LOCKWASHER (1 required per assembly)
		10-69035 - Screw/LockWasher [ More info ] $1.90 $1.52 10+ In Stock.
#21	93388A1	CABLE ASSY (1 required per assembly)
		84-93388A 1 - Cable Assembly [ More info ] $13.19 Available to Order: Shipping delay up to 10 days.
#22	26992	LOCKWASHER @5 (1 required per assembly)
		13-26992 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#23	94330	NUT @2 (1 required per assembly)
		11-94330 - Nut, Brass (1/4-20) [ More info ] $1.70 Available to Order: Shipping delay up to 10 days.
#24	NSS	NOT SOLD SEPARATE DECAL-IN-GEAR IDLE (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#25	8272822	DECAL WARNING HIGH VOLTAGE (1 required per assembly)
		37-827282 2 - Decal - Warning [ More info ] $2.09 Available to Order: Shipping delay up to 10 days.
#26	881865	DECAL-CAUTION (Start In Gear) (1 required per assembly)
		37-881865 - Decal -Caution [ More info ] $8.19 Available to Order: Shipping delay up to 10 days.
