Cylinder Block Assembly

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	899162A06	CYLINDER BLOCK (1 required per assembly) — Replaces: 9811T87, 9811T92
		885-899162A06 - Cylinder Block [ More info ] Unavailable
#1	889437A2	POWERHEAD ASSEMBLY COMPLETE (1 required per assembly)
		885-889437A 2 - Powerhead 250 Dfi Jet [ More info ] Unavailable
#2	8M0036405	PIN CENTER MAIN (3 required per assembly) — Replaces: 67296
		17-8M0036405 - Pin - Center Main [ More info ] $4.39 Available to Order: Shipping delay up to 10 days.
#3	82446180	SCREW (M10 X 80) (8 required per assembly)
		10-824461 80 - Screw [ More info ] $15.69 Available to Order: Shipping delay up to 10 days.
#4	43044	PIN DOWEL - WITHOUT HOLE (.375 X .625) (1 required per assembly)
		17-43044 - Pin -Dowel-solid [ More info ] $2.49 Available to Order: Shipping delay up to 10 days.
#5	82130012	SCREW (M6 X 12) (2 required per assembly)
		10-821300 12 - Screw - Priced Individually [ More info ] $1.80 5 In Stock.
#6	8M0111325	COVER STARTER (2 required per assembly) — Replaces: 8569662, 8M0041759
		8M0111325 - Cover [ More info ] $45.99 Available to Order: Shipping delay up to 10 days.
#7	81893440	SCREW (M8 X 40) (4 required per assembly)
		10-818934 40 - Screw [ More info ] $4.19 Available to Order: Shipping delay up to 10 days.
#8	81893435	SCREW (14 required per assembly)
		10-818934 35 - Screw [ More info ] $3.99 Available to Order: Shipping delay up to 10 days.
		108M0103814 - Screw (M8 x 35 MM) [ More info ] $4.19 6 In Stock.
#9	8781051	CHECK VALVE (1 required per assembly)
		21-878105 1 - Check Valve [ More info ] $45.99 3 In Stock.
#10	8248577	DEFLECTOR WATER (6 required per assembly)
		824857 7 - Water Deflector [ More info ] $2.59 Available to Order: Shipping delay up to 10 days.
#11	36382	PLUG (1 required per assembly)
		22-36382 - Plug [ More info ] $5.49 Available to Order: Shipping delay up to 10 days.
		18-8111-9 - Pipe Plug, 1/4 Inch, (Pack of 3) [ More info ] $12.29 Available to Order: Shipping delay up to 10 days.
		18-4256 - Plug, 1/4 Inch Brass, Sold Individually [ More info ] $2.46 2 In Stock.
#12	328022	PLUG-(BRASS)@2 (1 required per assembly)
		22-32802 2 - Brass Pipe Plug, Priced Individually [ More info ] $7.59 1 In Stock.
		18-4263 - Pipe Plug, 1/8-27 NPT, Brass [ More info ] $5.30 10+ In Stock.
#13	850309001	PLUG STOP STOP (6 required per assembly) — Replaces: 850309
		19-850309001 - Plug - Stop [ More info ] $2.39 Available to Order: Shipping delay up to 10 days.
#14	8M0204679	PLUG-PIPE (1 required per assembly) — Replaces: 428611
		22-8M0204679 - Exhaust Manifold Pipe Plug [ More info ] $10.99 Available to Order: Shipping delay up to 10 days.
#15	328022	PLUG-(BRASS)@2 (2 required per assembly)
#16	8405101	PIN SPECIAL - FLYWHEEL COVER (1 required per assembly)
		17-840510 1 - Pin [ More info ] $37.99 Available to Order: Shipping delay up to 10 days.
#17	8589521	BRACKET STARTER (1 required per assembly)
		858952 1 - Starter Bracket [ More info ] Unavailable
#18	858902	CLAMP CABLE SUPPORT (.562) (1 required per assembly)
		54-858902 - Clamp [ More info ] $4.79 Available to Order: Shipping delay up to 10 days.
#19	8588641	RETAINER OIL LINE (1 required per assembly)
		858864 1 - Retainer [ More info ] $1.90 Available to Order: Shipping delay up to 10 days.
#20	81893420	SCREW (1 required per assembly)
		10-818934 20 - Screw [ More info ] $5.79 Available to Order: Shipping delay up to 10 days.
