Mercury Marine Side Mount Remote Controls & Components Remote Control-4000 Side Mount (14 Pin)

Revise Search: Accessories 1994 & Up > Remote Controls & Components > Side Mount > 1994 & Up > Remote Control-4000 Side Mount (14 Pin)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Remote Control-4000 Side Mount (14 Pin)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0176287	REMOTE CNTRL 15FT (1 required per assembly) — Replaces: 8M0083666, 8M0138640
		8M0176287 - REMOTE CNTRL 15FT [ More info ] $707.02 In Stock
#-	8M0176288	REMOTE CNTRL 20FT (1 required per assembly) — Replaces: 8M0083667, 8M0138641
		8M0176288 - REMOTE CNTRL 20FT [ More info ] $707.02 Available to Order: Shipping delay up to 10 days.
#-	8M0176289	REMOTE CNTRL N/TR (1 required per assembly) — Replaces: 8M0083860, 8M0138642
		8M0176289 - SIDE MOUNT CONTROL 15' [ More info ] $707.02 Available to Order: Shipping delay up to 10 days.
#1	8M0100485	HANDLE ASSEMBLY NON TRIM (1 required per assembly)
		8M0100485 - Handle Without Trim [ More info ] $65.21 Available to Order: Shipping delay up to 10 days.
#2	8M0086976	PLUG HANDLE - REMOTE CONTROL (1 required per assembly)
		8M0086976 - PLUG [ More info ] $1.24 Available to Order: Shipping delay up to 10 days.
#3	8M0083671	GRIP HANDLE (1 required per assembly)
		8M0083671 - GRIP-Handle [ More info ] $9.12 Available to Order: Shipping delay up to 10 days.
#4	NSS	NOT SOLD SEPARATE HANDLE HUB (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#5	8M0192342	LOCK BAR-BLACK (1 required per assembly) — Replaces: 8M0083673, 8M0109629
		8M0192342 - LOCK BAR-BLACK [ More info ] Unavailable
#6	8M0099569	SCREW (M4 X 8) (1 required per assembly)
		108M0099569 - Screw [ More info ] $0.70 Available to Order: Shipping delay up to 10 days.
#7	16924	SPRING (1 required per assembly)
		24-16924 - Spring [ More info ] $1.58 Available to Order: Shipping delay up to 10 days.
#8	858686	SCREW (#8) (2 required per assembly)
		10-858686 - Screw [ More info ] $1.20 Available to Order: Shipping delay up to 10 days.
#9	8M0083674	RETAINER LOCK BAR REMOTE CONTROL (1 required per assembly)
		8M0083674 - Retainer [ More info ] $13.57 Available to Order: Shipping delay up to 10 days.
#10	8M0100486	CAP AND DECAL (1 required per assembly)
		8M0100486 - CAP/Decal ASSY [ More info ] $6.28 Available to Order: Shipping delay up to 10 days.
#11	8222131	BOLT (1 required per assembly)
		10-822213 1 - Bolt [ More info ] Unavailable
#12	8M0100483	HANDLE ASSEMBLY WITH TRIM (1 required per assembly)
		8M0100483 - Handle With Trim [ More info ] Unavailable
		8M0214461 - HANDLE ASY W/TRIM [ More info ] Unavailable
#13	8M0100481	TRIM SWITCH ASSEMBLY (1 required per assembly)
		84-8M0100481 - Trim Switch Assembly [ More info ] $17.83 Available to Order: Shipping delay up to 10 days.
#14	8M0083671	GRIP HANDLE (1 required per assembly)
#15	NSS	NOT SOLD SEPARATE HANDLE HUB (1 required per assembly)
#16	8M0192342	LOCK BAR-BLACK (1 required per assembly) — Replaces: 8M0083673, 8M0109629
#17	8M0099569	SCREW (M4 X 8) (1 required per assembly)
#18	16924	SPRING (1 required per assembly)
#19	858686	SCREW (#8) (2 required per assembly)
#20	8M0083674	RETAINER LOCK BAR REMOTE CONTROL (1 required per assembly)
#21	8M0101176	HOUSING ASSEMBLY REMOTE CONTROL, WITH DECAL SEE SEPARATE PARTS BREAKDOWN FOR REPLACEMENT PARTS. (1 required per assembly)
		8M0101176 - Housing ASY-RC [ More info ] $181.10 Available to Order: Shipping delay up to 10 days.
#22	8M0144930	ALARM ASSEMBLY AUDIO WARNING (1 required per assembly) — Replaces: 8M3001068
		84-8M0144930 - Alarm [ More info ] Unavailable
		84-8M0210763 - ALARM ASSY [ More info ] In Stock
#23	11083A4	SWITCH ASSEMBLY STOP (1 required per assembly)
		87-11083A 4 - Switch Assembly [ More info ] $58.99 Available to Order: Shipping delay up to 10 days.