#21	859172	CLAMP (.625) (2 required per assembly)
		54-859172 - Clamp [ More info ] $5.19 1 In Stock.
#22	9787A4	END CAP ASSEMBLY LOWER (1 required per assembly)
		1171-9787A 4 - End Cap Assembly [ More info ] $100.49 Available to Order: Shipping delay up to 10 days.
#23	8308981	SEAL OIL (2 required per assembly)
		26-830898 1 - Seal [ More info ] $27.39 Available to Order: Shipping delay up to 10 days.
#24	62700	O-RING (3.237 X .103) (1 required per assembly)
		25-62700 - O-Ring [ More info ] $3.99 1 In Stock.
		18-0860-9 - O-Ring 25-62700 2-Pack [ More info ] $7.29 Available to Order: Shipping delay up to 10 days.
#25	82130020	SCREW @5 (4 required per assembly)
		10-821300 20 - Screw - Priced Individually [ More info ] $2.69 Available to Order: Shipping delay up to 10 days.
#26	8266241	CLAMP CONNECTOR (1 required per assembly)
		826624 1 - Clamp [ More info ] $26.59 Available to Order: Shipping delay up to 10 days.
#27	82130012	SCREW @5 (2 required per assembly)
#28	8M0045380	SCREW @5 (40 required per assembly) — Replaces: 859096, 891570050
		10-8M0045380 - Screw - Priced Individually [ More info ] $6.89 1 In Stock.
#29	818574	SEAL CYLINDER HEAD (2 required per assembly)
		818574 - Cylinder Head Seal [ More info ] $27.69 In Stock
#30	884391	SEAL CYLINDER BORE (6 required per assembly)
		884391 - Cylinder Bore Seal [ More info ] $21.19 $20.49 Available to Order: Shipping delay up to 10 days.
#31	858483T05	HEAD ASY-CYL-PORT - Port (1 required per assembly)
		900-858483T05 - Cylinder Head Assembly - Port [ More info ] $372.99 Available to Order: Shipping delay up to 10 days.
#31	858485T05	HEAD ASY-CYL-STBD - Starboard (1 required per assembly)
		900-858485T05 - Cylinder Head Assembly - Stbd [ More info ] $366.99 Available to Order: Shipping delay up to 10 days.
#32	8M0148668	SENSOR ASSEMBLY TEMPERATURE - Design II (2 required per assembly) — Replaces: 885342001, 885342002
		8M0148668 - Temperature Sensor [ More info ] $48.39 1 In Stock.
#32	889575	SENSOR ASSY-TEMP - Design I (2 required per assembly) — Replaces: 858535
		889575 - Temperature Sensor Assembly [ More info ] Unavailable
		8M0214984 - Exhaust Temperature Sensor [ More info ] $62.49 1 In Stock.
#33	896699	O-RING (1.78 MM X .08 MM) - Design II (1 required per assembly) — Replaces: 888814
		25-896699 - O-ring, (1.78 Mm X .08 Mm) [ More info ] $12.49 Available to Order: Shipping delay up to 10 days.
#33	627021	O-RING (.301 X .070) - Design I (2 required per assembly) — Replaces: 62702
		25-62702 1 - O-Ring [ More info ] $1.70 10+ In Stock.
#34	82130025	SCREW @5 (4 required per assembly)
		10-821300 25 - Screw [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#35	885562A2	COVER ASSEMBLY WITH FITTING - Starboard (1 required per assembly)
		885562A 2 - Cover Assembly [ More info ] $39.49 Available to Order: Shipping delay up to 10 days.
#35	885562A1	COVER ASSEMBLY WITH FITTING - Port (1 required per assembly)
		885562A 1 - Cover Assembly [ More info ] Unavailable
#36	8503181	GASKET COVER (2 required per assembly)
		27-850318 1 - Gasket [ More info ] $4.99 4 In Stock.
#37	857186T02	PLATE ASSEMBLY ALTERNATOR (1 required per assembly) — Replaces: 857186A1
		857186T02 - Plate Assembly -alt [ More info ] $204.49 Available to Order: Shipping delay up to 10 days.
#38	855729	MOUNT (3 required per assembly)
		23-855729 - Mount [ More info ] $49.99 Available to Order: Shipping delay up to 10 days.
#39	855725	WASHER (6 required per assembly)
		12-855725 - Washer [ More info ] $2.19 Available to Order: Shipping delay up to 10 days.
#40	82130145	SCREW (3 required per assembly)
		10-821301 45 - Screw [ More info ] $10.99 Available to Order: Shipping delay up to 10 days.
#41	858951	J CLIP (1 required per assembly)
		54-858951 - J Clip [ More info ] $6.79 Available to Order: Shipping delay up to 10 days.
#42	82130012	SCREW @5 (2 required per assembly)
#43	858424	CLAMP (1 required per assembly)
		54-858424 - Clamp [ More info ] $7.29 Available to Order: Shipping delay up to 10 days.
#44	19565002	GROMMET SPLIT (1 required per assembly) — Replaces: 19565
		25-19565002 - Grommet [ More info ] $30.99 Available to Order: Shipping delay up to 10 days.
#45	40011107	SCREW @5 (2 required per assembly)
		10-40011107 - SCREW [ More info ] $1.80 2 In Stock.
#46	8M0082988	SENSOR CRANKSHAFT POSITION CRANKSHAFT POSITION (1 required per assembly) — Replaces: 8283582, 8M0030022
		8M0082988 - Sensor Assembly [ More info ] $120.49 $115.99 In Stock
#47	858950	WASHER (1 required per assembly)
		12-858950 - Washer [ More info ] Unavailable
#48	82130016	SCREW @5 (1 required per assembly)
		10-821300 16 - Screw - Priced Individually [ More info ] $5.89 2 In Stock.
#49	40011113	SCREW (3 required per assembly)
		10-40011113 - Screw [ More info ] $1.99 Available to Order: Shipping delay up to 10 days.
#50	8582261	COVER THROTTLE POSITION INDICATOR (1 required per assembly)
		858226 1 - Cover [ More info ] $25.99 Available to Order: Shipping delay up to 10 days.
#51	8M0008111	LINK THROTTLE POSITION INDICATOR (1 required per assembly) — Replaces: 883082
		8M0008111 - TPI Link [ More info ] $41.99 Available to Order: Shipping delay up to 10 days.
#52	883081	LEVER THROTTLE POSITION INDICATOR (1 required per assembly)
		883081 - Lever -tps [ More info ] $16.49 Available to Order: Shipping delay up to 10 days.
#53	8M6005165	TPI (1 required per assembly) — Replaces: 83295211
		8M6005165 - Throttle Position Sensor, TPI [ More info ] $164.99 $158.49 In Stock
#54	858932	CLIP (1 required per assembly)
		54-858932 - Clip [ More info ] $2.39 Available to Order: Shipping delay up to 10 days.
#55	8544862	BRACKET (1 required per assembly)
		854486 2 - Bracket [ More info ] $22.99 Available to Order: Shipping delay up to 10 days.
#56	82130025	SCREW @5 (3 required per assembly)
#57	65567	WASHER @2 (3 required per assembly)
		12-65567 - Washer, (.265 X .750 X .048) Stainless Steel [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
#58	834985	GROMMET @5 (3 required per assembly)
		25-834985 - Grommet [ More info ] $3.00 2 In Stock.
		25-8M0190980 - GROMMET Note: Must be ordered in multiples of 5 [ More info ] $3.89 Available to Order: Shipping delay up to 10 days.
#59	856954	BUSHING (3 required per assembly)
		23-856954 - Bushing [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#60	8M0024808	J CLIP (3 required per assembly) — Replaces: 65292
		54-8M0024808 - J-CLIP [ More info ] Unavailable
#61	36001	WASHER @3 (1 required per assembly)
		12-36001 - Washer - Priced Individually [ More info ] $1.50 10+ In Stock.
		18-4270 - Washer 12-36001 [ More info ] $1.25 $0.91 2 In Stock.
#62	889439A01	GASKET/SEAL SET POWERHEAD - NOTE: See Gasket/Seal Set - Powerhead Section For Parts Breakdown (1 required per assembly)
		27-889439A01 - Powerhead Gasket Set [ More info ] $259.99 Available to Order: Shipping delay up to 10 days.
#63	859736	CLIP CABLE SUPPORT (1 required per assembly)
		859736 - CLIP Cable Suppor [ More info ] Unavailable
#64	63779	PIN DOWEL (.250 X .625) IF REQUIRED (4 required per assembly)
		17-63779 - Pin, Dowel (.250 X .625) [ More info ] $5.09 1 In Stock.