#24	8M0164890	LANYARD CORD ASSEMBLY 54 INCH, MPP (1 required per assembly) — Replaces: 8M0092849
		8M0164890 - LANYARD ASY Note: Priced Individually [ More info ] $19.22 Available to Order: Shipping delay up to 10 days.
#24	8M0164891	LANYARD ASY @2 (1 required per assembly) — Replaces: 8M0092850
		8M0164891 - Lanyard - Sold Indivudually [ More info ] $19.71 5 In Stock.
#25	8M0055593	GROMMET (1 required per assembly)
		258M0055593 - Grommet [ More info ] $0.91 Available to Order: Shipping delay up to 10 days.
#26	897716K01	SWITCH KIT IGNITION (3 POSITION) WITH KEYS (1 required per assembly)
		87-897716K01 - Switch Kit, 3 Position [ More info ] $71.91 In Stock
#27	8M0207779	LOCKWASHER (1 required per assembly) — Replaces: 76629
		138M0207779 - LOCKWASHER [ More info ] $8.29 Available to Order: Shipping delay up to 10 days.
#28	897716001	NUT PLASTIC-KEY SWITCH (1 required per assembly)
		11-897716001 - Nut, Plastic-Key Switch [ More info ] $5.92 Available to Order: Shipping delay up to 10 days.
#29	8M0088358	SCREW SS (M4 X 0.7X 20) (6 required per assembly)
		108M0088358 - Screw - Priced Individually [ More info ] $0.14 Available to Order: Shipping delay up to 10 days.
#30	NSS	NOT SOLD SEPARATE UPPER / LOWER BACK, HOUSING (1 required per assembly)
#31	8M0114782	SPACER SIDE MOUNT REMOTE CONTROL (1 required per assembly)
		8M0114782 - Spacer [ More info ] $28.74 Available to Order: Shipping delay up to 10 days.
#32	8M0204698	SCREW @5 (1 required per assembly) — Replaces: 859665
		10-8M0204698 - SCREW @5 [ More info ] Unavailable
#33	401196	NUT (M6) (3 required per assembly)
		11-40119 6 - Nut [ More info ] $3.06 Available to Order: Shipping delay up to 10 days.
#34	8M0088358	SCREW SS (M4 X 0.7X 20) (3 required per assembly)
#35	40116110T	SCREW (M6 X 110) (3 required per assembly) — Replaces: 8M0094609
		10-40116110T - Screw [ More info ] $4.64 4 In Stock.
#36	35280	WASHER (.255 X .620 X .030) STAINLESS STEEL (3 required per assembly)
		12-35280 - Washer, (.255 X .620 X .030) Stainless Steel [ More info ] $3.19 $2.56 10+ In Stock.
#37	8M2100450	HARNESS ADAPTER NEUTRAL, FEMALE (1 required per assembly)
		848M2100450 - Harness-ADAP FEML [ More info ] Unavailable
#38	8M2100451	HARNESS ADAPTER NEUTRAL, MALE (1 required per assembly)
		848M2100451 - Harness-ADAP MALE [ More info ] Unavailable
#39	816311T	TIE STRAP (8.00 INCHES) (3 required per assembly)
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 10+ In Stock.
#40	899145	CLIP TIE STRAP (2 required per assembly)
		54-899145 - Clip [ More info ] $3.39 Available to Order: Shipping delay up to 10 days.
#41	8M0143199	TRIM HARNESS REMOTE CONTROL, 15 FEET (1 required per assembly) — Replaces: 8M0101077
		848M0143199 - Harness-RC 15 FT [ More info ] $185.76 Available to Order: Shipping delay up to 10 days.
#41	8M0143200	TRIM HARNESS REMOTE CONTROL, 20 FEET Trim Model Application (1 required per assembly) — Replaces: 8M0101079
		848M0143200 - HARNESS-RC 20 FT [ More info ] $201.35 Available to Order: Shipping delay up to 10 days.
#42	814434T	BULLET TERMINAL PLUG (1 required per assembly)
		86-814434T - Terminal Kit -20PCS [ More info ] $15.99 Available to Order: Shipping delay up to 10 days.
#43	8M0101080	HARNESS NON TRIM REMOTE CONTROL, 15 FEET Non Trim Model Application (1 required per assembly)
		848M0101080 - Harness-RC 15 FT [ More info ] $180.38 Available to Order: Shipping delay up to 10 days.
#44	814434T	BULLET TERMINAL PLUG (1 required per assembly)
